| Attribute | Value |
|---|---|
| 130.00 | |
| ABS Tone Ring Included | No |
| Assy/Disassy By Qualified Personnel Required! | . |
| Balancing Type | Mill Balancing |
| Bearings Included | No |
| Bolt Hole Circle Ø [in] | 5.12 |
| Bolt Hole Circle Ø [mm] | 130 |
| Bolt Hole Quantity | 7 |
| Brake Disc Thickness [in] | 0.87 |
| Brake Disc Type | Internally Vented |
| California Proposition 65 Required | No |
| Center Hole Diameter | 100.0 |
| Construction | Full Cast |
| Directional Or Non Directional Brake Surface | Non-directional |
| Disc Finish | Coated |
| Discard Thickness | 19.00 |
| Grade Type | Standard Replacement |
| Hat Finish | Coated |
| Height [in] | 3.03 |
| Hole Arrangement / Number | 05/07 |
| Hole Arrangement/Number | 05/07 |
| Inside Diameter | 85.1 |
| Material | Gray Cast Iron |
| Minimum Thickness [in] | 0.75 |
| Minimum Thickness [mm] | 19 |
| Mounting Bolt Hole Circle Diameter | 130.00 |
| Mounting Bolt Hole Quantity | 7 |
| Nominal Thickness | 22.00 |
| Outer Diameter [in] | 10.87 |
| Overall Height | 77.00 |
| Rust Resistant Coating | Yes |
| Solid Or Vented Type Rotor | Vented |
| Surface | Coated |
| Surface Type | Smooth |
| Technical Information Number | 54315pro |
| Weight [kg] | 6,7, 6.7 |
| Wheel Bolt Bore Diameter [mm] | 15.3 |
| Wheel Bolt Bore Ø [mm] | 15.3 |
This part fits the following vehicles:
| SubmodelSUB- MODEL |
Body Style | Years | Engine | Attributes |
|---|---|---|---|---|
| Base | Cab & Chassis | 2005 - 2006 | L5 2.7L DIESEL Turbo | RWD Automatic |
| Base | Standard Cargo Van | 2006 | L5 2.7L DIESEL Turbo | RWD Automatic |
| Base | Standard Cargo Van | 2006 | L5 2.7L DIESEL Turbo | RWD Automatic |
| Base | Standard Cargo Van | 2002 - 2006 | L5 2.7L DIESEL Turbo | RWD Automatic |
| Base | Standard Passenger Van | 2002 - 2006 | L5 2.7L DIESEL Turbo | RWD Automatic |
We offer fast, reliable shipping on all orders:
We want you to be 100% satisfied with your purchase. That's why we offer:
This part comes with a limited lifetime warranty. Warranty begins on the original purchase date.
Warranty does NOT cover:
| Brand | Part Number |
|---|---|
| Akebono | BN0228 |
| Akebono | BN0228E |
| AMC | FLDI00057 |
| AMC | FLDI00719 |
| AMC | FO2331 |
| ATE | 24012201611 |
| ATE | 24032201611 |
| ATE | 422161 |
| ATE | 522161 |
| Bendix | 561965B |
| Bendix | 562086BC |
| Bendix | 562120B |
| Bendix | 562483B |
| Bendix | 567760B |
| Blue Print | ADU174360 |
| Borg & Beck | BBD5081 |
| Borg & Beck | BBD5134 |
| Bosch | 0 986 478 849 |
| Bosch | 0 986 BB4 024 |
| Bosch | 0986479075 |
| Bosch | 0986AB5930 |
| Bosch | 0986BB4415 |
| Bradi | 1283724 |
| Brake Engineering | DI955555 |
| Brembo | 08681410 |
| Brembo | 09731410 |
| Brembo | 09731411 |
| Brembo | 09731414 |
| Brembo | 09731420 |
| Brembo | 09731421 |
| Brembo | 09731424 |
| Brembo | 09961814 |
| Brembo | 09961820 |
| Brembo | 09961824 |
| Cifam | 800418 |
| Delphi | BG3194 |
| Delphi | BG3236 |
| Delphi | BG3236C |
| DON | PCD18652 |
| EBC Brakes | D841 |
| EBC Brakes | D843 |
| Evobus | 421 129 02 03 |
| Evobus | 902 421 06 12 64 |
| Evobus | 9024210712 |
| Evobus | A9014210312 |
| Evobus | A9014210612 |
| Evobus | A9024210312 |
| Evobus | A9024210412 |
| Evobus | A9024210612 |
| Evobus | A9024210712 |
| Febi-Bilstein | 22857 |
| Febi-Bilstein | 7517 |
| Ferodo | DDF796 |
| Ferodo | DDF859 |
| Ferodo | FCR153A |
