| Attribute | Value |
|---|---|
| ABS Tone Ring Included | No |
| Assy/Disassy By Qualified Personnel Required! | . |
| Balancing Type | Mill Balancing |
| Bearings Included | No |
| Bolt Hole Circle Ø [mm] | 111,7, 111.7 |
| Brake Disc Thickness [in] | 0.79 |
| Brake Disc Thickness [mm] | 20 |
| Brake Disc Type | Internally Vented |
| California Proposition 65 Required | No |
| Center Hole Diameter | 112.0 |
| Centering Diameter [in] | 2.64 |
| Construction | Full Cast |
| Directional Or Non Directional Brake Surface | Non-directional |
| Disc Finish | Coated |
| Discard Thickness | 18.4 |
| Grade Type | Standard Replacement |
| Hat Finish | Coated |
| Hole Arrangement / Number | 05/06 |
| Hole Arrangement/Number | 05/06 |
| Inner Diameter [in] | 6.54 |
| Inside Diameter | 67.0 |
| Material | Gray Cast Iron |
| Minimum Thickness [mm] | 18,4, 18.4 |
| Mounting Bolt Hole Circle Diameter | 111.7 |
| Mounting Bolt Hole Quantity | 5 |
| Nominal Thickness | 20.0 |
| Outer Diameter [in] | 11.81 |
| Overall Height | 50.6 |
| Rust Resistant Coating | Yes |
| Solid Or Vented Type Rotor | Vented |
| Surface | Coated |
| Surface Type | Smooth |
| Technical Information Number | 55745pro |
| Weight [kg] | 5,5, 5.5 |
| Wheel Bolt Bore Diameter [mm] | 16.7 |
| Wheel Bolt Bore Ø [mm] | 16.7 |
This part fits the following vehicles:
| SubmodelSUB- MODEL |
Body Style | Years | Engine | Attributes |
|---|---|---|---|---|
| ALL4 | Wagon | 2017 - 2019 | L3 1.5L Turbo | AWD Automatic & Manual |
| Base | Wagon | 2017 - 2019 | L3 1.5L Turbo | FWD Automatic & Manual |
| Chili | Wagon | 2019 | L3 1.5L Turbo | FWD Automatic Dual Clutch |
| John Cooper Works ALL4 | Wagon | 2017 - 2019 | L4 2.0L Turbo | AWD Automatic & Manual |
| S | Wagon | 2017 - 2019 | L4 2.0L Turbo | FWD Automatic & Manual |
| S ALL4 | Wagon | 2017 - 2019 | L4 2.0L Turbo | AWD Automatic & Manual |
| S Chili | Wagon | 2018 | L3 1.5L Turbo | FWD Automatic |
| S Chili | Wagon | 2017 | L4 2.0L Turbo | FWD Automatic |
| S Hot Chili | Wagon | 2017 - 2019 | L4 2.0L Turbo | FWD Automatic |
We offer fast, reliable shipping on all orders:
This part comes with a limited lifetime warranty. Warranty begins on the original purchase date.
Warranty does NOT cover:
We want you to be 100% satisfied with your purchase. That's why we offer:
| Brand | Part Number |
|---|---|
| Akebono | BN1249 |
| Akebono | BN1249E |
| ATE | 24012002441 |
| Blue Print | ADBP430031 |
| BMW | 34 42 6 936 369 |
| BMW | 34206891086 |
| BMW | 6891086 |
| Borg & Beck | BBD5383 |
| Bosch | 0986479C95 |
| Brake Engineering | DI957140 |
| Brembo | 09C74311 |
| Brembo | 09C7431E |
| Delphi | BG4778C |
| Delphi | BG4778C18B1 |
| DON | PCD23222 |
| Dynamic Friction Company | 600-31158 |
| Dynamic Friction Company | 604-31158 |
| Dynamic Friction Company | 640-31158 |
| Dynamic Friction Company | 644-31158 |
| Dynamic Friction Company | 900-31158 |
| Dynamic Friction Company | 940-31158 |
| EBC Brakes | D1997 |
| EBC Brakes | GD1997 |
| EBC Brakes | USR1997 |
| Febi-Bilstein | 171479 |
| Ferodo | DDF2763C |
| FREMAX BRAKE ROTORS AND DRUMS | BD0044 |
| FTE | 9072572 |
| FTE | 9082278 |
| FTE | BS7800 |
| FTE | BS7800B |
| Girling | 6067552 |
| Hella Pagid | 55745PRO |
| Hella Pagid | 8DD355122631 |
| Japan Parts | DP0106 |
| Japan Parts | DP0106C |
| JP Group A/S | 1463207300 |
| Jurid | 563261JC |
| Jurid | 563261JC1 |
| LPR | B2080V |
| MEYLE | 3155230064PD |
| Mintex | MDC2679 |
| Mintex | MDC82679C |
| National | NBD2233 |
| NK Autoparts | 2015117 |
| NK Autoparts | 3115117 |
| Optimal | BS9606HC |
| PAGID Racing | 55745 |
| Quinton Hazell | BDC6259 |
| Quinton Hazell | MBD6259 |
| Remsa | 6163210 |
| SBS | 18152015117 |
| SBS | 18153115117 |
| Textar | 92274503 |
| Textar | 98200274501 |
| Tridon | 8120111070C |
| TRW | DF6755 |
| TRW Steering and Suspension Parts | DF6755S |
| VAICO | V2040053 |
| Valeo | 197973 |
| Valeo | 672870 |
| Werner Metzger GmbH | 6110786 |
| Zimmermann | 150293220 |
| Zimmermann | 150293252 |
Fits Years: 2017 2018 2019
Fits Models: Cooper Clubman
