| Attribute | Value |
|---|---|
| Abutment Clips Included | Yes |
| Attribute ID (Type) | California Proposition 65 |
| Axle Leading/Trailing [cntrc] | Leading |
| Bare Bracket Weight [cntrc] Lbs | 4.05 |
| Bare Caliper Body Weight [cntrc] Lbs | 10.10 |
| Bleeder Install Thread Count [cntrc] In | 4.5 |
| Bleeder Screw Included | Yes |
| Bleeder Screw Included [cntrc] | Yes |
| Bleeder Screw Thread Diameter | 10.000, 10x1.0 |
| Bleeder Screw Thread Size | M10-1.00 |
| Body Air Gap [cntrc] | 74.5mm |
| Bore Size(s) Millimeters | 44 |
| Bracket # [cntrc] | 743.61183 |
| Bracket Air Gap [cntrc] | 36.5mm |
| Bracket Mounting Bolts Include | No |
| Bracket Required (Y/N) | No |
| Bracket Required [cntrc] | Yes |
| Caliper & Pad Hardware Include | Yes |
| Caliper Boot & Seal Kit# [cntrc] | 143.35039 |
| Caliper Color | Gray |
| Caliper Manufacturer [cntrc] | Ate |
| Caliper Type | Floating |
| Car Position [cntrc] | Left Front |
| Casting Material | Cast Iron |
| Casting Number | 419; |
| Color | Gray |
| Disc Brake Caliper Casting Material | Cast Iron |
| Finish | Rust Preventative |
| Finish [cntrc] | Rust Preventative |
| Friction Materials Standards Institute Pad Number | 10x.18181 |
| Hardware Kit# [cntrc] | 117.61058 |
| Inlet Fitting Type | Banjo, Open |
| Inlet Thread Diameter | 10.000, M10x1.0 |
| Inlet Thread Size | M10-1.00 |
| Mount Spread Ctr2Ctr [cntrc] | 140.0mm |
| Mount Thread Size [cntrc] Mm | M14-2.00 |
| Mounting Hardware Included | No |
| New Or Ramanufactured [cntrc] | Remanufactured |
| New Or Remanufactured | Remanufactured |
| Pad Wear Sensor Included | No |
| Pads Included | No |
| Piston Diameter | 1.732, 44.000 |
| Piston Material | Phenolic |
| Piston Quantity | 2 |
| Product Grade [cntrc] | Premium |
| Published Bore Size [cntrc] | 44 |
| Root Core# [cntrc] | 61184 |
| Rust Preventative Coating | Yes |
| Rust Preventative Coating [cntrc] | Yes |
This part fits the following vehicles:
| SubmodelSUB- MODEL |
Body Style | Years | Engine | Attributes |
|---|---|---|---|---|
| Advance | Sedan | 2017 | L4 2.5L | FWD Automatic |
| Energi Platinum | Sedan | 2017 - 2018 | L4 2.0L PLUG-IN HYBRID EV-GAS (PHEV) | FWD Automatic CVT |
| Energi SE | Sedan | 2017 - 2018 | L4 2.0L PLUG-IN HYBRID EV-GAS (PHEV) | FWD Automatic CVT |
| Energi SEL | Sedan | 2019 | L4 2.0L PLUG-IN HYBRID EV-GAS (PHEV) | FWD Automatic CVT |
| Energi Titanium | Sedan | 2017 - 2019 | L4 2.0L PLUG-IN HYBRID EV-GAS (PHEV) | FWD Automatic CVT |
| Platinum | Sedan | 2017 - 2018 | L4 2.0L Turbo | AWD/FWD Automatic |
| Platinum Hybrid | Sedan | 2017 - 2018 | L4 2.0L FULL HYBRID EV-GAS (FHEV) | FWD Automatic CVT |
| S | Sedan | 2017 - 2019 | L4 2.5L | FWD Automatic |
| S | Sedan | 2017 - 2019 | L4 2.5L FLEX | FWD Automatic |
| S Hybrid | Sedan | 2017 - 2018 | L4 2.0L FULL HYBRID EV-GAS (FHEV) | FWD Automatic CVT |
| SE | Sedan | 2017 - 2019 | L4 1.5L Turbo | AWD/FWD Automatic |
| SE | Sedan | 2017 - 2019 | L4 2.0L Turbo | AWD/FWD Automatic |
| SE | Sedan | 2017 - 2019 | L4 2.5L | AWD/FWD Automatic |
| SE | Sedan | 2017 - 2019 | L4 2.5L FLEX | AWD/FWD Automatic |
| SE Hybrid | Sedan | 2017 - 2019 | L4 2.0L FULL HYBRID EV-GAS (FHEV) | FWD Automatic CVT |
| SE Hybrid | Sedan | 2017 | L4 2.0L FULL HYBRID EV-GAS (FHEV) | FWD Automatic |
| SE LUX Hybrid | Sedan | 2018 - 2019 | L4 2.0L FULL HYBRID EV-GAS (FHEV) | FWD Automatic CVT |
| SE LUX Hybrid | Sedan | 2017 | L4 2.0L FULL HYBRID EV-GAS (FHEV) | FWD Automatic |
| SE Luxury | Sedan | 2017 | L4 2.0L Turbo | FWD Automatic |
| SEL | Sedan | 2019 | L4 1.5L Turbo | AWD/FWD Automatic |
| SEL | Sedan | 2019 | L4 2.0L Turbo | AWD/FWD Automatic |
| SEL | Sedan | 2019 | L4 2.5L | AWD/FWD Automatic |
| SEL | Sedan | 2019 | L4 2.5L FLEX | AWD/FWD Automatic |
| SEL Hybrid | Sedan | 2019 | L4 2.0L FULL HYBRID EV-GAS (FHEV) | FWD Automatic CVT |
| Sport | Sedan | 2017 - 2019 | V6 2.7L Turbo | AWD Automatic |
| Titanium | Sedan | 2017 - 2019 | L4 2.0L Turbo | AWD/FWD Automatic |
| Titanium Hybrid | Sedan | 2017 - 2019 | L4 2.0L FULL HYBRID EV-GAS (FHEV) | FWD Automatic CVT |
We offer fast, reliable shipping on all orders:
We want you to be 100% satisfied with your purchase. That's why we offer:
This part comes with a limited lifetime warranty. Warranty begins on the original purchase date.
Warranty does NOT cover:
| Brand | Part Number |
|---|---|
| BrakeBest Brake Calipers | 141.61184 |
| Casting Numbers | 346 |
| Casting Numbers | 419 |
| Casting Numbers | F2GZ2B292A |
| NAPA Brake Calipers | 24283390 |
| OEM Part Number | G3GZ2B121A |
Fits Years: 2017 2018 2019
Fits Models: Fusion
