| Attribute | Value |
|---|---|
| ABS Tone Ring Included | No |
| Center Hole Diameter | 2.84, 72.15 |
| Conventional Or Drum In Hat Type Rotor | Conventional |
| Directional Or Non Directional Brake Surface | Non-directional |
| Discard Thickness | 0.906, 23 |
| Harmonize Code | 8708.30.5030 |
| Material | Cast Iron |
| Mounting Bolt Hole Circle Diameter | 114.3, 4.5 |
| Mounting Bolt Hole Diameter | 0.54, 13.7 |
| Mounting Bolt Hole Quantity | 5 |
| Nominal Thickness | 0.984, 25 |
| Overall Height | 1.905, 48.4 |
| Salability Restrictions | No |
| Solid Or Vented Type Rotor | Vented |
| Stud/Lug Hole Quantity | 5 |
| UNSPSC Code | 25171715 |
This part fits the following vehicles:
| SubmodelSUB- MODEL |
Body Style | Years | Engine | Attributes |
|---|---|---|---|---|
| GS | Hatchback | 2004 - 2006, 2009 - 2011 | L4 2.0L | FWD Automatic & Manual |
| GS | Sedan | 2004 - 2006, 2008 - 2012 | L4 2.0L | FWD Automatic & Manual |
| GS-SKY | Sedan | 2012 - 2013 | L4 2.0L | FWD Automatic & Manual |
| GT | Hatchback | 2010 - 2011 | L4 2.5L | FWD Automatic & Manual |
| GT | Hatchback | 2004 - 2006, 2008 - 2009 | L4 2.3L | FWD Automatic & Manual |
| GT | Sedan | 2010 - 2013 | L4 2.5L | FWD Automatic & Manual |
| GT | Sedan | 2004 - 2006, 2008 - 2009 | L4 2.3L | FWD Automatic & Manual |
| GX | Hatchback | 2009 - 2011 | L4 2.0L | FWD Automatic & Manual |
| GX | Sedan | 2004 - 2006, 2008 - 2013 | L4 2.0L | FWD Automatic & Manual |
| Grand Touring | Hatchback | 2010 - 2013 | L4 2.3L Turbo | FWD Manual |
| I Touring | Sedan | 2010 - 2013 | L4 2.0L | FWD Automatic & Manual |
| Mazdaspeed | Hatchback | 2007 - 2013 | L4 2.3L Turbo | FWD Manual |
| S | Hatchback | 2010 - 2013 | L4 2.5L | FWD Automatic & Manual |
| S | Hatchback | 2004 - 2009 | L4 2.3L | FWD Automatic & Manual |
| S | Sedan | 2010 - 2013 | L4 2.5L | FWD Automatic & Manual |
| S | Sedan | 2004 - 2009 | L4 2.3L | FWD Automatic & Manual |
| SP23 | Hatchback | 2005 | L4 2.3L | FWD Automatic & Manual |
| SP23 | Sedan | 2005 | L4 2.3L | FWD Automatic & Manual |
| Sport GS | Hatchback | 2011 | L4 2.5L | FWD Automatic & Manual |
| Sport GT | Hatchback | 2011 | L4 2.5L | FWD Automatic & Manual |
| Sport GX | Hatchback | 2011 | L4 2.0L | FWD Automatic & Manual |
| i | Hatchback | 2012 - 2013 | L4 2.0L | FWD Automatic & Manual |
| i | Sedan | 2004 - 2013 | L4 2.0L | FWD Automatic & Manual |
We offer fast, reliable shipping on all orders:
We want you to be 100% satisfied with your purchase. That's why we offer:
This part comes with a limited lifetime warranty. Warranty begins on the original purchase date.
Warranty does NOT cover:
| Brand | Part Number |
|---|---|
| Advance Auto Parts | N1000405784ZXC |
| Advance Auto Parts | YH145603 |
| Advance Auto Parts | YH145603C |
| Advance Auto Parts | YH145603P |
| Autopartsource | 474730 |
| Autoxtra | AX31363 |
| AutoZone | 31363DG |
| Bendix | 145603 |
| Bosch | 34010890 |
| BrakeBest | 980283 |
| BrakeBest | 980283FZN |
| BrakeBest | 980283R |
| BrakeBest | 980283RGS |
| Brembo | 09.9468.20 |
| Brembo | 09.9468.21 |
| Brembo | 25876 |
| Casting Numbers | 211669-C |
| Casting Numbers | 326181 |
| Centric Parts | 120.45069 |
| Centric Parts | 120.45069CRY |
| Centric Parts | 121.45069 |
| Centric Parts | 125.45069 |
| Centric Parts | 125.45069CRY |
| Centric Parts | 126.45069CSL |
| Centric Parts | 126.45069CSR |
| Centric Parts | 126.45069SL |
| Centric Parts | 126.45069SR |
| Centric Parts | 127.45069CL |
| Centric Parts | 127.45069CR |
| Centric Parts | 127.45069L |
| Centric Parts | 127.45069R |
| Centric Parts | 128.45069CL |
| Centric Parts | 128.45069CR |
| Centric Parts | 128.45069L |
| Centric Parts | 128.45069R |
| Centric Parts | 227.45069L |
| Centric Parts | 227.45069R |
| Centric Parts | 320.45069 |
| Centric Parts | 321.45069 |
| Dura Corp | BR31363 |
| Dura Corp | BR3136302 |
| Mazda | BP6Y3325XB |
| Mazda | BP6Y3325XD |
| Mazda | BP6Y3325XE |
| Mazda | BP6Y3325XF |
| Mazda | C26Y3325XA |
| Mazda | C26Y3325XB |
| Mazda | C26Y3325XC |
| Mazda | C26Y3325XD |
| Mighty Distributing System | 31363 |
| NAPA BRAKES | SDK6287 |
| Omnicraft | QBRR209 |
| PowerStop | JBR1115EVC |
| Promax | 14-31363 |
| Promax | 20-31363 |
| TRW | 4385 |
| UAP | 2031363 |
| Ultra Brake | MA-878 |
| VIPAR - Vehicle Indusrty Parts & Manufacturing | X51700 |
| WABCO - Archived | PS126328 |
| Wagner Brake | BD126328 |
| Wagner Brake | BD126328E |
| Winhere | 662964 |
Fits Years: 2004 2005 2006 2007 2008 2009 2010 2011 2012 2013
Fits Models: 3
