| Attribute | Value |
|---|---|
| ABS Tone Ring Included | No |
| Center Hole Diameter | 3.228, 82 |
| Conventional Or Drum In Hat Type Rotor | Conventional |
| Discard Thickness | 1.043, 26.5 |
| Harmonize Code | 8708.30.5030 |
| Mounting Bolt Hole Circle Diameter | 114.3, 4.5 |
| Mounting Bolt Hole Diameter | 114.3, 4.5 |
| Mounting Bolt Hole Quantity | 5 |
| Nominal Thickness | 1.102, 28 |
| Overall Height | 2.29, 58.15 |
| Salability Restrictions | No |
| Solid Or Vented Type Rotor | Vented |
| Stud/Lug Hole Quantity | 5 |
| UNSPSC Code | 25171715 |
This part fits the following vehicles:
| SubmodelSUB- MODEL |
Body Style | Years | Engine | Attributes |
|---|---|---|---|---|
| Base | SUV | 2003 - 2005 | V8 4.6L | AWD/RWD Automatic |
| Luxury | SUV | 2004 - 2005 | V8 4.6L | RWD Automatic |
| Premier | SUV | 2005 | V8 4.6L | AWD/RWD Automatic |
| Ultimate | SUV | 2004 | V8 4.6L | AWD Automatic |
We offer fast, reliable shipping on all orders:
We want you to be 100% satisfied with your purchase. That's why we offer:
This part comes with a limited lifetime warranty. Warranty begins on the original purchase date.
Warranty does NOT cover:
| Brand | Part Number |
|---|---|
| Advance Auto Parts | YH145444 |
| Autopartsource | 492495 |
| Bendix | 145444 |
| Bosch | 20010418 |
| BrakeBest | 680166 |
| BrakeBest | 680166R |
| BrakeBest | 680166RGS |
| Brembo | 27358 |
| Casting Numbers | 211566-C |
| Casting Numbers | 325999 |
| Centric Parts | 120.65093 |
| Centric Parts | 121.65093 |
| Centric Parts | 126.65093CSL |
| Centric Parts | 126.65093CSR |
| Centric Parts | 126.65093SL |
| Centric Parts | 126.65093SR |
| Centric Parts | 127.65093CL |
| Centric Parts | 127.65093CR |
| Centric Parts | 127.65093L |
| Centric Parts | 127.65093R |
| Centric Parts | 128.65093L |
| Centric Parts | 128.65093R |
| Centric Parts | 320.65093 |
| Dura Corp | BR54115 |
| Mighty Distributing System | 54115 |
| Motorcraft | BRR127 |
| Motorcraft | BRRF269 |
| Parts Master | 126039 |
| PowerStop | AR8592EVC |
| Promax | 14-54115 |
| VIPAR - Vehicle Indusrty Parts & Manufacturing | X51651 |
| Wagner Brake | BD126039 |
| Winhere | 6620223 |
Fits Years: 2003 2004 2005
Fits Models: Aviator
