| Attribute | Value |
|---|---|
| ABS Tone Ring Included | No |
| Center Hole Diameter | 117.6, 4.63 |
| Conventional Or Drum In Hat Type Rotor | Drum-in-hat |
| Directional Or Non Directional Brake Surface | Non-directional |
| Discard Thickness | 1.043, 26.5 |
| Harmonize Code | 8708.30.5030 |
| Material | Cast Iron |
| Mounting Bolt Hole Circle Diameter | 165.1, 6.5 |
| Mounting Bolt Hole Diameter | 0.625, 15.9 |
| Nominal Thickness | 1.142, 29 |
| Overall Height | 3.42, 86.85 |
| Salability Restrictions | No |
| Solid Or Vented Type Rotor | Vented |
| UNSPSC Code | 25171715 |
This part fits the following vehicles:
| SubmodelSUB- MODEL |
Body Style | Years | Engine | Attributes |
|---|---|---|---|---|
| Adventure | Crew Cab Pickup | 2009 | V8 6.2L FLEX | AWD Automatic |
| Adventure | Crew Cab Pickup | 2008 | V8 6.2L | AWD Automatic |
| Adventure | Crew Cab Pickup | 2005 - 2006 | V8 6.0L | AWD Automatic |
| Adventure | SUV | 2008 | V8 6.2L | AWD Automatic |
| Adventure | SUV | 2005, 2007 | V8 6.0L | AWD Automatic |
| Base | Crew Cab Pickup | 2009 | V8 6.2L FLEX | 4WD Automatic |
| Base | Crew Cab Pickup | 2008 | V8 6.2L | 4WD Automatic |
| Base | Crew Cab Pickup | 2005 - 2007 | V8 6.0L | 4WD Automatic |
| Base | SUV | 2009 | V8 6.2L FLEX | 4WD Automatic |
| Base | SUV | 2008 | V8 6.2L | 4WD Automatic |
| Base | SUV | 2003 - 2007 | V8 6.0L | 4WD Automatic |
| Luxury | SUV | 2009 | V8 6.2L FLEX | AWD Automatic |
| Luxury | SUV | 2008 | V8 6.2L | AWD Automatic |
| Luxury | SUV | 2005 - 2007 | V8 6.0L | AWD Automatic |
| Special Edition | SUV | 2007 | V8 6.0L | AWD Automatic |
We offer fast, reliable shipping on all orders:
This part comes with a limited lifetime warranty. Warranty begins on the original purchase date.
Warranty does NOT cover:
We want you to be 100% satisfied with your purchase. That's why we offer:
| Brand | Part Number |
|---|---|
| ACDelco | 177-860 |
| Advance Auto Parts | YH145262 |
| Advance Auto Parts | YH145262C |
| Advance Auto Parts | YH145262P |
| American Remanufactured | 89-44043 |
| Autopartsource | 493095 |
| Autopartsource | 593095 |
| Autospecialty | AR8643 |
| Autospecialty | AR8643E |
| Autoxtra | 8056830 |
| Autoxtra | AX55057 |
| AutoZone | 55057DG |
| AutoZone | 55057DL |
| AutoZone | DL55057 |
| Bendix | 145262 |
| Bendix | E12671048 |
| BrakeBest | 56830 |
| BrakeBest | 56830FZN |
| BrakeBest | 56830PER |
| BrakeBest | 56830R |
| BrakeBest | 56830RGS |
| BrakeBest | 81-125656 |
| Brembo | 09.8812.80 |
| Brembo | 27049 |
| Brembo | 27306 |
| California Drum & Rotor | 125656 |
| Casting Numbers | 211253-C |
| Casting Numbers | 325505 |
| Centric Parts | 120.66043 |
| Centric Parts | 120.66043CRY |
| Centric Parts | 121.66043 |
| Centric Parts | 125.66043 |
| Centric Parts | 125.66043CRY |
| Centric Parts | 126.66043CSL |
| Centric Parts | 126.66043CSR |
| Centric Parts | 126.66043SL |
| Centric Parts | 126.66043SR |
| Centric Parts | 127.66043CR |
| Centric Parts | 127.66043L |
| Centric Parts | 127.66043R |
| Centric Parts | 128.66043CL |
| Centric Parts | 128.66043CR |
| Centric Parts | 128.66043L |
| Centric Parts | 128.66043R |
| Centric Parts | 227.66043L |
| Centric Parts | 227.66043R |
| Centric Parts | 320.66043 |
| Dura Corp | BR55057 |
| Dura Corp | BR5505702 |
| Dura Corp | BR90166 |
| DuraGo | 900562 |
| DuraGo | BR900562 |
| DuraGo | BR90056202 |
| Dynamic Friction Company | 604-48039 |
| Guardian | 52-125656 |
| Hummer | 15712801 |
| Mighty Distributing System | 55057 |
| Omnicraft | QBRR166 |
| Omnicraft | QBRR196 |
| Pep Boys | 55057G |
| PowerStop | AR8643EVC |
| Promax | 14-55057 |
| Promax | 20-55057 |
| Qualis | 41243 |
| Quality Brand | Q4041 |
| UAP | 2055057 |
| Ultra Brake | 55410 |
| Universal | 101005 |
| VIPAR - Vehicle Indusrty Parts & Manufacturing | X51358 |
| WABCO - Archived | PS125656 |
| Wagner Brake | BD125656 |
| Wagner Brake | BD125656E |
| Winhere | 662574 |
| Winhere | YH2574 |
Fits Years: 2003 2004 2005 2006 2007 2008 2009
Fits Models: H2
