| Attribute | Value |
|---|---|
| Anti Lock Braking System | Yes |
| Anti Lock Braking System Type | Encoder |
| Bearing Generation | Gen 3 |
| Bearing Type | Ball |
| Bolt Circle Diameter | 120, 4.724 |
| Brake Pilot Diameter | 2.756, 70 |
| Drive Type | Driven |
| Flange Bolt Hole Quantity | 4 |
| Flange Diameter | 152, 5.98 |
| Flange Included | Yes |
| Flange Offset | 1.858, 47.2 |
| Flange Quantity | 2 |
| Flange Shape | Modified Rectangular |
| Knuckle Bolt Circle Diameter | 125, 4.921 |
| Knuckle Bolt Hole Size | 0.47 |
| Knuckle Bolt Thread Pitch | 1.25 |
| Knuckle Pilot Hole Diameter | 3.496, 88.8 |
| Spline Quantity | 30 |
| Wheel Pilot Diameter | 2.52, 64 |
| Wheel Stud Quantity | 5 |
| Wheel Stud Size | 0.55, 14 |
| Wheel Stud Thread Pitch | 1.5 |
This part fits the following vehicles:
| SubmodelSUB- MODEL |
Body Style | Years | Engine | Attributes |
|---|---|---|---|---|
| EX | SUV | 2009 - 2015 | V6 3.5L | AWD/FWD Automatic |
| EX-L | SUV | 2009 - 2015 | V6 3.5L | AWD/FWD Automatic |
| LX | SUV | 2009 - 2015 | V6 3.5L | AWD/FWD Automatic |
| SE | SUV | 2015 | V6 3.5L | AWD/FWD Automatic |
| Touring | SUV | 2009 - 2015 | V6 3.5L | AWD/FWD Automatic |
We offer fast, reliable shipping on all orders:
We want you to be 100% satisfied with your purchase. That's why we offer:
This part comes with a limited lifetime warranty. Warranty begins on the original purchase date.
Warranty does NOT cover:
| Brand | Part Number |
|---|---|
| Acura | 44300STXA01 |
| Alltech Automotive | 513267 |
| Autopart International | 1411247702 |
| Beck/Arnley | 051-6408 |
| Beck/Arnley | 0516408 |
| Centric Parts | 400.40003 |
| Centric Parts | 400.40003E |
| Centric Parts | 40040003 |
| GMB | 7350017 |
| Mevotech | H513267 |
| Raybestos Brakes | 713267 |
| Schaeffler | 102221 |
| Schaeffler | FW9267 |
| SKF | BR930720 |
| Timken | HA590228 |
| WJB | WA513267 |
Fits Years: 2009 2010 2011 2012 2013 2014 2015
Fits Models: Pilot