| Ferodo | FCR153AX |
| Ferodo | FCR228A |
| Ferodo | FCR228C |
| FREMAX BRAKE ROTORS AND DRUMS | BD0181 |
| FTE | 9072023 |
| FTE | 9082045 |
| FTE | BS4544 |
| FTE | BS4544B |
| FTE | BS4547 |
| Girling | 6027901 |
| Girling | 6043213 |
| Hella Pagid | 54315PRO |
| Hella Pagid | 8DD355111001 |
| Japan Parts | DI0561 |
| Jurid | 561965J |
| Jurid | 567760J |
| Jurid | 569122J |
| Jurid | 569122JC1 |
| Key Parts | KBD5134 |
| Magneti Marelli | 360406032400 |
| Magneti Marelli | 360406032500 |
| Magneti Marelli | 360406032800 |
| Magneti Marelli | 360406085700 |
| Magneti Marelli | 360406098500 |
| Magneti Marelli | 361302040216 |
| Mapco | 15794C |
| Mercedes-Benz | 901 421 03 12 |
| Mercedes-Benz | 901 421 06 12 |
| Mercedes-Benz | 902 421 03 12 |
| Mercedes-Benz | 902 421 04 12 |
| Mercedes-Benz | 902 421 06 12 |
| Mercedes-Benz | 902 421 07 12 |
| Mercedes-Benz | 902 421 09 12 |
| Mercedes-Benz | 902 421 09 12 04 |
| Mercedes-Benz | 9024210912 |
| Mercedes-Benz | 902421091204 |
| Mercedes-Benz | A 421 129 02 03 |
| Mercedes-Benz | A 901 421 03 12 |
| Mercedes-Benz | A 901 421 06 12 |
| Mercedes-Benz | A 902 421 03 12 |
| Mercedes-Benz | A 902 421 04 12 |
| Mercedes-Benz | A 902 421 06 12 |
| Mercedes-Benz | A 902 421 06 12 64 |
| Mercedes-Benz | A 902 421 07 12 |
| Mercedes-Benz | A 902 421 09 12 |
| Mercedes-Benz | A 902 421 09 12 04 |
| Mercedes-Benz | AA9014210312 |
| Mercedes-Benz | AA9014210612 |
| Mercedes-Benz | AA9024210312 |
| Mercedes-Benz | AA9024210412 |
| Mercedes-Benz | AA9024210612 |
| Mercedes-Benz | AA9024210712 |
| Mercedes-Benz | AA9024210912 |
| Mercedes-Benz | AA902421091204 |
| Meritor | MBR6011 |
| MEYLE | 0835212032PD |
| Mintex | MDC1037 |
| Mintex | MDC1037C |
| Mintex | MDK0066 |
| National | NBD790 |
| NK Autoparts | 203334 |
| NK Autoparts | 203397 |
| NK Autoparts | 313397 |
| NK Autoparts | 343397 |
| Optimal | BS4611 |
| Optimal | BS7290 |
| Optimal | BS7290HC |
| PAGID Racing | 52143 |
| PAGID Racing | 54315 |
| Quinton Hazell | BDC4544 |
| Quinton Hazell | BDC4547 |
| Remsa | 646110 |
| Repstar | MB03101031 |
| SBS | 1815203334 |
| SBS | 1815203397 |
| SBS | 1815313397 |
| SBS | 1815343397 |
| Sebro | 50427 |
| Sebro | 50428 |
| Skoda | 2D0 615 301 A |
| Skoda | 2D0 615 301 B |
| Skoda | 2D0 615 301 C |
| Skoda | 2D0 615 301 D |
| Textar | 92131500 |
| Textar | 92131503 |
| Textar | 92131505 |
| Textar | 98200073501 |
| Textar | 98200105401 |
| Textar | 98200131501 |
| Textar | TXD0085 |
| Topran | 107687 |
| Triscan | 812023129 |
| Triscan | 812023131 |
| TRW | DF2756 |
| TRW | DF2790 |
| TRW | DF4321 |
| TRW Steering and Suspension Parts | DF2790S |
| VAICO | V1080013 |
| VAICO | V3080053 |
| Valeo | 186553 |
| Valeo | 186774 |
| Valeo | 187041 |
| Valeo | 672571 |
| Wagner | WGR62281 |
| Werner Metzger GmbH | 24722 E |
| Werner Metzger GmbH | 24804 E |
| Werner Metzger GmbH | 6461.10 |
| Zimmermann | 400143900 |
| Zimmermann | 400144100 |
| Zimmermann | 400144120 |
| Zimmermann | 400144170 |
| Zimmermann | 400144172 |
| Zimmermann | 400144175 |
| Zimmermann | 400144200 |
| Zimmermann | 400144700 |
| Zimmermann | 400144720 |
| Zimmermann | 400144750 |
| Zimmermann | 400647000 |
| Zimmermann | 400647020 |
| Zimmermann | 400647070 |
| Zimmermann | 400647072 |
| Zimmermann | 400647075 |
Fits Years: 2002 2003 2004 2005 2006
Fits Models: Sprinter 2500
