Voice or type your vehicle details and Wrenchy will confirm fitment in seconds.
| Attribute | Value |
|---|---|
| 130.00 | |
| ABS Tone Ring Included | No |
| Assy/Disassy By Qualified Personnel Required! | . |
| Balancing Type | Mill Balancing |
| Bearings Included | No |
| Bolt Hole Circle Ø [in] | 5.12 |
| Bolt Hole Circle Ø [mm] | 130 |
| Bolt Hole Quantity | 7 |
| Brake Disc Thickness [in] | 0.63 |
| Brake Disc Thickness [mm] | 16 |
| Brake Disc Type | Solid |
| California Proposition 65 Required | No |
| Center Hole Diameter | 114.3 |
| Centering Diameter [in] | 3.35 |
| Color | Silver |
| Colour | Silver |
| Construction | Full Cast |
| Directional Or Non Directional Brake Surface | Non-directional |
| Disc Finish | Coated |
| Discard Thickness | 14.00 |
| Grade Type | Standard Replacement |
| Hat Finish | Coated |
| Height [in] | 2.80 |
| Hole Arrangement / Number | 06/07 |
| Hole Arrangement/Number | 06/07 |
| Inside Diameter | 85.0 |
| Machining | High-carbon |
| Material | Gray Cast Iron |
| Minimum Thickness [in] | 0.55 |
| Minimum Thickness [mm] | 14 |
| Mounting Bolt Hole Circle Diameter | 130.00 |
| Mounting Bolt Hole Quantity | 7 |
| Nominal Thickness | 16.00 |
| Number Of Bolts/screws | 1 |
| Outer Diameter [in] | 11.73 |
| Overall Height | 71.00 |
| Rust Resistant Coating | Yes |
| Solid Or Vented Type Rotor | Solid |
| Surface | Coated |
| Surface Type | Smooth |
| Technical Information Number | 59433pro_hc_na |
| Weight [kg] | 7,4, 7.4 |
This part fits the following vehicles:
| SubmodelSUB- MODEL |
Body Style | Years | Engine | Attributes |
|---|---|---|---|---|
| Base | Extended Cargo Van | 2015 - 2017 | L4 2.1L DIESEL Turbo | 4WD Automatic |
| Base | Extended Cargo Van | 2015 - 2018 | V6 3.0L DIESEL Turbo | 4WD Automatic |
| Base | Extended Cargo Van | 2014 - 2017 | L4 2.1L DIESEL Turbo | RWD Automatic |
| Base | Extended Cargo Van | 2012 | V6 3.0L DIESEL Turbo | RWD Automatic |
| Base | Extended Cargo Van | 2010 - 2011, 2013 - 2018 | V6 3.0L DIESEL Turbo | RWD Automatic |
| Base | Standard Cargo Van | 2015 - 2017 | L4 2.1L DIESEL Turbo | 4WD Automatic |
| Base | Standard Cargo Van | 2015 - 2018 | V6 3.0L DIESEL Turbo | 4WD Automatic |
| Base | Standard Cargo Van | 2014 - 2017 | L4 2.1L DIESEL Turbo | RWD Automatic |
| Base | Standard Cargo Van | 2010 - 2018 | V6 3.0L DIESEL Turbo | RWD Automatic |
| Base | Standard Passenger Van | 2015 - 2017 | L4 2.1L DIESEL Turbo | 4WD Automatic |
| Base | Standard Passenger Van | 2015 - 2018 | V6 3.0L DIESEL Turbo | 4WD Automatic |
| Base | Standard Passenger Van | 2014 - 2017 | L4 2.1L DIESEL Turbo | RWD Automatic |
| Base | Standard Passenger Van | 2010 - 2018 | V6 3.0L DIESEL Turbo | RWD Automatic |
We offer fast, reliable shipping on all orders:
We want you to be 100% satisfied with your purchase. That's why we offer:
This part comes with a limited lifetime warranty. Warranty begins on the original purchase date.
Warranty does NOT cover:
| Brand | Part Number |
|---|---|
| Akebono | BN0177 |
| Akebono | BN0177E |
| AMC | FLDI00720 |
| AMC | FO2822 |
| Ashuki | P331008 |
| ATE | 24011601211 |
| ATE | 416121 |
| Bendix | 521287 |
| Bendix | 562486B |
| Blue Print | ADU174351 |
| Borg & Beck | BBD4571 |
| Bosch | 0986479295 |
| Bosch | 0986479S05 |
| Bosch | F026A06767 |
| Brake Engineering | DI956433 |
| Brembo | 08950910 |
| Brembo | 08950911 |
| Brembo | 08950914 |
| Brembo | 0895091G |
| Cifam | 800936 |
| Delphi | BG4033 |
| Delphi | BG4033T |
| Delphi | BG5124C |
| DON | CVD656 |
| DON | PCD18332 |
| Dynamic Friction Company | 631-40044L |
| Dynamic Friction Company | 631-40044R |
| Dynamic Friction Company | 633-40044L |
| Dynamic Friction Company | 633-40044R |
| EBC Brakes | D1564 |
| Febi-Bilstein | 27699 |
| Ferodo | FCR311A |
| Ferodo | FCR311AX |
| Ferodo | FCR311C |
| FREMAX BRAKE ROTORS AND DRUMS | BD0191 |
| FTE | 9071005 |
| FTE | 9081124 |
| FTE | BS7131 |
| FTE | BS7131B |
| Girling | 6048235 |
| Hella Pagid | 59433PROHCNA |
| Hella Pagid | 8DD355123172 |
| Japan Parts | DP0527 |
| Japan Parts | DP0527C |
| Jurid | 569137J |
| Jurid | 569137JC1 |
| Key Parts | KBD4571 |
| LPR | M2043P |
| LPR | M2043PR |
| Magneti Marelli | 360704012800 |
| Mercedes-Benz | 910 423 00 00 |
| Mercedes-Benz | 910 423 01 00 |
| Mercedes-Benz | 9104230000 |
| Mercedes-Benz | 910423000007 |
| Mercedes-Benz | A 906 423 00 12 |
| Mercedes-Benz | A 910 423 00 00 |
| Mercedes-Benz | A 910 423 01 00 |
| Mercedes-Benz | A910423000007 |
| METELLI | 230936 |
| MEYLE | 0155232100 |
| MEYLE | 0835232100PD |
| Mintex | MDC1772 |
| Mintex | MDC1772C |
| Mintex | MVK0030 |
| Mintex | MVK0083 |
| National | NBD1422 |
| NK Autoparts | 2047122 |
| NK Autoparts | 3147122 |
| NK Autoparts | 344712 |
| Optimal | BS7846 |
| Optimal | BS7846C |
| PAGID Racing | 59433 |
| PAGID Racing | 59433PRO |
| Remsa | 6103500 |
| SBS | 18152047122 |
| SBS | 18153147122 |
| SBS | 1815344712 |
| Textar | 93143300 |
| Textar | 93143303 |
| Textar | 93143305 |
| Textar | 98200143301 |
| Topran | 111654 |
| TRW | DF4823 |
| TRW | DF4823S |
| TRW | RPDI04910 |
| VAICO | V1040081 |
| Valeo | 187142 |
| Valeo | 197030 |
| Valeo | 197322 |
| Valeo | 672918 |
| Wagner | WGR63111 |
| Zimmermann | 400647700 |
| Zimmermann | 400647720 |
| Zimmermann | 400647770 |
| Zimmermann | 400647772 |
| Zimmermann | 400647775 |
Fits Years: 2010 2011 2012 2013 2014 2015 2016 2017 2018
Fits Models: Sprinter 2500
