| Attribute | Value |
|---|---|
| Abutment Clips Included | Yes |
| Attribute ID (Type) | California Proposition 65 |
| Axle Leading/Trailing [cntrc] | Leading |
| Bleeder Install Thread Count [cntrc] In | 4.5 |
| Bleeder Screw Included | Yes |
| Bleeder Screw Included [cntrc] | Yes |
| Bleeder Screw Thread Diameter | 10.000, 10x1.0 |
| Bleeder Screw Thread Size | M10-1.00 |
| Body Air Gap [cntrc] | 69.5mm |
| Bore Size(s) Millimeters | 52 |
| Bracket # [cntrc] | 743.85001 |
| Bracket Air Gap [cntrc] | 32.0mm |
| Bracket Included | Yes |
| Bracket Mounting Bolts Include | No |
| Bracket Required (Y/N) | Yes |
| Bracket Required [cntrc] | Yes |
| Caliper & Pad Hardware Include | Yes |
| Caliper Boot & Seal Kit# [cntrc] | 143.85001 |
| Caliper Color | Gray |
| Caliper Manufacturer [cntrc] | Brembo |
| Caliper Type | Floating |
| Car Position [cntrc] | Left Front |
| Casting Material | Cast Iron |
| Color | Gray |
| Disc Brake Caliper Casting Material | Cast Iron |
| Finish | Rust Preventative |
| Finish [cntrc] | Rust Preventative |
| Friction Materials Standards Institute Pad Number | 10x.12680 |
| Hardware Kit# [cntrc] | 117.85001 |
| Inlet Fitting Type | Bubble |
| Inlet Thread Diameter | 10.000, M10x1.0 |
| Inlet Thread Size | M10-1.00 |
| Mount Spread Ctr2Ctr [cntrc] | 196.0mm |
| Mount Thread Size [cntrc] Mm | M14-1.50 |
| Mounting Hardware Included | No |
| New Or Ramanufactured [cntrc] | Remanufactured |
| New Or Remanufactured | Remanufactured |
| Pad Wear Sensor Included | No |
| Pads Included | No |
| Piston Diameter | 2.047, 52.000 |
| Piston Material | Steel |
| Piston Quantity | 2 |
| Product Grade [cntrc] | Premium |
| Published Bore Size [cntrc] | 52 |
| Root Core# [cntrc] | 85002 |
| Rust Preventative Coating | Yes |
| Rust Preventative Coating [cntrc] | Yes |
This part fits the following vehicles:
| SubmodelSUB- MODEL |
Body Style | Years | Engine | Attributes |
|---|---|---|---|---|
| Base | Cab & Chassis | 2015 - 2017 | L4 2.1L DIESEL Turbo | 4WD Automatic |
| Base | Cab & Chassis | 2015 - 2018 | V6 3.0L DIESEL Turbo | 4WD Automatic |
| Base | Cab & Chassis | 2014 - 2017 | L4 2.1L DIESEL Turbo | RWD Automatic |
| Base | Cab & Chassis | 2007 - 2018 | V6 3.0L DIESEL Turbo | RWD Automatic |
| Base | Cab & Chassis | 2007 - 2008 | V6 3.5L | RWD Automatic |
| Base | Extended Cargo Van | 2015 - 2017 | L4 2.1L DIESEL Turbo | 4WD Automatic |
| Base | Extended Cargo Van | 2015 - 2018 | V6 3.0L DIESEL Turbo | 4WD Automatic |
| Base | Extended Cargo Van | 2014 - 2017 | L4 2.1L DIESEL Turbo | RWD Automatic |
| Base | Extended Cargo Van | 2007 - 2008, 2010, 2014 - 2018 | V6 3.0L DIESEL Turbo | RWD Automatic |
| Base | Extended Cargo Van | 2007 - 2008 | V6 3.5L | RWD Automatic |
| Base | Standard Cargo Van | 2015 - 2017 | L4 2.1L DIESEL Turbo | 4WD Automatic |
| Base | Standard Cargo Van | 2015 - 2018 | V6 3.0L DIESEL Turbo | 4WD Automatic |
| Base | Standard Cargo Van | 2014 - 2017 | L4 2.1L DIESEL Turbo | RWD Automatic |
| Base | Standard Cargo Van | 2007 - 2018 | V6 3.0L DIESEL Turbo | RWD Automatic |
| Base | Standard Cargo Van | 2007 - 2008 | V6 3.5L | RWD Automatic |
We offer fast, reliable shipping on all orders:
We want you to be 100% satisfied with your purchase. That's why we offer:
This part comes with a limited lifetime warranty. Warranty begins on the original purchase date.
Warranty does NOT cover:
| Brand | Part Number |
|---|---|
| Beck/Arnley | 0772272S |
| BrakeBest | 18B5089 |
| CARDONE Reman | 185088 |
| CARDONE Reman | 18B5088 |
| CARDONE Reman | 5088 |
| Casting Numbers | 68006726AA |
| Formula Blue Hydraulic Brake Parts | E146-90-007 |
| Formula Blue Hydraulic Brake Parts | E14690007 |
| IMC | 61233710 |
| King Kalipers | 6851 |
| Meritor | R42R85002 |
| NAPA Brake Calipers | 24275640A |
| Nugeon | 22177391 |
| Nugeon | 2217739L |
| OEM Part Number | 0034208883 |
| OEM Part Number | 0044205883 |
| OEM Part Number | 68006736AA |
| OEM Part Number | 68064361AA |
| OEM Part Number | W8002901 |
| Quality Rebuilders Corporation | 68085 |
| UCX | 1014422 |
| UCX | 10442223 |
| UCX | 104422S |
| Wagner Brake | CR140312 |
| Wagner Brake | CR141491 |
Fits Years: 2007 2008 2009 2010 2011 2012 2013 2014 2015 2016 2017 2018
Fits Models: Sprinter 3500
