| Attribute | Value |
|---|---|
| Abutment Clips Included | Yes |
| Attribute ID (Type) | California Proposition 65 |
| Axle Leading/Trailing [cntrc] | Leading |
| Bare Bracket Weight [cntrc] Lbs | 4.65 |
| Bare Caliper Body Weight [cntrc] Lbs | 9.10 |
| Bleeder Install Thread Count [cntrc] In | 5.5 |
| Bleeder Screw Included | Yes |
| Bleeder Screw Included [cntrc] | Yes |
| Bleeder Screw Thread Diameter | 10.000, 10x1.0 |
| Bleeder Screw Thread Size | M10-1.00 |
| Body Air Gap [cntrc] | 66.0mm |
| Bore Size(s) Millimeters | 47.5/47.5 |
| Bracket # [cntrc] | 743.66061 |
| Bracket Air Gap [cntrc] | 36.0mm |
| Bracket Mounting Bolts Include | No |
| Bracket Required [cntrc] | Yes |
| Caliper & Pad Hardware Include | Yes |
| Caliper Boot & Seal Kit# [cntrc] | 143.65030 |
| Caliper Color | Gray |
| Caliper Manufacturer [cntrc] | Akebono |
| Caliper Type | Floating |
| Car Position [cntrc] | Right Front |
| Casting Material | Cast Iron |
| Color | Gray |
| Disc Brake Caliper Casting Material | Cast Iron |
| Finish | Rust Preventative |
| Finish [cntrc] | Rust Preventative |
| Friction Materials Standards Institute Pad Number | 10x.13781 |
| Hardware Kit# [cntrc] | 117.66031 |
| Inlet Fitting Type | Banjo |
| Inlet Thread Diameter | 10.000, M10x1.0 |
| Inlet Thread Size | M10-1.00 |
| Mount Spread Ctr2Ctr [cntrc] | 140.0mm |
| Mount Thread Size [cntrc] Mm | M14-2.00 |
| Mounting Hardware Included | No |
| New Or Ramanufactured [cntrc] | Remanufactured |
| New Or Remanufactured | Remanufactured |
| Notes [cntrc] | Similar To 141.66063, Shorter Bracket |
| Pad Wear Sensor Included | No |
| Pads Included | No |
| Piston Diameter | 1.870, 47.500 |
| Piston Material | Phenolic |
| Piston Quantity | 2 |
| Product Grade [cntrc] | Premium |
| Published Bore Size [cntrc] | 47.5 |
| Root Core# [cntrc] | 66061 |
| Rust Preventative Coating | Yes |
| Rust Preventative Coating [cntrc] | Yes |
This part fits the following vehicles:
| SubmodelSUB- MODEL |
Body Style | Years | Engine | Attributes |
|---|---|---|---|---|
| AT4 | SUV | 2020 | V6 3.6L | AWD/4WD Automatic |
| All Terrain | SUV | 2019 | V6 3.6L | AWD Automatic |
| Denali | SUV | 2017 - 2020 | V6 3.6L | AWD/FWD/4WD Automatic |
| SL | SUV | 2017 - 2020 | L4 2.5L | FWD Automatic |
| SLE | SUV | 2020 | L4 2.0L Turbo | FWD/4WD Automatic |
| SLE | SUV | 2017 - 2020 | L4 2.5L | FWD/4WD Automatic |
| SLE | SUV | 2017 - 2020 | V6 3.6L | FWD/4WD Automatic |
| SLT | SUV | 2020 | L4 2.0L Turbo | FWD/4WD Automatic |
| SLT | SUV | 2018 | V6 3.6L | AWD Automatic |
| SLT | SUV | 2017 - 2019 | L4 2.5L | FWD/4WD Automatic |
| SLT | SUV | 2017 - 2020 | V6 3.6L | FWD/4WD Automatic |
We offer fast, reliable shipping on all orders:
We want you to be 100% satisfied with your purchase. That's why we offer:
This part comes with a limited lifetime warranty. Warranty begins on the original purchase date.
Warranty does NOT cover:
| Brand | Part Number |
|---|---|
| BrakeBest Brake Calipers | 141.66061 |
| Casting Numbers | 13595196 |
| Casting Numbers | 4830 |
| NAPA Brake Calipers | 24283539 |
| OEM Part Number | 13509725 |
Fits Years: 2017 2018 2019 2020
Fits Models: Acadia
