| Attribute | Value |
|---|---|
| Bolt Hole Pattern | 2 |
| Bolt Hole PCD Clutch Pres.plte | 10.2362, 260 |
| Bolt Hole PCD Crankshaft | 2.7559, 70 |
| Centering Diameter / Dowel Hole | 10.2362, 260 |
| Crank Hole Dia. | 0.4949, 12.57 |
| Crank To Friction Surface | 0.7736, 19.65 |
| Dowel Hole Pattern | 5 |
| Dowel Hole Diameter | 0.315 |
| Flange Thickness | 0.2972, 7.55 |
| Flywheel Cup Depth Or Step Height | -0.2854, -7.25 |
| Flywheel Friction Surface Inner Diameter | 148, 5.8268 |
| Flywheel Thickness [mm] | 1.2992, 33 |
| Flywheel Friction Surface Outer Diameter | 235, 9.252 |
| Flywheel Matches Clutch | Flywheel Matches Clutch |
| Has Dowel Pins | With Dowel Pins |
| I.D. For Pilot | 1.2547, 31.87 |
| Number Of Teeth, Starter Ring Gear | 112 |
| Overall Casting O.D. | 11.2598, 286 |
| Ring Gear Chamfer Position @ 6:00 O´clock | Left |
| Ring Gear Chamfer Side | Engine |
| Ring Gear Chamfer Matches OE | Ring Gear Chamfer Matches Oe |
| Ring Gear Major Dia. | 11.378, 289 |
| Ring Gear Mounting O.D. | 10.2913, 261.4 |
| Ring Gear Thickness | 0.3209, 8.15 |
This part fits the following vehicles:
| SubmodelSUB- MODEL |
Body Style | Years | Engine | Attributes |
|---|---|---|---|---|
| GS | Hatchback | 2004 - 2006, 2009 | L4 2.0L | FWD Automatic & Manual |
| GS | Sedan | 2004 - 2006, 2008 - 2009 | L4 2.0L | FWD Automatic & Manual |
| GT | Hatchback | 2004 - 2006, 2008 - 2009 | L4 2.3L | FWD Automatic & Manual |
| GT | Sedan | 2004 - 2006, 2008 - 2009 | L4 2.3L | FWD Automatic & Manual |
| GX | Hatchback | 2009 | L4 2.0L | FWD Automatic & Manual |
| GX | Sedan | 2004 - 2006, 2008 - 2009 | L4 2.0L | FWD Automatic & Manual |
| Mazdaspeed | Hatchback | 2007 - 2009 | L4 2.3L Turbo | FWD Manual |
| S | Hatchback | 2004 - 2009 | L4 2.3L | FWD Automatic & Manual |
| S | Sedan | 2004 - 2009 | L4 2.3L | FWD Automatic & Manual |
| SP23 | Hatchback | 2005 | L4 2.3L | FWD Automatic & Manual |
| SP23 | Sedan | 2005 | L4 2.3L | FWD Automatic & Manual |
| i | Sedan | 2004 - 2009 | L4 2.0L | FWD Automatic & Manual |
We offer fast, reliable shipping on all orders:
We want you to be 100% satisfied with your purchase. That's why we offer:
This part comes with a limited lifetime warranty. Warranty begins on the original purchase date.
Warranty does NOT cover:
| Brand | Part Number |
|---|---|
| Mazda | L327-11-500C |
Fits Years: 2004 2005 2006 2007 2008 2009
Fits Models: 3
