| Attribute | Value |
|---|---|
| Bolt Quantity | 4 |
| Bolt Thread | M6 X 1.0 Hole |
| Clutch Type | D - Severe Duty & Truck Fan Drive |
| Color | Raw Aluminum In Color |
| Description | Fan Clutches |
| Dia. IN | 6.45 |
| Duty Rating | Severe |
| Electronic Clutch? | Non Electronic |
| Fan Bolt Circle IN | 3.25 |
| Fan Bolt Circle MM | 82.6 |
| Material | Aluminum |
| Meets / Exceeds OEM? | Yes |
| Mount Dia. IN | 1.44 |
| Mount Hole Qty | 4 |
| Mounting Hardware? | Not Included |
| New Or Reman | New |
| Overall Dia. IN | 6.45 |
| Overall Dia. MM | 163.8 |
| Overall Height IN | 3.27 |
| Overall Height MM | 82.9 |
| Performance Rated? | Yes |
| Pilot Depth IN | 0.7 |
| Pilot Depth MM | 17.8 |
| Pilot Dia. IN | 1.18 |
| Pilot Dia. MM | 30 |
| Rotation | Rev |
| Type | Thermal |
This part fits the following vehicles:
| SubmodelSUB- MODEL |
Body Style | Years | Engine | Attributes |
|---|---|---|---|---|
| Base | SUV | 2003 - 2005 | V8 4.6L | AWD/RWD Automatic |
| Luxury | SUV | 2004 - 2005 | V8 4.6L | RWD Automatic |
| Premier | SUV | 2005 | V8 4.6L | AWD/RWD Automatic |
| Ultimate | SUV | 2004 | V8 4.6L | AWD Automatic |
We offer fast, reliable shipping on all orders:
We want you to be 100% satisfied with your purchase. That's why we offer:
This part comes with a limited lifetime warranty. Warranty begins on the original purchase date.
Warranty does NOT cover:
| Brand | Part Number |
|---|---|
| Everco Heavy Duty | 971358 |
| Gilmore Products | 36720 |
| Visteon | 140158 |
Fits Years: 2003 2004 2005
Fits Models: Aviator
