| Attribute | Value |
|---|---|
| Bolt Grade | 10.9 |
| Color | Plateado, Silver |
| Contenidos Del Paquete | 10 Espárragos De La Rueda |
| Diámetro Del Nudo (in) | 15.75 Mm |
| Estilo | Espárrago Dentado |
| Finish | Chrome Plated, Enchapado En Cromo |
| Grade Type | Regular |
| Head Diameter | 22 Mm, 22mm |
| Knurl Diameter (In) | 15.75 Mm |
| Longitud De La Rosca (in) | 51mm |
| Longitud Del Reborde (in) | 7mm |
| Material | Acero, Steel |
| Nariz De Inicio Rápido | Sí |
| Quick Start Nose | Oui, Yes |
| SAE Or Metric | Metric, Métrico |
| Shoulder Diameter | 15.45 |
| Shoulder Length (In) | 7 Mm |
| Shoulder Shape | Redondo, Round |
| Shoulder Thickness | 15.45 |
| Splined | No, Non |
| Thread Diameter | 14 |
| Thread Direction | Clockwise (right), Rotar En El Sentido De Las Agujas Del Reloj (derecha) |
| Thread Length (In) | 51 Mm |
| Thread Pitch | 1.5 |
| Thread Type | Media, Medium |
| Under Head Length | 65 Mm, 65mm |
This part fits the following vehicles:
| SubmodelSUB- MODEL |
Body Style | Years | Engine | Attributes |
|---|---|---|---|---|
| Base | Cab & Chassis | 2019 - 2020 | L4 2.2L DIESEL Turbo | RWD Manual |
| Cargo | Extended Cargo Van | 2019 | L4 2.2L DIESEL Turbo | RWD Automatic & Manual |
| Cargo | Extended Cargo Van | 2019 | V6 3.7L | RWD Automatic & Manual |
| Cargo | Standard Cargo Van | 2024 | V6 3.5L | RWD Automatic |
| Cargo | Standard Cargo Van | 2019 | L4 2.2L DIESEL Turbo | RWD Automatic & Manual |
| Cargo | Standard Cargo Van | 2019 | V6 3.7L | RWD Automatic & Manual |
| Jumbo | Standard Cargo Van | 2022 - 2024 | L4 2.0L DIESEL Turbo | RWD Manual |
| Jumbo | Standard Cargo Van | 2020 | L4 2.2L DIESEL Turbo | RWD Manual |
| Jumbo 470E | Standard Cargo Van | 2021 | L4 2.0L DIESEL Turbo | RWD Manual |
| Larga | Cab & Chassis | 2022 - 2024 | L4 2.0L DIESEL Turbo | RWD Manual |
| Larga 500L | Cab & Chassis | 2021 | L4 2.0L DIESEL Turbo | RWD Manual |
| Mediana | Cab & Chassis | 2022 - 2024 | L4 2.0L DIESEL Turbo | RWD Manual |
| Mediana | Cab & Chassis | 2022 - 2023 | L4 2.0L DIESEL Turbo | RWD Automatic |
| Mediana | Cab & Chassis | 2022 - 2023 | V6 3.5L | RWD Automatic & Manual |
| Mediana | Standard Cargo Van | 2022 - 2023 | L4 2.0L DIESEL Turbo | RWD Automatic & Manual |
| Mediana | Standard Cargo Van | 2022 - 2023 | V6 3.5L | RWD Manual |
| Mediana | Standard Cargo Van | 2020 - 2023 | V6 3.5L | RWD Automatic |
| Mediana 350M | Cab & Chassis | 2021 | L4 2.0L DIESEL Turbo | RWD Manual |
| Pasajeros | Extended Passenger Van | 2024 | L4 2.0L DIESEL Turbo | RWD Automatic & Manual |
| Pasajeros | Extended Passenger Van | 2020 - 2024 | V6 3.5L | RWD Automatic |
| Pasajeros | Extended Passenger Van | 2020, 2024 | V6 3.5L | RWD Manual |
| Pasajeros | Extended Passenger Van | 2019 - 2020 | L4 2.2L DIESEL Turbo | RWD Automatic & Manual |
| Pasajeros | Extended Passenger Van | 2019 | V6 3.7L | RWD Automatic & Manual |
| Pasajeros | Standard Passenger Van | 2020 | L4 2.2L DIESEL Turbo | RWD Automatic & Manual |
| Pasajeros | Standard Passenger Van | 2020 | V6 3.5L | RWD Automatic & Manual |
| Pasajeros 410L | Standard Passenger Van | 2021 - 2023 | L4 2.0L DIESEL Turbo | RWD Manual |
| Pasajeros 460E | Extended Passenger Van | 2021 - 2023 | L4 2.0L DIESEL Turbo | RWD Manual |
