| Attribute | Value |
|---|---|
| Amperage (A) | 7.1 |
| Average Current Draw | 7.1 |
| Average Flow Rating | 34 |
| Bracket Included | No |
| Connector Color | Black/grey |
| Connector Gender | Male |
| Connector Shape | Round/square |
| Electric Or Mechanical | Electrical |
| Fill Vapor Valve Included | No |
| Flow Rate (gph) | 34 |
| Flow Rate (lph) | 129 |
| Flow Restriction Pressure (psi) | Na |
| Fuel Filter Included | No |
| Fuel Level Sensor Assembly Included | Yes |
| Fuel Level Vent Valve (FLVV) Included | No |
| Fuel Pressure Regulator Included | No |
| Fuel Sending Unit Included | Yes |
| Fuel Static Pressure (psi) | Na |
| Fuel Tank Pressure Sensor Included | No |
| Fuel Type | Gas |
| Gasket Or Seal Included | Yes |
| Gasket Or Seal Material | Nbr |
| Grade Type | Regular |
| Housing Length | 99 |
| Housing Width | 99 |
| In Line Pump | No |
| Inlet Attachment Method | Na |
| Inlet Diameter (In) | Na |
| Inlet Diameter (mm) | Na |
| Inlet Fitting Thread Size | Na |
| Inlet Fitting Type | Na |
| Inlet Outside Diameter | Na |
| Inlet Quantity | 0 |
| Inlet Thread Diameter | Na |
| Internal Or External Strainer | External |
| Lock Ring Included | No |
| Manufacturer | Autotecnica |
| Maximum Flow Rating | Na |
| Maximum Free Flow Rate (gph) | Na |
| Maximum Pressure | Na |
| Maximum Pressure (psi) | Na |
| Mechanical Or Electric | Electric |
| Minimum Flow Rating | Na |
| Minimum Free Flow Rate | Na |
| Minimum Free Flow Rate (gph) | Na |
| Minimum Pressure | Na |
| Module Included | Yes |
| Mounting Hardware Included | No |
| Negative Ground | Yes |
| OE Part/Casting Number | Pfs170 |
| Operating Pressure (psi) | Na |
| Outlet Attachment Method | Hose |
| Outlet Diameter (In) | .37 |
| Outlet Diameter (mm) | 9.5 |
| Outlet Fitting Thread Size | Na |
| Outlet Fitting Type | Hose |
| Outlet Outside Diameter | 9.5 |
| Outlet Quantity | 1 |
| Outlet Thread Diameter | Na |
| Pressure Rating (kPa) | Na |
| Pressure Rating (psi) | Na |
| Pump Design | In Tank |
| Pump Type | Electric |
| Regulator Included | No |
| Relief Pressure (psi) | Na |
| Resistance Ohms Empty | 16.3 |
| Resistance Ohms Full | 159.7 |
| Rheostat Range (Ohm) | 16.3-159.7 |
| Rollover Valve Included | No |
| Shut Off Pressure (psi) | Na |
| Strainer Included | Yes |
| Strainer Location | External |
| System Pressure (psi) | Na |
| Tank Seal Included | Yes |
| Terminal Gender | Female |
| Terminal Quantity | 4 |
| Terminal Shape | Pin |
| Terminal Type | Pin |
| Thermistor Low Fuel Indicator Included | No |
| Top Mount Diameter | 190.3 |
| Top Mount Diameter (mm) | 190.3 |
| Vapor Pressure Sensor Included | No |
| Vapor Vent Line Included | No |
| Wire Harness Included | Yes |
| Wire Quantity | 7 |
| Wiring Harness Length | 450 / 370 |
| Wiring Harness Length (mm) | 820 |
This part fits the following vehicles:
| SubmodelSUB- MODEL |
Body Style | Years | Engine | Attributes |
|---|---|---|---|---|
| Base | Convertible | 2004 | V6 3.9L | RWD Automatic & Manual |
| Base | Convertible | 2001 - 2004 | V6 3.8L | RWD Automatic & Manual |
| Base | Convertible | 2001 - 2003 | V8 4.6L | RWD Automatic & Manual |
| Base | Coupe | 2004 | V6 3.9L | RWD Automatic & Manual |
| Base | Coupe | 2001 - 2004 | V6 3.8L | RWD Automatic & Manual |
| Base | Coupe | 2001 - 2003 | V8 4.6L | RWD Automatic & Manual |
| Equipado | Convertible | 2001 - 2003 | V8 4.6L | RWD Automatic & Manual |
| Equipado | Coupe | 2001 - 2003 | V8 4.6L | RWD Automatic & Manual |
| GT | Convertible | 2001 - 2004 | V8 4.6L | RWD Automatic & Manual |
| GT | Coupe | 2001 - 2004 | V8 4.6L | RWD Automatic & Manual |
| GT Base | Convertible | 2004 | V8 4.6L | RWD Automatic & Manual |
| GT Base | Coupe | 2004 | V8 4.6L | RWD Automatic & Manual |
| GT Bullitt | Coupe | 2001 | V8 4.6L | RWD Automatic & Manual |
| GT Equipado | Convertible | 2004 | V8 4.6L | RWD Automatic & Manual |
| GT Equipado | Coupe | 2004 | V8 4.6L | RWD Automatic & Manual |
| Mach 1 | Coupe | 2003 - 2004 | V8 4.6L | RWD Automatic & Manual |
| SVT Cobra | Convertible | 2003 - 2004 | V8 4.6L Supercharged | RWD Manual |
| SVT Cobra | Convertible | 2001 | V8 4.6L | RWD Manual |
| SVT Cobra | Coupe | 2003 - 2004 | V8 4.6L Supercharged | RWD Manual |
| SVT Cobra | Coupe | 2001 | V8 4.6L | RWD Manual |
| SVT Cobra 10th Anniversary | Convertible | 2003 | V8 4.6L Supercharged | RWD Manual |
| SVT Cobra 10th Anniversary | Coupe | 2003 | V8 4.6L Supercharged | RWD Manual |
We offer fast, reliable shipping on all orders:
We want you to be 100% satisfied with your purchase. That's why we offer:
This part comes with a limited lifetime warranty. Warranty begins on the original purchase date.
Warranty does NOT cover:
| Brand | Part Number |
|---|---|
| Airtex | E2301M |
| Autotecnica | FD0517380 |
| Bosch | 67 170 |
| Carter | P76505M |
| Delphi | FG0827 |
| GMB | 525-2900 |
| Motorcraft | PFS-170 |
| Spectra Premium | SP2301M |
| TYC | 150034 |
| TYC | 150034-A |
Fits Years: 2001 2002 2003 2004
Fits Models: Mustang
