| Attribute | Value |
|---|---|
| Bearing Cap Diameter (1) | 1.062 |
| Bearing Cap Diameter (2) | 1.062 |
| Bearing Cap Diameter A (mm) | 26.975 |
| Bearing Cap Diameter B (mm) | 26.975 |
| Bearing Cap Finish | Ground |
| Bearing Cap Type | Round |
| Bearing Cap Type A | Osr |
| Bearing Cap Type B | Osr |
| Coating Type | None |
| Grease Fitting Location | One Straight Lube Fitting In Cross |
| Grease Type | N.l.g.i. Grade 2 |
| Grease Zerk Included | Y |
| Greaseable | Y |
| Length A (In) | 3.625 |
| Length A (mm) | 92.1 |
| Length B (In) | 3.625 |
| Length B (mm) | 92.1 |
| Material | Steel |
| Model Number | Spicer 1330 |
| Mounting Hardware Included | N |
| OEM Mfg | Spicer |
| OEM Series | 1330 |
| Pre Greased | N |
| Prop 65 | No |
| SR(1)Brng Cap To Brng Cap(OSR) | 3.625 |
| SR(2)Brng Cap To Brng Cap(OSR) | 3.625 |
| Seal Color/Finish | Blue |
| Seal Material | Rubber |
| Snap Ring Included | Y |
| Snap Ring Type | External |
| Type | Osr Style |
This part fits the following vehicles:
| SubmodelSUB- MODEL |
Body Style | Years | Engine | Attributes |
|---|---|---|---|---|
| Base | SUV | 2003 - 2005 | V8 4.6L | AWD/RWD Automatic |
| Luxury | SUV | 2004 - 2005 | V8 4.6L | RWD Automatic |
| Premier | SUV | 2005 | V8 4.6L | AWD/RWD Automatic |
| Ultimate | SUV | 2004 | V8 4.6L | AWD Automatic |
We offer fast, reliable shipping on all orders:
We want you to be 100% satisfied with your purchase. That's why we offer:
This part comes with a limited lifetime warranty. Warranty begins on the original purchase date.
Warranty does NOT cover:
| Brand | Part Number |
|---|---|
| ACDelco | 45U0106 |
| ACDelco | 45U0115 |
| ACDelco | 45U0141 |
| AM General | 05595706 |
| AM General | 05595706B |
| AM General | 5595706 |
| AM General | 5595706-B |
| Chrysler | 4746936 |
| Chrysler | 5014 062AA |
| Chrysler | 5014 733AA |
| Chrysler | 5014 733AB |
| Chrysler | 5014062AA |
| Chrysler | 5014733AA |
| Chrysler | 5014733AB |
| Chrysler | 5175 392AA |
| Chrysler | 5175392AA |
| Chrysler | 5175392AB |
| Chrysler | 6804 8401AB |
| Chrysler | 68048401AA |
| Chrysler | 68048401AB |
| Chrysler | P3690773 |
| Daimler Truck North America | SP 5 213X |
| Daimler Truck North America | SP 5 213XHP |
| Dana Commercial Vehicle Service Parts | 2104-5213X |
| Dana Commercial Vehicle Service Parts | 5-213XSB |
| Dana Commercial Vehicle Service Parts | 5-273X |
| Dana Commercial Vehicle Service Parts | DT213 |
| General Motors | 12472407 |
| General Motors | 12473124 |
| General Motors | 12476135 |
| General Motors | 12543573 |
| General Motors | 15580369 |
| General Motors | 8-89040-243-0 |
| General Motors | 8124761350 |
| General Motors | 8890402430 |
| General Motors | 88940038 |
| General Motors | 88940243 |
| General Motors | 88955261 |
| General Motors | 89022621 |
| General Motors | 89022696 |
| General Motors | 89040243 |
| International Harvester IHC | 5213X |
| International Harvester IHC | D5213X |
| International Harvester IHC | D5273X |
| International Harvester IHC | E5213X |
| International Harvester IHC | ZJU5213X |
| John Deere | AT194838 |
| Mazda | ZZN0-25-060 |
| Mazda | ZZN0-25-060A |
| Mazda | ZZN025060 |
| Mazda | ZZN025060A |
| Mazda | ZZP0-25-060 |
| Mazda | ZZP0-25-060A |
| Mazda | ZZP025060 |
| Mazda | ZZP025060A |
| McNeilus | 2GN267 |
| Meritor | CP213X |
| Midwest | 5-213XR |
| MOOG Chassis Products | RL1330 |
| MOOG Chassis Products | RL5552 |
| Navistar | 5273X |
| Navistar | DS5213X |
| Navistar | E5273X |
| Navistar | E5479X |
| Neapco OE Series | 2-1203 |
| Nissan | 37125-EB71A |
| Nissan | 37125EB71A |
| Nissan | 37126-EA025 |
| Nissan | 37126-EA026 |
| Nissan | 37126-EA027 |
| Nissan | 37126-EA028 |
| Nissan | 37126EA025 |
| Nissan | 37126EA026 |
| Nissan | 37126EA027 |
| Nissan | 37126EA028 |
| Paccar Parts | 5-213X |
| Precision | 254 |
| Precision | 270 |
| Precision | 354 |
| Rockwell International | CP 213X |
| SKF | 2-0790 |
| SKF | 2-4800 |
| SKF | 2-4800G |
| SKF | 2-4801 |
| SKF | UJ254 |
| SKF | UJ270 |
| SKF | UJ354 |
| Suzuki | 27200-82Z10 |
| Suzuki | 27200-82Z20 |
| Suzuki | 2720082Z10 |
| Suzuki | 2720082Z20 |
| SVL | 15-213X |
| Toyota | 04362-60200 |
| Toyota | 0436260200 |
| Toyota | 04371-04030 |
| Toyota | 04371-04090 |
| Toyota | 04371-0K070 |
| Toyota | 04371-0K080 |
| Toyota | 0437104030 |
| Toyota | 0437104090 |
| Toyota | 043710K070 |
| Toyota | 043710K080 |
| Toyota | 04375-0C020 |
| Toyota | 04375-0C030 |
| Toyota | 04375-0C040 |
| Toyota | 04375-0C041 |
| Toyota | 043750C020 |
| Toyota | 043750C030 |
| Toyota | 043750C040 |
| Toyota | 043750C041 |
| Volvo | 30090-5011 |
| Volvo | 85129128 |
| Volvo | SHP5213X |
| Volvo | SP 5213X |
Fits Years: 2003 2004 2005
Fits Models: Aviator
