| Attribute | Value |
|---|---|
| Active Or Passive Suspension | Passive |
| Adjustable Compression | Yes |
| Adjustable Damping | Yes |
| Adjustable Rebound | Yes |
| Adjustable Ride Height | No |
| Air Adjustable | No |
| Air Ride Suspension | No |
| Bearing Plate Included | No |
| Bladder Heavy Duty Crimping Rings Included | No |
| Bladder Sleeve(s) Included | No |
| Bladder(s) Included | No |
| Body Color | Silver |
| Body Diameter | 2.18, 55.4 |
| Body Material | Steel |
| Boot Included | Yes |
| Coil Over Springs Included | No |
| Coil Spring Insulator(s) Included | No |
| Compressed Length | 11.76, 298.7 |
| Cylinder Color | Silver |
| Cylinder Finish | Painted |
| Cylinder Material | Steel |
| Cylinder Outside Diameter | 2.18, 55.4 |
| Damping Adjustment Type | Manual |
| Dust Shield Color | Red |
| Dust Shield Diameter | 2.99, 75.9 |
| Dust Shield Included | Yes |
| Dust Shield Material | Rubber |
| Extended Length | 17.35, 440.7 |
| Gas Charged | Yes |
| Grade Type | Performance |
| Hydraulic Lockout | No |
| Includes Bump Stop | No |
| Internal Construction Type | Tri Tube |
| Internal Rebound Bumper | Yes |
| Internal Rebound Spring | No |
| Lower Mount Code | Ls39 |
| Lower Mount Type | Loop Bushing And Sleeve Mount - 1/2" Sleeve Id X 1.5/8" Sleeve Oal |
| Maximum Ride Height Lowering Distance | 0 |
| Maximum Ride Height Raising Distance | 0 |
| Mounting Hardware Included | No |
| Parts Pack(s) | None |
| Remote Reservoir | No |
| Rod Diameter | 0.622, 15.8 |
| Self Leveling | No |
| Shaft Material | Nitrocarburized |
| Shock Absorber Body End Measuring Point | Center Of Loop |
| Shock Absorber Bore Size | 1.26, 32 |
| Shock Absorber Rod End Measuring Point | Center Of Loop |
| Shock Stroke | 142, 5.59 |
| Spring Included | No |
| Spring Isolators Included | No |
| Spring Seat Included | No |
| Strut Mount Insulator(s) Included | No |
| Travel Length | 142, 5.59 |
| Upper Mount Code | Ls39 |
| Upper Mount Type | Loop Bushing And Sleeve Mount - 1/2" Sleeve Id X 1.5/8" Sleeve Oal |
| Valving Type | Progressive |
This part fits the following vehicles:
| SubmodelSUB- MODEL |
Body Style | Years | Engine | Attributes |
|---|---|---|---|---|
| Base | SUV | 1992 - 1996, 2005 | V6 4.3L | 4WD Automatic & Manual |
| Base | SUV | 1992 - 1996 | V6 4.3L | RWD Automatic & Manual |
| Base | SUV | 1992, 1994 - 1996 | V6 4.3L | RWD/4WD Automatic & Manual |
| Diamond Edition | SUV | 2000 - 2001 | V6 4.3L | RWD/4WD Automatic & Manual |
| Envoy | SUV | 1999 - 2000 | V6 4.3L | AWD Automatic & Manual |
| Envoy | SUV | 1998 - 2000 | V6 4.3L | 4WD Automatic & Manual |
| Envoy | SUV | 1998 - 1999 | V6 4.3L | RWD Automatic & Manual |
| SL | SUV | 1999 | V6 4.3L | AWD Automatic & Manual |
| SL | SUV | 1999 | V6 4.3L | AWD Automatic & Manual |
| SL | SUV | 1996 - 1999, 2001 | V6 4.3L | RWD/4WD Automatic & Manual |
| SL | SUV | 1995 - 1999 | V6 4.3L | RWD/4WD Automatic & Manual |
| SLE | SUV | 1999 - 2000 | V6 4.3L | AWD Automatic & Manual |
| SLE | SUV | 1992 - 2001 | V6 4.3L | RWD/4WD Automatic & Manual |
| SLE | SUV | 1992 - 1994 | V6 4.3L | RWD/4WD Automatic & Manual |
| SLS | SUV | 1999 | V6 4.3L | AWD Automatic & Manual |
| SLS | SUV | 1993 - 2005 | V6 4.3L | 4WD Automatic |
| SLS | SUV | 1993 - 2004 | V6 4.3L | RWD Automatic |
| SLS | SUV | 1993 - 2001, 2005 | V6 4.3L | 4WD Manual |
| SLS | SUV | 1993 - 2001 | V6 4.3L | RWD Manual |
| SLS | SUV | 1993 - 1998, 2002 - 2004 | V6 4.3L | RWD/4WD Automatic |
| SLS | SUV | 1993 - 1998 | V6 4.3L | RWD/4WD Manual |
| SLT | SUV | 1995, 1999 - 2000 | V6 4.3L | AWD Automatic & Manual |
| SLT | SUV | 1993 - 1994 | V6 4.3L | RWD/4WD Automatic & Manual |
| SLT | SUV | 1992 - 2001 | V6 4.3L | RWD/4WD Automatic & Manual |
We offer fast, reliable shipping on all orders:
We want you to be 100% satisfied with your purchase. That's why we offer:
This part comes with a limited lifetime warranty. Warranty begins on the original purchase date.
Warranty does NOT cover:
Fits Years: 1992 1993 1994 1995 1996 1997 1998 1999 2000 2001 2002 2003 2004 2005
Fits Models: Jimmy
