Voice or type your vehicle details and Wrenchy will confirm fitment in seconds.
| Attribute | Value |
|---|---|
| Active Or Passive Suspension | Passive |
| Adjustable Compression | No |
| Adjustable Damping | No |
| Adjustable Rebound | No |
| Adjustable Ride Height | No |
| Air Adjustable | No |
| Air Ride Suspension | No |
| Bearing Plate Included | No |
| Bladder Heavy Duty Crimping Rings Included | No |
| Bladder Sleeve(s) Included | No |
| Bladder(s) Included | No |
| Body Color | White |
| Body Diameter | 2.25, 57.2 |
| Body Material | Steel |
| Boot Included | Yes |
| Coil Over Springs Included | No |
| Coil Spring Insulator(s) Included | No |
| Compressed Length | 13.04, 331.2 |
| Cylinder Color | White |
| Cylinder Finish | Painted |
| Cylinder Material | Steel |
| Cylinder Outside Diameter | 2.25, 57.2 |
| Dust Shield Color | Red |
| Dust Shield Diameter | 2.99, 75.9 |
| Dust Shield Included | Yes |
| Dust Shield Material | Plastic |
| Extended Length | 15.39, 390.9 |
| Gas Charged | Yes |
| Grade Type | Performance |
| Hydraulic Lockout | No |
| Includes Bump Stop | No |
| Internal Construction Type | Twin Tube |
| Internal Rebound Bumper | No |
| Internal Rebound Spring | No |
| Lower Mount Code | Ls42 |
| Lower Mount Type | Loop Bushing And Sleeve Mount - 14mm Sleeve Id X 1.5/16" Sleeve Oal |
| Maximum Ride Height Lowering Distance | 0 |
| Maximum Ride Height Raising Distance | 0 |
| Mounting Hardware Included | Yes |
| Parts Pack(s) | P01167 |
| Remote Reservoir | No |
| Rod Diameter | 0.622, 15.8 |
| Self Leveling | No |
| Shaft Material | Nitrocarburized |
| Shock Absorber Body End Measuring Point | Base Of Stem |
| Shock Absorber Bore Size | 1.3779527559055118, 35 |
| Shock Absorber Rod End Measuring Point | Center Of Loop |
| Shock Stroke | 2.35, 59.7 |
| Spring Included | No |
| Spring Isolators Included | No |
| Spring Seat Included | No |
| Strut Mount Insulator(s) Included | No |
| Travel Length | 2.35, 59.7 |
| Upper Mount Code | S5 |
| Upper Mount Type | Stem Mount - 2.5/8" Stem Length X 1/2"-13 Thread Pitch |
| Valving Type | Progressive |
This part fits the following vehicles:
| SubmodelSUB- MODEL |
Body Style | Years | Engine | Attributes |
|---|---|---|---|---|
| Adventure | Crew Cab Pickup | 2009 | V8 6.2L FLEX | AWD Automatic |
| Adventure | Crew Cab Pickup | 2008 | V8 6.2L | AWD Automatic |
| Adventure | Crew Cab Pickup | 2005 - 2006 | V8 6.0L | AWD Automatic |
| Adventure | SUV | 2008 | V8 6.2L | AWD Automatic |
| Adventure | SUV | 2005, 2007 | V8 6.0L | AWD Automatic |
| Base | Crew Cab Pickup | 2009 | V8 6.2L FLEX | 4WD Automatic |
| Base | Crew Cab Pickup | 2008 | V8 6.2L | 4WD Automatic |
| Base | Crew Cab Pickup | 2005 - 2007 | V8 6.0L | 4WD Automatic |
| Base | SUV | 2009 | V8 6.2L FLEX | 4WD Automatic |
| Base | SUV | 2008 | V8 6.2L | 4WD Automatic |
| Base | SUV | 2003 - 2007 | V8 6.0L | 4WD Automatic |
| Luxury | SUV | 2009 | V8 6.2L FLEX | AWD Automatic |
| Luxury | SUV | 2008 | V8 6.2L | AWD Automatic |
| Luxury | SUV | 2005 - 2007 | V8 6.0L | AWD Automatic |
| Special Edition | SUV | 2007 | V8 6.0L | AWD Automatic |
We offer fast, reliable shipping on all orders:
This part comes with a limited lifetime warranty. Warranty begins on the original purchase date.
Warranty does NOT cover:
We want you to be 100% satisfied with your purchase. That's why we offer:
| Brand | Part Number |
|---|---|
| ACDelco | 520135 |
| ACDelco | 530311 |
| ACDelco | 540326 |
| ACDelco | 560272 |
| ACDelco | 560614 |
| AL-KO Xtreme | 813001 |
| Chevrolet | 19208003 |
| FCS | 341598 |
| Gabriel | G63817 |
| General Motors | 19152876 |
| General Motors | 19168457 |
| General Motors | 19177927 |
| General Motors | 19211023 |
| General Motors | 20951274 |
| General Motors | 20951275 |
| General Motors | 88945479 |
| General Motors | 88966866 |
| Gold Shock Absorber | 565102 |
| Gold Shock Absorber | 9160312 |
| KYB | 344383 |
| KYB | KG54340 |
| Monroe Shocks & Struts | 34504 |
| Monroe Shocks & Struts | 37181 |
| Monroe Shocks & Struts | 911181 |
| Monroe Shocks & Struts | 911507 |
| Rancho | RS5288 |
| Sensen | 12140199 |
| Skyjacker | N8019 |
Fits Years: 2003 2004 2005 2006 2007 2008 2009
Fits Models: H2
