| Attribute | Value |
|---|---|
| 120.6 | |
| ABS Tone Ring Included | No |
| Attribute ID (Type) | California Proposition 65 |
| Bearings Included | No |
| Bolt Hole Quantity | 5 |
| California Proposition 65 Site [basic] | Https://www.p65warnings.ca.gov/ |
| California Proposition 65 Text [cntrc] | Warning: Cancer And Reproductive Harm |
| Center Hole Diameter | 2.783, 70.700 |
| Disc Finish | Partially Coated |
| Disc Mounting [cntrc] | Floating / Dih |
| Discard Thickness | 0.728, 18.5, 18.500 |
| Hat Finish | Coated |
| Hub Hole/Whl Reg Mm | 70.7 |
| Max PB Drum Dia [cntrc] In | 7.539 |
| Max PB Drum Dia [cntrc] Mm | 191.500 |
| Misc Holes [cntrc] | 0 |
| Mounting Bolt Hole Circle Diameter | 120.600, 4.748 |
| Mounting Type | Floating / Dih |
| Nominal Drum Diameter | 190.100, 7.484 |
| Nominal Thickness | 0.787, 20, 20.000 |
| Overall Height | 3.740, 95.000 |
| Product Grade [cntrc] | Premium |
| Solid Or Vented Type Rotor | Vented |
| Stud/Lug Hole Diameter | 0.520, 13.200 |
| Stud/Lug Hole Quantity | 5 |
| Surface Type | Smooth |
| Vane Style | Straight |
| Vane Style [cntrc] | Straight |
| Weight [cntrc] Kgs | 7.270 |
| Weight [cntrc] Lbs | 16.000 |
This part fits the following vehicles:
| SubmodelSUB- MODEL |
Body Style | Years | Engine | Attributes |
|---|---|---|---|---|
| Base | SUV | 2005 | V6 4.3L | 4WD Automatic & Manual |
| Diamond Edition | SUV | 2000 - 2001 | V6 4.3L | RWD/4WD Automatic & Manual |
| Envoy | SUV | 1999 - 2000 | V6 4.3L | AWD Automatic & Manual |
| Envoy | SUV | 1998 - 2000 | V6 4.3L | 4WD Automatic & Manual |
| Envoy | SUV | 1998 - 1999 | V6 4.3L | RWD Automatic & Manual |
| SL | SUV | 1999 | V6 4.3L | AWD Automatic & Manual |
| SL | SUV | 1999 | V6 4.3L | AWD Automatic & Manual |
| SL | SUV | 1997 - 1999 | V6 4.3L | RWD/4WD Automatic & Manual |
| SL | SUV | 1997 - 1999, 2001 | V6 4.3L | RWD/4WD Automatic & Manual |
| SLE | SUV | 1999 - 2000 | V6 4.3L | AWD Automatic & Manual |
| SLE | SUV | 1997 - 2001 | V6 4.3L | RWD/4WD Automatic & Manual |
| SLS | SUV | 1999 | V6 4.3L | AWD Automatic & Manual |
| SLS | SUV | 1997 - 2005 | V6 4.3L | 4WD Automatic |
| SLS | SUV | 1997 - 2004 | V6 4.3L | RWD Automatic |
| SLS | SUV | 1997 - 2001, 2005 | V6 4.3L | 4WD Manual |
| SLS | SUV | 1997 - 2001 | V6 4.3L | RWD Manual |
| SLS | SUV | 1997 - 1998, 2002 - 2004 | V6 4.3L | RWD/4WD Automatic |
| SLS | SUV | 1997 - 1998 | V6 4.3L | RWD/4WD Manual |
| SLT | SUV | 1999 - 2000 | V6 4.3L | AWD Automatic & Manual |
| SLT | SUV | 1997 - 2001 | V6 4.3L | RWD/4WD Automatic & Manual |
We offer fast, reliable shipping on all orders:
We want you to be 100% satisfied with your purchase. That's why we offer:
This part comes with a limited lifetime warranty. Warranty begins on the original purchase date.
Warranty does NOT cover:
| Brand | Part Number |
|---|---|
| Raybestos Brakes | 56707FZN |
Fits Years: 1997 1998 1999 2000 2001 2002 2003 2004 2005
Fits Models: Jimmy
