| Attribute | Value |
|---|---|
| Contains Electronic Components | No |
| Does It Require SDS | No |
| FAA A1 | Hoses Should Be Replaced If They Appear Brittle Or If There Are Any Kinks Or Leaks. |
| FAA A2 | The Difference Is The Orientation Of The Teeth On The Pitman Shaft And Power Piston. Variable Teeth Will Have A Faster Ratio Than Non-variable Teeth. |
| FAA A3 | In A Standard Rotation Gear Box, The Input And Pitman Shaft Rotate In The Same Direction. The Shafts Turn In Opposite Directions On A Reverse Rotation Gear Box. |
| FAA A4 | Not Recommended. The Preload Is Adjusted At The Time Of Assembly. If Excessive Play Is Present, It’s Due To Wear Of Internal Components. If Adjustment Is Attempted, It Could Lead To Binding. |
| FAQ Q1 | Should The Power Steering Hoses Be Replaced? |
| FAQ Q2 | What Is The Difference Between A Fast Ratio And A Slow Ratio Gear Box? |
| FAQ Q3 | How Can I Tell If My Gear Box Is A Standard Or Reverse Rotation? |
| FAQ Q4 | Can I Adjust My Original Gear Box If It Has A Lot Of Play? |
| Input Shaft Diameter | 0.755, 19.177 |
| Is Item A Chemical | No |
| Is Or Contains A Battery | No |
| Is Or Contains A Bulb | No |
| Is Prop Sixty Five Affected | No |
| Is The Item CARB Affected | No |
| Mounting Hardware Included | No |
| Output Shaft Diameter | 1.13, 28.58 |
| Output Shaft Spline Quantity | 32 |
| Output Shaft Thread Diameter | 0.864, 21.95 |
| Power Assisted | No |
| Product Condition | Remanufactured |
| Splined Input Shaft | Yes |
| Total Turns Lock To Lock | 6.5 |
| Type | Manual |
This part fits the following vehicles:
| SubmodelSUB- MODEL |
Body Style | Years | Engine | Attributes |
|---|---|---|---|---|
| Base | SUV | 1980 - 1981 | L4 2.5L | 4WD Automatic & Manual |
| Base | SUV | 1980 - 1981 | L6 4.6L | 4WD Manual |
| Base | SUV | 1976 - 1978 | L6 3.8L | 4WD Automatic & Manual |
| Base | SUV | 1976 - 1981 | L6 4.2L | 4WD Automatic & Manual |
| Base | SUV | 1976 - 1981 | V8 5.0L | 4WD Automatic & Manual |
| Golden Eagle | SUV | 1977 - 1978 | L6 3.8L | 4WD Automatic & Manual |
| Golden Eagle | SUV | 1977 - 1979 | L6 4.2L | 4WD Automatic & Manual |
| Golden Eagle | SUV | 1977 - 1979 | V8 5.0L | 4WD Automatic & Manual |
| Golden Hawk | SUV | 1980 | L4 2.5L | 4WD Automatic & Manual |
| Golden Hawk | SUV | 1980 | L6 4.2L | 4WD Automatic & Manual |
| Golden Hawk | SUV | 1980 | V8 5.0L | 4WD Automatic & Manual |
| Laredo | SUV | 1980 - 1981 | L4 2.5L | 4WD Automatic & Manual |
| Laredo | SUV | 1980 - 1981 | L6 4.2L | 4WD Automatic & Manual |
| Laredo | SUV | 1980 - 1981 | V8 5.0L | 4WD Automatic & Manual |
| Renegade | SUV | 1980 - 1981 | L4 2.5L | 4WD Automatic & Manual |
| Renegade | SUV | 1976 - 1978 | L6 3.8L | 4WD Automatic & Manual |
| Renegade | SUV | 1976 - 1981 | L6 4.2L | 4WD Automatic & Manual |
| Renegade | SUV | 1976 - 1981 | V8 5.0L | 4WD Automatic & Manual |
We offer fast, reliable shipping on all orders:
We want you to be 100% satisfied with your purchase. That's why we offer:
This part comes with a limited lifetime warranty. Warranty begins on the original purchase date.
Warranty does NOT cover:
Fits Years: 1976 1977 1978 1979 1980 1981
Fits Models: CJ7
