| Attribute | Value |
|---|---|
| Bypass Flange Diameter | 1.38 |
| Bypass Flange Length | 1.58 |
| Flange Height | .7 |
| Flange Thickness | .05 |
| Gasket Quantity | 0 |
| Grade Type | Oe Performance |
| Height Between Flanges | 1.6 |
| Installation Tool Included | No |
| Jiggle Pin Check Valve Quantity | 1 |
| Jiggle Pin Weep Hole | Yes |
| Material | Stainless Steel, Copper |
| Seal Quantity | 0 |
| Sealing Flange Outside Diameter | 2.13 |
| Start To Open Temperature | 180, 82 |
| Type | Oe Type Thermostat |
This part fits the following vehicles:
| SubmodelSUB- MODEL |
Body Style | Years | Engine | Attributes |
|---|---|---|---|---|
| Base | SUV | 2003 - 2005 | V8 4.6L | AWD/RWD Automatic |
| Luxury | SUV | 2004 - 2005 | V8 4.6L | RWD Automatic |
| Premier | SUV | 2005 | V8 4.6L | AWD/RWD Automatic |
| Ultimate | SUV | 2004 | V8 4.6L | AWD Automatic |
We offer fast, reliable shipping on all orders:
We want you to be 100% satisfied with your purchase. That's why we offer:
This part comes with a limited lifetime warranty. Warranty begins on the original purchase date.
Warranty does NOT cover:
| Brand | Part Number |
|---|---|
| Carquest | 32918 |
| Carquest Premium Caps and Stats | 14138 |
| CST | 4138 |
| CST | 7354-180 |
| Mazda | CA0115170A |
| Mazda | CA1915171 |
| Mazda | CA6915170 |
| Mazda | ZZJ115172 |
| Motorad | 354-180 |
| Motorcraft | RT1172 |
| Motorcraft | RT1182 |
| NAPA Belts/Hose | 33238 |
| Stant | 46138 |
| Stant | 4G209003 |
Fits Years: 2003 2004 2005
Fits Models: Aviator
Keep your Aviator's 4.6L V8 running at the right temperature by understanding this critical cooling system part.
