| Attribute | Value |
|---|---|
| Active Or Passive Suspension | Passive |
| Adjustable Compression | Yes |
| Adjustable Damping | Yes |
| Adjustable Rebound | Yes |
| Adjustable Ride Height | No |
| Air Adjustable | No |
| Air Ride Suspension | No |
| Bearing Plate Included | No |
| Bladder Heavy Duty Crimping Rings Included | No |
| Bladder Sleeve(s) Included | No |
| Bladder(s) Included | No |
| Body Color | Silver |
| Body Diameter | 2.18, 55.4 |
| Body Material | Steel |
| Boot Included | Yes |
| Coil Over Springs Included | No |
| Coil Spring Insulator(s) Included | No |
| Compressed Length | 13.22, 335.8 |
| Cylinder Color | Silver |
| Cylinder Finish | Painted |
| Cylinder Material | Steel |
| Cylinder Outside Diameter | 2.18, 55.4 |
| Damping Adjustment Type | Manual |
| Dust Shield Color | Red |
| Dust Shield Diameter | 2.99, 75.9 |
| Dust Shield Included | Yes |
| Dust Shield Material | Plastic |
| Extended Length | 15.28, 388.1 |
| Gas Charged | Yes |
| Grade Type | Performance |
| Hydraulic Lockout | No |
| Includes Bump Stop | Yes |
| Internal Construction Type | Tri Tube |
| Internal Rebound Bumper | Yes |
| Internal Rebound Spring | No |
| Lower Mount Code | Clev |
| Lower Mount Type | Clevis Bracket Mount |
| Maximum Ride Height Lowering Distance | 0 |
| Maximum Ride Height Raising Distance | 0 |
| Mounting Hardware Included | Yes |
| Parts Pack(s) | P01356 |
| Remote Reservoir | No |
| Rod Diameter | 0.622, 15.8 |
| Self Leveling | No |
| Shaft Material | Nitrocarburized |
| Shock Absorber Body End Measuring Point | Base Of Stem |
| Shock Absorber Bore Size | 1.26, 32 |
| Shock Absorber Rod End Measuring Point | Center Of Mounting Hole |
| Shock Stroke | 2.06, 52.3 |
| Spring Included | No |
| Spring Isolators Included | No |
| Spring Seat Included | No |
| Strut Mount Insulator(s) Included | No |
| Travel Length | 2.06, 52.3 |
| Upper Mount Code | S51 |
| Upper Mount Type | Stem Mount - 2 5/8" Stem Length X 1/2"-13 Thread Pitch |
| Valving Type | Progressive |
This part fits the following vehicles:
| SubmodelSUB- MODEL |
Body Style | Years | Engine | Attributes |
|---|---|---|---|---|
| Adventure | Crew Cab Pickup | 2010 | L5 3.7L | 4WD Automatic & Manual |
| Alpha | Crew Cab Pickup | 2010 | V8 5.3L FLEX | 4WD Automatic |
| Alpha | Crew Cab Pickup | 2009 - 2010 | V8 5.3L | 4WD Automatic |
| Base | Crew Cab Pickup | 2009 - 2010 | L5 3.7L | 4WD Automatic & Manual |
We offer fast, reliable shipping on all orders:
We want you to be 100% satisfied with your purchase. That's why we offer:
This part comes with a limited lifetime warranty. Warranty begins on the original purchase date.
Warranty does NOT cover:
Fits Years: 2009 2010
Fits Models: H3T
