2011 - 2014 Ford Mustang Supercharger Kit (Edelbrock) NEW

Out of Stock
$ 7,658 .95
120-DayReturns
LifetimeWarranty
100%Money-Back

Product Notes Read before buying

Tune TVS Series: 2300 HP: 559 Torque (Ft.-lbs): 503
E-Force Supercharger for 2011-14 Mustang GT 5.0L Coyote - Stage 1
The Edelbrock supercharger Stage 1 Street system part #1588 for 2011-14 Mustangs increases the performance of your Coyote 5.0L 4V engine to 559 horsepower and 503 ft-lbs of torque at the crank. The core of this system is the Eaton Gen VI 2300 TVS rotating assembly with a four-lobe design with 160 degrees of twist for maximum flow, minimum temperature rise and quiet operation for excellent drivability. We also designed our superchargers with an integrated bypass valve to help eliminate parasitic loss under light throttle, improving mileage potential. Our unique and efficient inlet configuration results in a shorter, less restrictive intake path for improved airflow, without the need for a jack-shaft. Keeping the air cool is a high-capacity air-to-water intercooler and low-temp heat exchanger. The Edelbrock #1588 system is 50-state emissions legal. The supplied tune is intended for completely stock vehicles with the exception of a cat-back exhaust.
Brand: Edelbrock
Condition: New
Wrenchy the Robot
Not sure? Ask WrenchyYour Parts Assistant.

Voice or type your vehicle details and Wrenchy will confirm fitment in seconds.

Specifications & Info


Attribute Value
9040 D-215-89
Air Filter Included Yes
Calibration Yes
Center Housing Cooling Type Intercooler
Harmonic Balancer Diameter 6.67
Hose Included Yes
Internal Step Up Yes
Maximum Boost Pressure 4.75
Maximum Horsepower 559
Maximum Pressure Reading 4.75
Maximum Torque 503
Mounting Hardware Included Yes
Oil Capacity 150
Outside Pulley Diameter 3.75
Pulley Belt Width 6-rib
Quantity Kit
RGL Warning: This Product Can Expose You To Chromium, Which Is Known To The State Of California To Cause Cancer Or Birth Defects Or Other Reproductive Harm. For More Information, Visit Www.p65warnings.ca.gov.
Rotor Type Eaton Tvs 2300
System Type Stage 1 - Street System
Tensioner Included Yes
Vehicle Model Mustang

Vehicle Fitment Guide

This part fits the following vehicles:

Ford 1 model (tapclick to expand)(tapclick to hide)
Mustang 2011-2014 (tapclick to expand)(tapclick to hide)
Swipe left/right to see more info
SubmodelSUB-
MODEL
Body Style Years Engine Attributes
Base Convertible 2011 - 2014 V6 3.7L RWD Automatic & Manual
Base Coupe 2011 - 2014 V6 3.7L RWD Automatic & Manual
Boss 302 Coupe 2012 - 2013 V8 5.0L RWD Manual
GT Convertible 2011 - 2014 V8 5.0L RWD Automatic & Manual
GT Coupe 2011 - 2014 V8 5.0L RWD Automatic & Manual
ST Coupe 2014 V6 3.7L RWD Automatic
ST Coupe 2012, 2014 V6 3.7L RWD Manual
Shelby Convertible 2013 - 2014 V8 5.8L Supercharged RWD Manual
Shelby Convertible 2011 - 2012 V8 5.4L Supercharged RWD Manual
Shelby Coupe 2013 - 2014 V8 5.8L Supercharged RWD Manual
Shelby Coupe 2011 - 2012 V8 5.4L Supercharged RWD Manual
Shelby GT500 Convertible 2013 - 2014 V8 5.8L Supercharged RWD Manual
Shelby GT500 Convertible 2011 - 2012 V8 5.4L Supercharged RWD Manual
Shelby GT500 Coupe 2013 - 2014 V8 5.8L Supercharged RWD Manual
Shelby GT500 Coupe 2011 - 2012 V8 5.4L Supercharged RWD Manual
Verify before ordering — please confirm your vehicle's year, make, model and sub-model specifications before placing your order. If anything is unclear, our customer service team is available to help.
