Voice or type your vehicle details and Wrenchy will confirm fitment in seconds.
| Attribute | Value |
|---|---|
| Active Or Passive Suspension | Active |
| Adjustable | Oui, Sí, Yes |
| Adjustable Compression | Oui, Sí, Yes |
| Adjustable Damping | Oui, Sí, Yes |
| Adjustable Rebound | Oui, Sí, Yes |
| Adjustable Ride Height | Oui, Sí, Yes |
| Air Adjustable | No, Non |
| Bladder Heavy Duty Crimping Rings Included | No, Non |
| Bladder Sleeve(s) Included | No, Non |
| Bladder(s) Included | No, Non |
| Body Diameter | 50.2 |
| Body Length | 563.4 |
| Boot Included | Oui, Sí, Yes |
| Coil Spring Included | Oui, Sí, Yes |
| Coil Spring Insulator(s) Included | Oui, Sí, Yes |
| Compressed Length | 165 |
| Cylinder Finish | Painted, Pintado |
| Cylinder Material | Acero, Steel |
| Cylinder Outside Diameter | 50.2 |
| Damping Adjustment Type | Electronic, Electrónico |
| Dust Shield Included | No, Non |
| Extended Length | 563.4 |
| Gas Charged | Oui, Sí, Yes |
| Grade Type | Regular |
| Includes Bump Stop | Oui, Sí, Yes |
| Internal Construction Type | Single Tube, Tubo Sencillo |
| Internal Rebound Spring | No, Non |
| Lower Mount Type | Barra En T, T-bar |
| Mounting Hardware Included | No, Non |
| Progressive Spring Rate | No, Non |
| Relaxed Length | 563.4 |
| Remote Reservoir | No, Non |
| Self Leveling | Oui, Sí, Yes |
| Shaft Material | Acero, Steel |
| Spring Coil Quantity | 1, 1 Ensamble De Manguera Del Calentador |
| Spring Material | Acero, Steel |
| Spring Rate | 93.3 N/mm |
| Strut Mount Insulator(s) Included | Oui, Sí, Yes |
| Strut Mount(s) Included | Oui, Sí, Yes |
| Suspension Type | Resorte, Spring |
| Travel Length | 128 |
| Upper Mount Type | Bolt, Perno |
| Valving Type | Progressive |
This part fits the following vehicles:
| SubmodelSUB- MODEL |
Body Style | Years | Engine | Attributes |
|---|---|---|---|---|
| All Terrain | Crew Cab Pickup | 2016 - 2018 | V8 5.3L FLEX | 4WD Automatic |
| All Terrain | Crew Cab Pickup | 2015 | V8 5.3L FLEX | AWD Automatic |
| All Terrain | Standard Cab Pickup | 2015 | V8 5.3L FLEX | AWD Automatic |
| Denali | Crew Cab Pickup | 2017 - 2018 | V8 6.2L | 4WD Automatic |
| Denali | Crew Cab Pickup | 2015 - 2016 | V8 6.2L | AWD Automatic |
| Denali | Crew Cab Pickup | 2015 - 2016 | V8 6.2L FLEX | AWD Automatic |
| SLE | Crew Cab Pickup | 2016 | V8 5.3L FLEX | AWD Automatic |
| SLE | Crew Cab Pickup | 2015 - 2016 | V8 5.3L | AWD Automatic |
| SLE | Standard Cab Pickup | 2017 - 2018 | V8 5.3L FLEX | 4WD Automatic |
| SLE | Standard Cab Pickup | 2016 | V8 5.3L FLEX | AWD Automatic |
| SLE | Standard Cab Pickup | 2015 - 2016 | V8 5.3L | AWD Automatic |
| SLT | Crew Cab Pickup | 2015 | V8 5.3L FLEX | 4WD Automatic |
We offer fast, reliable shipping on all orders:
This part comes with a limited lifetime warranty. Warranty begins on the original purchase date.
Warranty does NOT cover:
We want you to be 100% satisfied with your purchase. That's why we offer:
| Brand | Part Number |
|---|---|
| General Motors | 11547419 |
| General Motors | 11548570 |
| General Motors | 19332631 |
| General Motors | 23312166 |
| General Motors | 84061243 |
| General Motors | 84157475 |
| General Motors | 84176631 |
| General Motors | 84176638 |
Fits Years: 2015 2016 2017 2018
Fits Models: Sierra
