| Attribute | Value |
|---|---|
| ABS Tone Ring Included | No |
| Assy/Disassy By Qualified Personnel Required! | . |
| Bolt Circle Diameter | 108.0 |
| Bolt Hole Circle Ø [in] | 4.25 |
| Bolt Hole Circle Ø [mm] | 108 |
| Bolt Hole Quantity | 5 |
| Brake Diameter, Outer [mm] | 279 |
| California Proposition 65 Required | No |
| Center Hole Diameter | 63.4 |
| Directional Or Non Directional Brake Surface | Non-directional |
| Drum Diameter [mm] | 228,5, 228.5 |
| Fitting Position | Rear Axle |
| Hole Arrangement / Number | 05/05 |
| Hole Arrangement/Number | 05/05 |
| Inner Brake Drum Height [in] | 2.68 |
| Inner Brake Drum Height [mm] | 68 |
| Inner Brake Drum Diameter [in] | 9.02 |
| Inner Brake Drum Diameter [mm] | 229 |
| Inside Diameter | 228.50 |
| Material | Gray Cast |
| Max. Skimmed Drum Measure [mm] | 229.6 |
| Max.skimmed Drum Measure [mm] | 229,6 |
| Maximum Brake Diameter (Discard) | 230.20 |
| Maximum Drum Diameter | 229.6 |
| Mounting Hole Diameter | 108.00 |
| Number Of Holes | 5 |
| Outer Brake Diameter [mm] | 279 |
| Outer Brake Drum Diameter [in] | 10.98 |
| Outer Brake Drum Diameter [mm] | 279 |
| Overall Height | 89.5 |
| Rust Resistant Coating | Yes |
| Technical Information Number | 61244 |
| Total Br. Drum Height [mm] | 89,5 |
| Total Brake Drum Height [in] | 3.54 |
| Total Brake Drum Height [mm] | 89.5 |
| Weight | 17.4 |
| Weight [kg] | 7,9, 7.9 |
| Wheel Bolt Bore Diameter [mm] | 12.9 |
| Wheel Bolt Bore Ø [mm] | 12.9 |
| Max. Brake Drum Reboring Dimension [mm] | 229.6 |
This part fits the following vehicles:
| SubmodelSUB- MODEL |
Body Style | Years | Engine | Attributes |
|---|---|---|---|---|
| Electric | Mini Cargo Van | 2011 - 2012 | -- -L BATTERY EV (EV/BEV) | FWD Automatic |
| Electric | Mini Passenger Van | 2011 - 2012 | -- -L BATTERY EV (EV/BEV) | FWD Automatic |
| XL | Mini Cargo Van | 2010 - 2013 | L4 2.0L | FWD Automatic |
| XL | Mini Passenger Van | 2010, 2012 | L4 2.0L | FWD Automatic |
| XLT | Mini Cargo Van | 2010 - 2013 | L4 2.0L | FWD Automatic |
| XLT | Mini Passenger Van | 2010 - 2013 | L4 2.0L | FWD Automatic |
| XLT Premium | Mini Passenger Van | 2011 - 2013 | L4 2.0L | FWD Automatic |
We offer fast, reliable shipping on all orders:
We want you to be 100% satisfied with your purchase. That's why we offer:
This part comes with a limited lifetime warranty. Warranty begins on the original purchase date.
Warranty does NOT cover:
| Brand | Part Number |
|---|---|
| ATE | 24022280331 |
| ATE | 480181 |
| Blue Print | ADBP470000 |
| Borg & Beck | BBR7117 |
| Bosch | 0 986 477 129 |
| Brake Engineering | DR962408 |
| Brembo | 14A69110 |
| Delphi | BF488 |
| Ferodo | FDR329794 |
| FREMAX BRAKE ROTORS AND DRUMS | BD5981 |
| FTE | 9190063 |
| FTE | BT634 |
| Hella Pagid | 61244 |
| Hella Pagid | 8DT355300431 |
| Japan Parts | TA0313 |
| Japan Parts | TA0313C |
| JapKo | 560313 |
| JapKo | 560313C |
| Jurid | 329794J |
| MaXgear | 192315 |
| MEYLE | 7155237038 |
| Mintex | MBD260 |
| NK Autoparts | 252536 |
| Optimal | BT2050 |
| Pilenga | 6018 |
| Quinton Hazell | BDR634 |
| Remsa | 709800 |
| SBS | 1825252536 |
| Textar | 94024400 |
| Textar | 98100024401 |
| TRW | DB4309 |
| Valeo | 237053 |
| Zimmermann | 250176900 |
| Zimmermann | 250176920 |
Fits Years: 2010 2011 2012 2013
Fits Models: Transit Connect
