Voice or type your vehicle details and Wrenchy will confirm fitment in seconds.
| Attribute | Value |
|---|---|
| Bolt Grade | 10.9 |
| Color | Plateado, Silver |
| Contenidos Del Paquete | 10 Espárragos |
| Diámetro Del Nudo (in) | 15.75 Mm |
| Estilo | Espárrago Dentado |
| Finish | Geomet |
| Grade Type | Regular |
| Head Diameter | 22 Mm, 22mm |
| Knurl Diameter (In) | 15.75 Mm |
| Longitud De La Rosca (in) | 49 Mm |
| Longitud Del Reborde (in) | 7.5mm |
| Material | Acero, Steel |
| Nariz De Inicio Rápido | No |
| Quick Start Nose | No, Non |
| SAE Or Metric | Metric, Métrico |
| Shoulder Diameter | 15.75 |
| Shoulder Length (In) | 7.5 Mm |
| Shoulder Shape | Redondo, Round |
| Shoulder Thickness | 15.75 |
| Splined | No, Non |
| Thread Diameter | 14 |
| Thread Direction | Clockwise (right), Rotar En El Sentido De Las Agujas Del Reloj (derecha) |
| Thread Length (In) | 49 Mm |
| Thread Pitch | 1.5 |
| Thread Type | Media, Medium |
| Under Head Length | 63 Mm, 63mm |
This part fits the following vehicles:
| SubmodelSUB- MODEL |
Body Style | Years | Engine | Attributes |
|---|---|---|---|---|
| Base | Cab & Chassis | 2019 - 2020 | L4 2.2L DIESEL Turbo | RWD Manual |
| Cargo | Extended Cargo Van | 2019 | L4 2.2L DIESEL Turbo | RWD Automatic & Manual |
| Cargo | Extended Cargo Van | 2019 | V6 3.7L | RWD Automatic & Manual |
| Cargo | Standard Cargo Van | 2019 | L4 2.2L DIESEL Turbo | RWD Automatic & Manual |
| Cargo | Standard Cargo Van | 2019 | V6 3.7L | RWD Automatic & Manual |
| Jumbo | Standard Cargo Van | 2020 | L4 2.2L DIESEL Turbo | RWD Manual |
| Mediana | Standard Cargo Van | 2020 | V6 3.5L | RWD Automatic |
| Pasajeros | Extended Passenger Van | 2020 | V6 3.5L | RWD Automatic & Manual |
| Pasajeros | Extended Passenger Van | 2019 - 2020 | L4 2.2L DIESEL Turbo | RWD Automatic & Manual |
| Pasajeros | Extended Passenger Van | 2019 | V6 3.7L | RWD Automatic & Manual |
| Pasajeros | Standard Passenger Van | 2020 | L4 2.2L DIESEL Turbo | RWD Automatic & Manual |
| Pasajeros | Standard Passenger Van | 2020 | V6 3.5L | RWD Automatic & Manual |
We offer fast, reliable shipping on all orders:
We want you to be 100% satisfied with your purchase. That's why we offer:
This part comes with a limited lifetime warranty. Warranty begins on the original purchase date.
Warranty does NOT cover:
Fits Years: 2019 2020
Fits Models: Transit
