| Attribute | Value |
|---|---|
| 108.00 | |
| ABS Tone Ring Included | No |
| Assy/Disassy By Qualified Personnel Required! | . |
| Balancing Type | Mill Balancing |
| Bearings Included | No |
| Bolt Hole Circle Ø [in] | 4.25 |
| Bolt Hole Circle Ø [mm] | 108 |
| Bolt Hole Quantity | 5 |
| Brake Disc Thickness [in] | 0.94 |
| Brake Disc Thickness [mm] | 24 |
| Brake Disc Type | Internally Vented |
| California Proposition 65 Required | No |
| Center Hole Diameter | 100.0 |
| Construction | Full Cast |
| Directional Or Non Directional Brake Surface | Non-directional |
| Disc Finish | Oiled |
| Discard Thickness | 22.00 |
| Grade Type | Standard Replacement |
| Hat Finish | Oiled |
| Hole Arrangement / Number | 05/05 |
| Hole Arrangement/Number | 05/05 |
| Inside Diameter | 63.6 |
| Material | Gray Cast Iron |
| Minimum Thickness [in] | 0.87 |
| Mounting Bolt Hole Circle Diameter | 108.00 |
| Mounting Bolt Hole Quantity | 5 |
| Nominal Thickness | 24.00 |
| Outer Diameter [in] | 10.94 |
| Overall Height | 44.40 |
| Rust Resistant Coating | No |
| Solid Or Vented Type Rotor | Vented |
| Surface Type | Smooth |
| Technical Information Number | 54248 |
| Weight [kg] | 7, 7,0 |
| Weight [lb] | 15.44 |
| Weight [lbs] | 15.44 |
This part fits the following vehicles:
| SubmodelSUB- MODEL |
Body Style | Years | Engine | Attributes |
|---|---|---|---|---|
| Electric | Mini Cargo Van | 2011 - 2012 | -- -L BATTERY EV (EV/BEV) | FWD Automatic |
| Electric | Mini Passenger Van | 2011 - 2012 | -- -L BATTERY EV (EV/BEV) | FWD Automatic |
| XL | Mini Cargo Van | 2010 - 2013 | L4 2.0L | FWD Automatic |
| XL | Mini Passenger Van | 2010, 2012 | L4 2.0L | FWD Automatic |
| XLT | Mini Cargo Van | 2010 - 2013 | L4 2.0L | FWD Automatic |
| XLT | Mini Passenger Van | 2010 - 2013 | L4 2.0L | FWD Automatic |
| XLT Premium | Mini Passenger Van | 2011 - 2013 | L4 2.0L | FWD Automatic |
We offer fast, reliable shipping on all orders:
We want you to be 100% satisfied with your purchase. That's why we offer:
This part comes with a limited lifetime warranty. Warranty begins on the original purchase date.
Warranty does NOT cover:
| Brand | Part Number |
|---|---|
| Akebono | BN0195 |
| Akebono | BN0195E |
| AMC | FO2913 |
| Ashuki | P330144 |
| ATE | 24012401791 |
| ATE | 424179 |
| Bendix | 521911 |
| Bendix | 562251B |
| Blue Print | ADF124340 |
| Borg & Beck | BBD4316 |
| Bosch | 0 986 479 069 |
| Bosch | 0986479112 |
| Bosch | 0986479B66 |
| Brake Engineering | DI956228 |
| Brembo | 09958910 |
| Brembo | 09958911 |
| Brembo | 09958914 |
| Cifam | 800760C |
| Delphi | BG3826 |
| Delphi | BG3826T |
| DON | PCD18732 |
| EBC Brakes | D1235 |
| Febi-Bilstein | 26592 |
| Ferodo | DDF1172 |
| Ferodo | DDF11721 |
| Ferodo | DDF1172C |
| FREMAX BRAKE ROTORS AND DRUMS | BD5980 |
| FTE | 9072121 |
| FTE | BS5366 |
| Girling | 6042771 |
| Hella Pagid | 54248 |
| Hella Pagid | 8DD355110281 |
| Japan Parts | DI0325 |
| Japan Parts | DI0325C |
| Japan Parts | DI0326 |
| JP Group A/S | 1563101500 |
| Jurid | 562251J |
| Jurid | 562251JC |
| Jurid | 562251JC1 |
| Key Parts | KBD4316 |
| LPR | F1006V |
| LPR | F1006VR |
| Magneti Marelli | 360406026500 |
| Magneti Marelli | 360704000300 |
| Magneti Marelli | 361302040130 |
| Mapco | 15699C |
| Meritor | MBR6022 |
| METELLI | 230760C |
| MEYLE | 7155217030 |
| MEYLE | 7835217030PD |
| Mintex | MDC1556 |
| Mintex | MDC1556C |
| Mintex | MVK0013 |
| National | NBD1244 |
| NK Autoparts | 202555 |
| NK Autoparts | 312555 |
| Optimal | BS7668 |
| Optimal | BS7668HC |
| PAGID Racing | 54248PRO |
| Remsa | 666210 |
| SBS | 1815202555 |
| SBS | 1815312555 |
| Textar | 89015600 |
| Textar | 92124800 |
| Textar | 92124803 |
| Textar | 98200124801 |
| TRW | DF4277 |
| VAICO | V2580016 |
| Valeo | 186748 |
| Valeo | 297748 |
| Valeo | 672954 |
| Wagner | WGR11721 |
| Werner Metzger GmbH | 24928 E |
| Zimmermann | 250135000 |
| Zimmermann | 250135020 |
| Zimmermann | 250135070 |
| Zimmermann | 250135072 |
| Zimmermann | 250135075 |
Fits Years: 2010 2011 2012 2013
Fits Models: Transit Connect
