| Attribute | Value |
|---|---|
| Attribute ID (Type) | California Proposition 65 |
| Bolt Circle Diameter [cntrc] In | 4.750 |
| Bolt Circle Diameter [cntrc] Mm | 120.650 |
| Bolt Circle Diameter In | 4.750 |
| Bolt Circle Diameter Mm | 120.65 |
| Brake Pilot Diameter | 3.107, 78.920 |
| Flange Diameter | 142.88, 142.880, 5.625 |
| Inner Mount Pilot [cntrc] In | 3.486 |
| Inner Mount Pilot [cntrc] Mm | 88.540 |
| Mounting Hole Qty [cntrc] | 4 |
| Mounting Thread Pitch | 1.5 |
| Mounting Thread Pitch [cntrc] Mm | 1.500 |
| Mounting Thread Size | M12 |
| Mouting Thread Size [cntrc] Mm | 12.000 |
| Notes [cntrc] | Magnetic Encoder Seal, Roll Form Design. Retaining Hole 1x M8-1.25 |
| Off Set (inch) | 50.95 |
| Off Set [cntrc] In | 50.950 |
| Off Set [cntrc] Mm | 2.006 |
| Product Grade [cntrc] | Premium |
| Spline Quantity | 26 |
| Thread Pitch To Wheel Mounting | 1.25 |
| Thread Pitch To Wheel Mounting [cntrc] Mm | 1.250 |
| Wheel Pilot Diameter | 2.856, 72.540 |
| Wheel Stud Quantity | 5 |
| Wheel Stud Size | 14.000, M14 |
| Wheel Studs Included | Yes |
This part fits the following vehicles:
| SubmodelSUB- MODEL |
Body Style | Years | Engine | Attributes |
|---|---|---|---|---|
| Base | Hatchback | 2013 - 2016 | L4 1.6L | FWD Automatic & Manual |
| John Cooper Works | Hatchback | 2014 - 2016 | L4 1.6L Turbo | AWD Automatic & Manual |
| John Cooper Works ALL4 | Hatchback | 2013 - 2016 | L4 1.6L Turbo | AWD Automatic & Manual |
| S | Hatchback | 2013 - 2016 | L4 1.6L Turbo | FWD Automatic & Manual |
| S ALL4 | Hatchback | 2013 - 2016 | L4 1.6L Turbo | AWD Automatic & Manual |
| S Chili | Hatchback | 2013 - 2016 | L4 1.6L Turbo | FWD Automatic & Manual |
| S Hot Chili | Hatchback | 2013 - 2016 | L4 1.6L Turbo | AWD/FWD Automatic & Manual |
We offer fast, reliable shipping on all orders:
We want you to be 100% satisfied with your purchase. That's why we offer:
This part comes with a limited lifetime warranty. Warranty begins on the original purchase date.
Warranty does NOT cover:
| Brand | Part Number |
|---|---|
| CR Services | BR930864 |
| Iljin | IJ133034 |
| OEM Part Number | 31 20 9 806 297 |
| OEM Part Number | 31 20 9 813 211 |
| OEM Part Number | 31209806297 |
| OEM Part Number | 31209813211 |
| OEM Part Number | 33 40 9 813 212 |
| OEM Part Number | 33409813212 |
| Schaeffler | F57398201 |
| Schaeffler | F57398206 |
| Schaeffler | F57398207 |
| Timken | HA590423 |
Fits Years: 2013 2014 2015 2016
Fits Models: Cooper Paceman
