| Attribute | Value |
|---|---|
| Anti Lock Braking System | Yes |
| Anti Lock Braking System Type | Tone Ring With Sensor |
| Bearing Generation | Gen 3 |
| Bearing Type | Taper |
| Bolt Circle Diameter | 135, 5.315 |
| Brake Pilot Diameter | 3.543, 90 |
| Drive Type | Non-driven |
| Flange Bolt Hole Quantity | 4 |
| Flange Diameter | 183, 7.2 |
| Flange Included | Yes |
| Flange Offset | 1.791, 45.5 |
| Flange Quantity | 2 |
| Flange Shape | Square |
| Knuckle Bolt Circle Diameter | 160, 6.299 |
| Knuckle Bolt Hole Size | 0.55, 14 |
| Knuckle Bolt Thread Pitch | 1.5 |
| Knuckle Pilot Hole Diameter | 3.91, 99.3 |
| Wheel Pilot Diameter | 3.416, 86.8 |
| Wheel Stud Quantity | 6 |
| Wheel Stud Size | 0.55, 14 |
| Wheel Stud Thread Pitch | 2 |
This part fits the following vehicles:
| SubmodelSUB- MODEL |
Body Style | Years | Engine | Attributes |
|---|---|---|---|---|
| Base | SUV | 2011 - 2014 | V8 5.4L FLEX | RWD/4WD Automatic |
| L | SUV | 2011 - 2014 | V8 5.4L FLEX | RWD/4WD Automatic |
| L Executive | SUV | 2013 - 2014 | V8 5.4L | RWD Automatic |
| L Ultimate | SUV | 2013 - 2014 | V8 5.4L | RWD Automatic |
| Limited | SUV | 2013 - 2014 | V8 5.4L | RWD Automatic |
| Ultimate | SUV | 2011 - 2014 | V8 5.4L | AWD/RWD Automatic |
| Ultimate | SUV | 2011 | V8 5.4L FLEX | AWD/RWD Automatic |
We offer fast, reliable shipping on all orders:
We want you to be 100% satisfied with your purchase. That's why we offer:
This part comes with a limited lifetime warranty. Warranty begins on the original purchase date.
Warranty does NOT cover:
| Brand | Part Number |
|---|---|
| Alltech Automotive | 530682 |
| Autopart International | 1411480984 |
| Centric Parts | 407.65005 |
| Centric Parts | 407.65005E |
| DuraGo | 29515143 |
| GMB | 7253110 |
| Mevotech | MB40303 |
| MOOG Chassis Products | 515143 |
| Motorcraft | HUB172 |
| Motorcraft | HUB229 |
| Motorcraft | HUB293 |
| Motorcraft | HUB354 |
| MPA | WH550220 |
| Raybestos Brakes | 715143 |
| Schaeffler | 102766 |
| SKF | BR930791 |
| Timken | HA590487 |
| Timken | SP550220 |
Fits Years: 2011 2012 2013 2014
Fits Models: Navigator
