| Attribute | Value |
|---|---|
| Automotive Item Weight (lbs) | 26.631841 Lb |
| Bearings Included | Yes |
| Bolt Circle Diameter | 127 Mm |
| Bolt Hole Quantity | 5 |
| Center Bore Diameter | 65.011 Mm |
| Construction | Vented |
| Conventional Or Drum In Hat Type Rotor | Conventional |
| Directional Or Non Directional Brake Surface | Directional |
| Disc Brake Rotor Material | Iron Alloy |
| Disc Design | Solid |
| Disc Finish | Geomet |
| Discard Thickness | 30.86 Mm |
| Hat Finish | Coated |
| Hub Attached | Yes |
| Nominal Thickness | 32.64 Mm |
| Outside Diameter (Disc Brake Rotor) | 301.2 Mm |
| Overall Height | 125.4 Mm |
| Product Height | 4.937008 In |
| Prop 65 Warning Label Required? | No |
| Rotor Without Hub Assembly | No |
| Rust Resistant Coating | Yes |
| Thickness (Disc Brake Rotor) | 32.64 Mm |
This part fits the following vehicles:
| SubmodelSUB- MODEL |
Body Style | Years | Engine | Attributes |
|---|---|---|---|---|
| Rally | Extended Passenger Van | 1985 - 1993 | V6 4.3L | RWD Automatic |
| Rally | Extended Passenger Van | 1985 - 1990 | V6 4.3L | RWD Manual |
| Rally | Extended Passenger Van | 1985 - 1993 | V8 5.0L | RWD Automatic |
| Rally | Extended Passenger Van | 1985 - 1990 | V8 5.0L | RWD Manual |
| Rally | Extended Passenger Van | 1985 - 1993 | V8 5.7L | RWD Automatic |
| Rally | Extended Passenger Van | 1985 - 1990 | V8 5.7L | RWD Manual |
| Rally | Extended Passenger Van | 1985 - 1993 | V8 6.2L DIESEL | RWD Automatic |
| Rally | Extended Passenger Van | 1985 - 1990 | V8 6.2L DIESEL | RWD Manual |
| Rally STX | Extended Passenger Van | 1985 - 1993 | V6 4.3L | RWD Automatic |
| Rally STX | Extended Passenger Van | 1985 - 1990 | V6 4.3L | RWD Manual |
| Rally STX | Extended Passenger Van | 1985 - 1993 | V8 5.0L | RWD Automatic |
| Rally STX | Extended Passenger Van | 1985 - 1990 | V8 5.0L | RWD Manual |
| Rally STX | Extended Passenger Van | 1985 - 1993 | V8 5.7L | RWD Automatic |
| Rally STX | Extended Passenger Van | 1985 - 1990 | V8 5.7L | RWD Manual |
| Rally STX | Extended Passenger Van | 1985 - 1993 | V8 6.2L DIESEL | RWD Automatic |
| Rally STX | Extended Passenger Van | 1985 - 1990 | V8 6.2L DIESEL | RWD Manual |
| Vandura | Extended Cargo Van | 1985 - 1993 | V6 4.3L | RWD Automatic |
| Vandura | Extended Cargo Van | 1985 - 1990 | V6 4.3L | RWD Manual |
| Vandura | Extended Cargo Van | 1985 - 1993 | V8 5.0L | RWD Automatic |
| Vandura | Extended Cargo Van | 1985 - 1990 | V8 5.0L | RWD Manual |
| Vandura | Extended Cargo Van | 1985 - 1993 | V8 5.7L | RWD Automatic |
| Vandura | Extended Cargo Van | 1985 - 1990 | V8 5.7L | RWD Manual |
| Vandura | Extended Cargo Van | 1985 - 1993 | V8 6.2L DIESEL | RWD Automatic |
| Vandura | Extended Cargo Van | 1985 - 1990 | V8 6.2L DIESEL | RWD Manual |
| Vandura | Standard Cargo Van | 1985 - 1993 | V6 4.3L | RWD Automatic |
| Vandura | Standard Cargo Van | 1985 - 1990 | V6 4.3L | RWD Manual |
| Vandura | Standard Cargo Van | 1985 - 1993 | V8 5.0L | RWD Automatic |
| Vandura | Standard Cargo Van | 1985 - 1990 | V8 5.0L | RWD Manual |
| Vandura | Standard Cargo Van | 1985 - 1993 | V8 5.7L | RWD Automatic |
| Vandura | Standard Cargo Van | 1985 - 1990 | V8 5.7L | RWD Manual |
| Vandura | Standard Cargo Van | 1985 - 1993 | V8 6.2L DIESEL | RWD Automatic |
| Vandura | Standard Cargo Van | 1985 - 1990 | V8 6.2L DIESEL | RWD Manual |
We offer fast, reliable shipping on all orders:
This part comes with a limited lifetime warranty. Warranty begins on the original purchase date.
Warranty does NOT cover:
We want you to be 100% satisfied with your purchase. That's why we offer:
| Brand | Part Number |
|---|---|
| Cadillac | 6274216 |
| GMC | 14054932 |
| GMC | 15667752 |
Fits Years: 1985 1986 1987 1988 1989 1990 1991 1992 1993
Fits Models: G2500
