| Attribute | Value |
|---|---|
| Attribute ID (Type) | California Proposition 65 |
| Bolt Circle Diameter [cntrc] In | 5.500 |
| Bolt Circle Diameter [cntrc] Mm | 139.700 |
| Bolt Circle Diameter In | 5.500 |
| Bolt Circle Diameter Mm | 139.70 |
| Brake Pilot Diameter | 3.542, 89.970 |
| Flange Diameter | 182.96, 182.960, 7.203 |
| Inner Mount Pilot [cntrc] In | 3.909 |
| Inner Mount Pilot [cntrc] Mm | 99.290 |
| Mounting Hole Qty [cntrc] | 4 |
| Mounting Thread Size | M14 |
| Mouting Thread Size [cntrc] Mm | 14.000 |
| Notes [cntrc] | Abs Ring 45 Teeth; 4wd Hub Engage, Removable Abs Sensor Wire; "o" Ring Grove In Inner Hub Pilot - Internal Pilot Brgs. |
| Off Set (inch) | 45.59 |
| Off Set [cntrc] In | 45.590 |
| Off Set [cntrc] Mm | 1.795 |
| Product Grade [cntrc] | Premium |
| Spline Quantity | 45 |
| Thread Pitch To Wheel Mounting | 18 |
| Thread Pitch To Wheel Mounting [cntrc] In | 18.000 |
| Wheel Pilot Diameter | 3.416, 86.800 |
| Wheel Stud Quantity | 5 |
| Wheel Stud Size | 0.5625, 0.563 |
| Wheel Studs Included | Yes |
This part fits the following vehicles:
| SubmodelSUB- MODEL |
Body Style | Years | Engine | Attributes |
|---|---|---|---|---|
| FX2 | Crew Cab Pickup | 2010 | V8 4.6L | RWD Automatic |
| FX2 | Crew Cab Pickup | 2010 | V8 5.4L FLEX | RWD Automatic |
| FX2 | Extended Cab Pickup | 2010 | V8 4.6L | RWD Automatic |
| FX2 | Extended Cab Pickup | 2010 | V8 5.4L FLEX | RWD Automatic |
| FX4 | Crew Cab Pickup | 2010 | V8 5.4L FLEX | 4WD Automatic |
| FX4 | Extended Cab Pickup | 2010 | V8 5.4L FLEX | 4WD Automatic |
| Harley-Davidson Edition | Crew Cab Pickup | 2010 | V8 5.4L FLEX | AWD/RWD Automatic |
| King Ranch | Crew Cab Pickup | 2010 | V8 5.4L FLEX | RWD/4WD Automatic |
| Lariat | Crew Cab Pickup | 2010 | V8 5.4L FLEX | RWD/4WD Automatic |
| Lariat | Extended Cab Pickup | 2010 | V8 5.4L FLEX | RWD/4WD Automatic |
| Platinum | Crew Cab Pickup | 2010 | V8 5.4L FLEX | RWD/4WD Automatic |
| STX | Extended Cab Pickup | 2010 | V8 4.6L | RWD/4WD Automatic |
| STX | Standard Cab Pickup | 2010 | V8 4.6L | RWD/4WD Automatic |
| SVT Raptor | Extended Cab Pickup | 2010 | V8 5.4L FLEX | 4WD Automatic |
| SVT Raptor | Extended Cab Pickup | 2010 | V8 6.2L | 4WD Automatic |
| XL | Crew Cab Pickup | 2010 | V8 4.6L | RWD/4WD Automatic |
| XL | Crew Cab Pickup | 2010 | V8 5.4L FLEX | RWD/4WD Automatic |
| XL | Extended Cab Pickup | 2010 | V8 4.6L | RWD/4WD Automatic |
| XL | Extended Cab Pickup | 2010 | V8 5.4L FLEX | RWD/4WD Automatic |
| XL | Standard Cab Pickup | 2010 | V6 4.2L | RWD Automatic & Manual |
| XL | Standard Cab Pickup | 2010 | V8 4.6L | RWD/4WD Automatic |
| XL | Standard Cab Pickup | 2010 | V8 5.4L FLEX | RWD/4WD Automatic |
| XLT | Crew Cab Pickup | 2010 | V8 4.6L | RWD/4WD Automatic |
| XLT | Crew Cab Pickup | 2010 | V8 5.4L FLEX | RWD/4WD Automatic |
| XLT | Extended Cab Pickup | 2010 | V8 4.6L | RWD/4WD Automatic |
| XLT | Extended Cab Pickup | 2010 | V8 5.4L FLEX | RWD/4WD Automatic |
| XLT | Standard Cab Pickup | 2010 | V8 4.6L | RWD/4WD Automatic |
| XLT | Standard Cab Pickup | 2010 | V8 5.4L FLEX | RWD/4WD Automatic |
We offer fast, reliable shipping on all orders:
We want you to be 100% satisfied with your purchase. That's why we offer:
This part comes with a limited lifetime warranty. Warranty begins on the original purchase date.
Warranty does NOT cover:
| Brand | Part Number |
|---|---|
| CR Services | BR930759 |
| Mevotech | H515119 |
| MOOG Chassis Products | 515119 |
| NTN | WE61038 |
| OEM Part Number | 9L3Z 1104A |
| OEM Part Number | 9L3Z1104A |
| Schaeffler | FW7119 |
| Timken | SP550214 |
Fits Years: 2010
Fits Models: F-150
