| Attribute | Value |
|---|---|
| ABS Tone Ring Included | No |
| Center Hole Diameter | 2.84, 72.15 |
| Conventional Or Drum In Hat Type Rotor | Conventional |
| Directional Or Non Directional Brake Surface | Non-directional |
| Discard Thickness | 0.965, 24.5 |
| Harmonize Code | 8708.30.5030 |
| Material | Cast Iron |
| Mounting Bolt Hole Circle Diameter | 114.3, 4.5 |
| Mounting Bolt Hole Diameter | 0.636, 16.15 |
| Mounting Bolt Hole Quantity | 5 |
| Nominal Thickness | 1.025, 26.05 |
| Overall Height | 2.6, 66.05 |
| Salability Restrictions | No |
| Solid Or Vented Type Rotor | Solid |
| Stud/Lug Hole Quantity | 5 |
| Surface Type | Smooth |
| UNSPSC Code | 25171715 |
This part fits the following vehicles:
| SubmodelSUB- MODEL |
Body Style | Years | Engine | Attributes |
|---|---|---|---|---|
| Eddie Bauer | SUV | 2003 | V6 4.0L | AWD Automatic |
| Eddie Bauer | SUV | 2003 | V6 4.0L FLEX | AWD Automatic |
| Eddie Bauer | SUV | 2003 | V8 4.6L | AWD Automatic |
| Eddie Bauer | SUV | 2002 - 2003 | V6 4.0L | RWD/4WD Automatic |
| Eddie Bauer | SUV | 2002 - 2003 | V6 4.0L FLEX | RWD/4WD Automatic |
| Eddie Bauer | SUV | 2002 - 2003 | V8 4.6L | RWD/4WD Automatic |
| Limited | SUV | 2003 | V6 4.0L | AWD Automatic |
| Limited | SUV | 2003 | V6 4.0L FLEX | AWD Automatic |
| Limited | SUV | 2003 | V8 4.6L | AWD Automatic |
| Limited | SUV | 2002 - 2003 | V6 4.0L | RWD/4WD Automatic |
| Limited | SUV | 2002 - 2003 | V6 4.0L FLEX | RWD/4WD Automatic |
| Limited | SUV | 2002 - 2003 | V8 4.6L | RWD/4WD Automatic |
| Postal | Stripped Chassis | 2002 - 2003 | V6 4.0L | RWD/4WD Automatic |
| Postal | Stripped Chassis | 2002 - 2003 | V6 4.0L FLEX | RWD/4WD Automatic |
| XLS | SUV | 2003 | V6 4.0L | AWD Automatic |
| XLS | SUV | 2003 | V6 4.0L FLEX | AWD Automatic |
| XLS | SUV | 2002 - 2003 | V6 4.0L | RWD/4WD Automatic |
| XLS | SUV | 2002 | V6 4.0L | RWD/4WD Manual |
| XLS | SUV | 2002 - 2003 | V6 4.0L FLEX | RWD/4WD Automatic |
| XLS | SUV | 2002 | V6 4.0L FLEX | RWD/4WD Manual |
| XLT | SUV | 2003 | V6 4.0L | AWD Automatic |
| XLT | SUV | 2003 | V6 4.0L FLEX | AWD Automatic |
| XLT | SUV | 2003 | V8 4.6L | AWD Automatic |
| XLT | SUV | 2002 - 2003 | V6 4.0L | RWD/4WD Automatic |
| XLT | SUV | 2002 - 2003 | V6 4.0L FLEX | RWD/4WD Automatic |
| XLT | SUV | 2002 - 2003 | V8 4.6L | RWD/4WD Automatic |
We offer fast, reliable shipping on all orders:
We want you to be 100% satisfied with your purchase. That's why we offer:
This part comes with a limited lifetime warranty. Warranty begins on the original purchase date.
Warranty does NOT cover:
| Brand | Part Number |
|---|---|
| Advance Auto Parts | YH145341 |
| Advance Auto Parts | YH145341C |
| Advance Auto Parts | YH145341P |
| Autopartsource | 492375 |
| Autopartsource | 592375 |
| Autospecialty | AR8586 |
| Autospecialty | AR8586E |
| Autoxtra | 125721 |
| Autoxtra | 80680027 |
| AutoZone | 54097DG |
| AutoZone | DL54097 |
| Bendix | 145341 |
| Bosch | 20010331 |
| BrakeBest | 680027 |
| BrakeBest | 680027FZN |
| BrakeBest | 680027R |
| BrakeBest | 680027RGS |
| BrakeBest | 81-125721 |
| Brembo | 09.8975.85 |
| Brembo | 27238 |
| Bridgestone | 7006426 |
| Casting Numbers | 211381-C |
| Casting Numbers | 2539901 |
| Casting Numbers | 325541 |
| Centric Parts | 120.65082 |
| Centric Parts | 120.65082CRY |
| Centric Parts | 121.65082 |
| Centric Parts | 126.65082CSL |
| Centric Parts | 126.65082CSR |
| Centric Parts | 126.65082SL |
| Centric Parts | 126.65082SR |
| Centric Parts | 127.65082CL |
| Centric Parts | 127.65082CR |
| Centric Parts | 127.65082L |
| Centric Parts | 127.65082R |
| Centric Parts | 128.65082CL |
| Centric Parts | 128.65082CR |
| Centric Parts | 128.65082L |
| Centric Parts | 128.65082R |
| Centric Parts | 227.65082L |
| Centric Parts | 227.65082R |
| Centric Parts | 320.65082 |
| Centric Parts | 320.65082F |
| Centric Parts | 321.65082 |
| Dura Corp | BR54097 |
| Dura Corp | BR5409702 |
| DuraGo | 60353 |
| DuraGo | 900298 |
| DuraGo | BR60353 |
| DuraGo | BR900298 |
| Guardian | 52-125721 |
| Mazda | 1F6033251A |
| Mighty Distributing System | 54097 |
| Motorcraft | 2U2Z1V125FA |
| Motorcraft | BRR107 |
| Motorcraft | NBRR16 |
| Pep Boys | 54097G |
| PowerStop | AR8586EVC |
| Promax | 14-54097 |
| Promax | 20-54094 |
| Quality Brand | Q4103 |
| UAP | 2054097 |
| Ultra Brake | 54180 |
| Universal | 102688 |
| VIPAR - Vehicle Indusrty Parts & Manufacturing | X51352 |
| WABCO - Archived | PS125721 |
| Wagner Brake | BD125721 |
| Wagner Brake | BD125721E |
| Wagner Brake | BD126030 |
| Winhere | 662864 |
Fits Years: 2002 2003
Fits Models: Explorer
