| Attribute | Value |
|---|---|
| Adjustable | No |
| Ball Joint Assembly | No |
| Bushings Included | No |
| Castle Nut Included | Yes |
| Color | Gray |
| Cotter Pin Hole | Yes |
| Cotter Pin Included | Yes |
| Dust Boot Included | Yes |
| Dust Boot Material | Rubber |
| Grease Fitting Included | No |
| Material | Ball Material - Alloy Steel Sae 5140, Housing Material - Carbon Steel Sae 1040 |
| Maximum Outside Diameter | 1.909, 48.49 |
| Mount Plate Included | No |
| Mounting Hardware Included | Yes |
| Mounting Hole Quantity | 0 |
| Mounting Type | Press-in |
| Nuts Included | Yes |
| Position(s) | Rear Lower |
| Stud Tapered End 1 Diameter | 0.488, 12.4 |
| Stud Tapered End 2 Diameter | 0.661, 16.8 |
| Stud Thread Diameter | 0.47 |
| Stud Thread Length | 0.764, 19.4 |
| Stud Thread Pitch | 1.75 |
| Tapered Stud | Yes |
| Washers Included | No |
This part fits the following vehicles:
| SubmodelSUB- MODEL |
Body Style | Years | Engine | Attributes |
|---|---|---|---|---|
| Base | SUV | 2015 - 2016 | V6 3.5L Turbo | AWD Automatic |
| Base | SUV | 2015 | V6 3.5L Turbo | RWD/4WD Automatic |
| Base | SUV | 2009 - 2014 | V8 5.4L FLEX | RWD/4WD Automatic |
| Base | SUV | 2008 | V8 5.4L | RWD/4WD Automatic |
| L | SUV | 2015 | V6 3.5L Turbo | AWD/RWD/4WD Automatic |
| L | SUV | 2009 - 2014 | V8 5.4L FLEX | RWD/4WD Automatic |
| L | SUV | 2008 | V8 5.4L | RWD/4WD Automatic |
| L Executive | SUV | 2013 - 2014 | V8 5.4L | RWD Automatic |
| L Luxury | SUV | 2007 | V8 5.4L | RWD/4WD Automatic |
| L Reserve | SUV | 2016 - 2017 | V6 3.5L Turbo | RWD/4WD Automatic |
| L Reserve | SUV | 2015 | V6 3.5L Turbo | AWD Automatic |
| L Select | SUV | 2016 - 2017 | V6 3.5L Turbo | RWD/4WD Automatic |
| L Ultimate | SUV | 2007 - 2009, 2013 - 2014 | V8 5.4L | RWD Automatic |
| L Ultimate | SUV | 2007 - 2008 | V8 5.4L | AWD Automatic |
| L Ultimate | SUV | 2007, 2009 | V8 5.4L | 4WD Automatic |
| Limited | SUV | 2013 - 2014 | V8 5.4L | RWD Automatic |
| Luxury | SUV | 2007 | V8 5.4L | RWD/4WD Automatic |
| Reserve | SUV | 2016 - 2017 | V6 3.5L Turbo | RWD/4WD Automatic |
| Reserve | SUV | 2015 | V6 3.5L Turbo | AWD Automatic |
| Select | SUV | 2016 - 2017 | V6 3.5L Turbo | RWD/4WD Automatic |
| Ultimate | SUV | 2011 | V8 5.4L FLEX | AWD Automatic |
| Ultimate | SUV | 2010 - 2011 | V8 5.4L FLEX | RWD Automatic |
| Ultimate | SUV | 2010 | V8 5.4L FLEX | 4WD Automatic |
| Ultimate | SUV | 2007 - 2009, 2011 - 2014 | V8 5.4L | RWD Automatic |
| Ultimate | SUV | 2007 - 2008, 2011 - 2014 | V8 5.4L | AWD Automatic |
| Ultimate | SUV | 2007 | V8 5.4L | 4WD Automatic |
We offer fast, reliable shipping on all orders:
We want you to be 100% satisfied with your purchase. That's why we offer:
This part comes with a limited lifetime warranty. Warranty begins on the original purchase date.
Warranty does NOT cover:
| Brand | Part Number |
|---|---|
| MAS Industries | BJ85845 |
| MAS Industries | BJ85845PR |
| Mevotech | GS40510 |
| Mevotech | MS40510 |
| TRW | JBJ489 |
Fits Years: 2007 2008 2009 2010 2011 2012 2013 2014 2015 2016 2017
Fits Models: Navigator
