| Attribute | Value |
|---|---|
| Belt Type | Serpentine |
| Clutch Included | Included |
| Coil Clock | 1 Wire Lead |
| Discharge Port Type | O-ring |
| ECV Harness Connector | Compressor Se10f, Vehicle Se10m |
| Electronic Control Valve | Yes |
| Groove | 7 |
| Model | Tsb19c |
| Mount Distance IN | 1.61 |
| Mount Distance MM | 40.89 |
| Mounting Hardware? | Not Included |
| New Or Reman | New |
| O Ring A Number/Desc | 24681 / Green O-ring |
| O Ring A Quantity | 1 |
| O Ring B Number/Desc | 24661 / Green O-ring |
| O Ring B Quantity | 1 |
| Oil Type | Pag 46 |
| Pulley Diameter IN | 4.53 |
| Pulley Diameter MM | 115.06 |
| Refrigerant Type | R134a |
| Suction Port Type | O-ring |
| Switch / Sensor Desc | Control Valve |
| Switch Type | N/a |
| Type | Denso |
This part fits the following vehicles:
| SubmodelSUB- MODEL |
Body Style | Years | Engine | Attributes |
|---|---|---|---|---|
| Base | Sedan | 2013 - 2018 | V6 3.5L | FWD Automatic |
We offer fast, reliable shipping on all orders:
We want you to be 100% satisfied with your purchase. That's why we offer:
This part comes with a limited lifetime warranty. Warranty begins on the original purchase date.
Warranty does NOT cover:
| Brand | Part Number |
|---|---|
| Gilmore Products | AC1208014 |
| Gilmore Products | AC1208546 |
| Nippendenso | 4711031 |
| Nippendenso | 4711045 |
| Omega | 2022267 |
| Reach Cooling | 7421885 |
| Toyota | 883200E090 |
Fits Years: 2013 2014 2015 2016 2017 2018
Fits Models: ES350
