Voice or type your vehicle details and Wrenchy will confirm fitment in seconds.
| Attribute | Value |
|---|---|
| Advertised Exhaust Duration | 306 |
| Advertised Intake Duration | 273 |
| Amazon ASIN | B002edy1kq |
| Assembly Lubricant Included | No |
| Basic Operating RPM Range | 750-6,600 |
| C.A.R.B. E.O. Number | N/a |
| C.A.R.B. Exempt For California Certified Vehicles Manufactured Before 1965? | Yes, But Must Meet Tailpipe Emission Standards For Year Of Vehicle. |
| C.A.R.B. Exempt For Federally Certified Vehicles Manufactured Before 1967? | Yes, But Must Meet Tailpipe Emission Standards For Year Of Vehicle. |
| C.A.R.B. Exempt For Foreign Vehicles Manufactured Before 1967? | Yes, But Must Meet Tailpipe Emission Standards For Year Of Vehicle. |
| C.A.R.B. Exempt For On Road Vehicles? | No |
| C.A.R.B. Exempt For Racing And Off Road Only Vehicles? | Yes, But Must Be A Race/competition Only Vehicle. |
| C.A.R.B. Exemption Reason | N/a |
| Cam Type | Hydraulic Roller Finger Follower |
| Camshaft Gear Attachment | 1-bolt |
| Camshaft Material | Billet Steel |
| Camshaft Series | Thumpr Nsr (no Springs Required) |
| Engine Family | Ford 4.6l And 5.4l Sohc Modular 3 Valve 8 Cylinder (2004+) |
| Exhaust Valve Lift | 0.45 |
| Grind Number | Mt273ll-9 |
| Intake Duration At .050 Inch Lift | 234 |
| Intake Valve Lift | 0.45 |
| Lifter Type | Hydraulic Roller Finger Follower |
| Lifters Included | No |
| Lobe Separation | 109 |
| Usage | Street/strip |
| Valve Springs Required | No |
This part fits the following vehicles:
| SubmodelSUB- MODEL |
Body Style | Years | Engine | Attributes |
|---|---|---|---|---|
| Base | SUV | 2009 - 2014 | V8 5.4L FLEX | RWD/4WD Automatic |
| Base | SUV | 2005, 2008 | V8 5.4L | RWD/4WD Automatic |
| L | SUV | 2009 - 2014 | V8 5.4L FLEX | RWD/4WD Automatic |
| L | SUV | 2008 | V8 5.4L | RWD/4WD Automatic |
| L Executive | SUV | 2013 - 2014 | V8 5.4L | RWD Automatic |
| L Luxury | SUV | 2007 | V8 5.4L | RWD/4WD Automatic |
| L Ultimate | SUV | 2007 - 2009, 2013 - 2014 | V8 5.4L | RWD Automatic |
| L Ultimate | SUV | 2007 - 2008 | V8 5.4L | AWD Automatic |
| L Ultimate | SUV | 2007, 2009 | V8 5.4L | 4WD Automatic |
| Limited | SUV | 2013 - 2014 | V8 5.4L | RWD Automatic |
| Luxury | SUV | 2006 - 2007 | V8 5.4L | RWD/4WD Automatic |
| Ultimate | SUV | 2011 | V8 5.4L FLEX | AWD Automatic |
| Ultimate | SUV | 2010 - 2011 | V8 5.4L FLEX | RWD Automatic |
| Ultimate | SUV | 2010 | V8 5.4L FLEX | 4WD Automatic |
| Ultimate | SUV | 2006 - 2007 | V8 5.4L | 4WD Automatic |
| Ultimate | SUV | 2005 - 2009, 2011 - 2014 | V8 5.4L | RWD Automatic |
| Ultimate | SUV | 2005 - 2008, 2011 - 2014 | V8 5.4L | AWD Automatic |
We offer fast, reliable shipping on all orders:
We want you to be 100% satisfied with your purchase. That's why we offer:
This part comes with a limited lifetime warranty. Warranty begins on the original purchase date.
Warranty does NOT cover:
Fits Years: 2005 2006 2007 2008 2009 2010 2011 2012 2013 2014
Fits Models: Navigator
