| Attribute | Value |
|---|---|
| Adjustable | No |
| Attachments Included | No |
| Ball Joint Assembly | Yes |
| Bearing Type | Plastic |
| Bushings Included | No |
| Castle Nut Included | No |
| Cotter Pin Hole | No |
| Cotter Pin Included | No |
| Dust Boot Included | Yes |
| Dust Boot Material | Rubber |
| Grade Type | Standard Replacement |
| Grease Fitting Included | Yes |
| Greaseable | Yes |
| Maximum Outside Diameter | 2.598, 66.00 |
| Mount Plate Included | No |
| Mounting Bolts Included | No |
| Mounting Hardware Included | Yes |
| Mounting Type | Press-in |
| Position(s) | Front Lower |
| Pre Greased | Yes |
| Reinforced | No |
| Retaining Ring Included | Yes |
| Steering Type | Power |
| Stud Tapered End 1 Diameter | 0.717, 18.20 |
| Stud Tapered End 2 Diameter | 0.846, 21.50 |
| Stud Thread Diameter | 0.630, 16.00 |
| Stud Thread Length | 1.024, 26.00 |
| Stud Thread Pitch | 1.50 |
| Stud Type | Threaded |
| Suspension Grade Type | Standard Replacement |
| Tapered Stud | Yes |
| Thread Direction | Counterclockwise (left) |
| Type | Standard |
| Washers Included | No |
| Wear Indicator Included | No |
| Wrench Size | 6 Mm |
This part fits the following vehicles:
| SubmodelSUB- MODEL |
Body Style | Years | Engine | Attributes |
|---|---|---|---|---|
| Electric | Mini Cargo Van | 2011 - 2012 | -- -L BATTERY EV (EV/BEV) | FWD Automatic |
| Electric | Mini Passenger Van | 2011 - 2012 | -- -L BATTERY EV (EV/BEV) | FWD Automatic |
| XL | Mini Cargo Van | 2010 - 2013 | L4 2.0L | FWD Automatic |
| XL | Mini Passenger Van | 2010, 2012 | L4 2.0L | FWD Automatic |
| XLT | Mini Cargo Van | 2010 - 2013 | L4 2.0L | FWD Automatic |
| XLT | Mini Passenger Van | 2010 - 2013 | L4 2.0L | FWD Automatic |
| XLT Premium | Mini Passenger Van | 2011 - 2013 | L4 2.0L | FWD Automatic |
We offer fast, reliable shipping on all orders:
We want you to be 100% satisfied with your purchase. That's why we offer:
This part comes with a limited lifetime warranty. Warranty begins on the original purchase date.
Warranty does NOT cover:
| Brand | Part Number |
|---|---|
| Mevotech | MS40516 |
| MOOG Chassis Products | K500191 |
Fits Years: 2010 2011 2012 2013
Fits Models: Transit Connect
