| Attribute | Value |
|---|---|
| Amperage (A) | 6.6 |
| Attachment Method | In Tank |
| Average Current Draw | 6.6 |
| Average Flow Rating | 142.5 |
| Bracket Included | No |
| Connector Color | Black |
| Connector Gender | Female |
| Connector Shape | Round |
| Electric Or Mechanical | Electric |
| Fill Vapor Valve Included | No |
| Flow Rate (gph) | 37.5 |
| Flow Rate (lph) | 142.5 |
| Flow Restriction Pressure (psi) | 80 |
| Fuel Filter Included | No |
| Fuel Level Sensor Assembly Included | Yes |
| Fuel Level Vent Valve (FLVV) Included | No |
| Fuel Pressure Regulator Included | No |
| Fuel Sending Unit Included | Yes |
| Fuel Static Pressure (psi) | Na |
| Fuel Tank Pressure Sensor Included | No |
| Fuel Type | Gas |
| Gasket Or Seal Included | Yes |
| Gasket Or Seal Material | Nbr |
| Grade Type | Regular |
| Housing Length | 99 |
| Housing Width | 99 |
| In Line Pump | No |
| Inlet Attachment Method | Hose |
| Inlet Diameter (In) | 0.31 |
| Inlet Diameter (mm) | 7.8 |
| Inlet Fitting Size (In) | .31 |
| Inlet Fitting Thread Size | Na |
| Inlet Fitting Type | Hose |
| Inlet Outside Diameter | 7.8 |
| Inlet Quantity | 1 |
| Inlet Thread Diameter | Na |
| Internal Or External Strainer | External |
| Lock Ring Included | No |
| Manufacturer | Autotecnica |
| Maximum Flow Rate (gph) | 41 |
| Maximum Flow Rating | 41 |
| Maximum Pressure | Na |
| Maximum Pressure (psi) | 80 |
| Minimum Flow Rate (gph) | 34 |
| Minimum Flow Rating | 34 |
| Minimum Free Flow Rate | Na |
| Minimum Pressure | Na |
| Module Included | No |
| Mounting Hardware Included | No |
| Negative Ground | Yes |
| OE Part/Casting Number | Yl8z9h307ah |
| Outlet Diameter (In) | .374 |
| Outlet Fitting Size (In) | .374 |
| Outlet Fitting Thread Size | Na |
| Outlet Fitting Type | Hose |
| Outlet Outside Diameter | 9.5 |
| Outlet Quantity | 1 |
| Outlet Thread Diameter | Na |
| Pump Design | Na |
| Pump Type | Electric |
| Regulator Included | Yes |
| Resistance Ohms Empty | 15.3 |
| Resistance Ohms Full | 158.3 |
| Rheostat Range (Ohm) | 15.1 - 158.3 |
| Rollover Valve Included | No |
| Shut Off Pressure (psi) | Na |
| Strainer Included | Yes |
| Strainer Location | External |
| Tank Seal Included | Yes |
| Terminal Gender | Male |
| Terminal Quantity | 4 |
| Terminal Shape | Round |
| Terminal Type | Pin |
| Thermistor Low Fuel Indicator Included | No |
| Top Mount Diameter | 124.8 |
| Top Mount Diameter (mm) | 124.8 |
| Vapor Pressure Sensor Included | No |
| Vapor Vent Line Included | No |
| Wire Harness Included | Yes |
| Wire Quantity | 4 |
| Wiring Harness Length | 64 |
This part fits the following vehicles:
| SubmodelSUB- MODEL |
Body Style | Years | Engine | Attributes |
|---|---|---|---|---|
| DX | SUV | 2001 - 2004 | L4 2.0L | FWD/4WD Automatic & Manual |
| DX | SUV | 2001 - 2004 | V6 3.0L | FWD/4WD Automatic & Manual |
| ES | SUV | 2001 - 2004 | V6 3.0L | FWD/4WD Automatic |
| LX | SUV | 2001 - 2004 | V6 3.0L | FWD/4WD Automatic |
We offer fast, reliable shipping on all orders:
We want you to be 100% satisfied with your purchase. That's why we offer:
This part comes with a limited lifetime warranty. Warranty begins on the original purchase date.
Warranty does NOT cover:
| Brand | Part Number |
|---|---|
| Airtex | E2291M |
| Autotecnica | FD0517229 |
| Bosch | 67 192 |
| Carter | P74963M |
| Delphi | FG0969 |
| Mazda | AJ03-13-35XB |
| Mazda | AJ03-13-35XC |
| Mazda | AJTT-13-35X |
| Mazda | AJTW-13-35X |
| Mazda | YF09-13-35XB |
| Mazda | YF09-13-35XC |
| Mazda | YFTT-13-35X |
| Mazda | YFTT-13-35XA |
| Mazda | ZZC3-13-35X |
| Mazda | ZZTT-13-35X |
| Motorcraft | PFS-1013 |
| Spectra Premium | SP2291M |
| TYC | 150037-A |
| US Motor Works | USEP2291M |
Fits Years: 2001 2002 2003 2004
Fits Models: Tribute
