| Attribute | Value |
|---|---|
| 120.00 | |
| ABS Tone Ring Included | No |
| Assy/Disassy By Qualified Personnel Required! | . |
| Balancing Type | Mill Balancing |
| Bearings Included | No |
| Bolt Hole Circle Ø [in] | 4.72 |
| Bolt Hole Circle Ø [mm] | 120 |
| Bolt Hole Quantity | 6 |
| Brake Disc Thickness [in] | 0.87 |
| Brake Disc Type | Internally Vented |
| California Proposition 65 Required | No |
| Center Hole Diameter | 120.0 |
| Centering Diameter [in] | 3.11 |
| Construction | Full Cast |
| Directional Or Non Directional Brake Surface | Non-directional |
| Disc Finish | Coated |
| Discard Thickness | 20.40 |
| Grade Type | Standard Replacement |
| Hat Finish | Coated |
| Hole Arrangement / Number | 05/06 |
| Hole Arrangement/Number | 05/06 |
| Inside Diameter | 79.0 |
| Machining | High-carbon |
| Material | Gray Cast Iron |
| Minimum Thickness [mm] | 20,4, 20.4 |
| Mounting Bolt Hole Circle Diameter | 120.00 |
| Mounting Bolt Hole Quantity | 6 |
| Nominal Thickness | 22.00 |
| Outer Diameter [in] | 11.57 |
| Overall Height | 45.00 |
| Rust Resistant Coating | Yes |
| Solid Or Vented Type Rotor | Vented |
| Surface | Coated |
| Surface Type | Smooth |
| Technical Information Number | 55778pro_hc |
| Weight [kg] | 6,6, 6.6 |
This part fits the following vehicles:
| SubmodelSUB- MODEL |
Body Style | Years | Engine | Attributes |
|---|---|---|---|---|
| Base | Hatchback | 2013 - 2016 | L4 1.6L | FWD Automatic & Manual |
| John Cooper Works | Hatchback | 2014 - 2016 | L4 1.6L Turbo | AWD Automatic & Manual |
| John Cooper Works ALL4 | Hatchback | 2013 - 2016 | L4 1.6L Turbo | AWD Automatic & Manual |
| S | Hatchback | 2013 - 2016 | L4 1.6L Turbo | FWD Automatic & Manual |
| S ALL4 | Hatchback | 2013 - 2016 | L4 1.6L Turbo | AWD Automatic & Manual |
| S Chili | Hatchback | 2013 - 2016 | L4 1.6L Turbo | FWD Automatic & Manual |
| S Hot Chili | Hatchback | 2013 - 2016 | L4 1.6L Turbo | AWD/FWD Automatic & Manual |
We offer fast, reliable shipping on all orders:
We want you to be 100% satisfied with your purchase. That's why we offer:
This part comes with a limited lifetime warranty. Warranty begins on the original purchase date.
Warranty does NOT cover:
| Brand | Part Number |
|---|---|
| ADVICS | W6F1467WS |
| Akebono | BN0581 |
| Akebono | BN0581E |
| ATE | 24012202711 |
| Blue Print | ADB114311 |
| Borg & Beck | BBD5337 |
| Bosch | 0986479725 |
| Brake Engineering | DI956985 |
| Brembo | 09B64510 |
| Brembo | 09B64511 |
| Cifam | 8001408C |
| Delphi | BG4668C |
| DON | PCD19002 |
| Dynamic Friction Company | 600-32009 |
| Dynamic Friction Company | 604-32009 |
| Dynamic Friction Company | 900-32009 |
| EBC Brakes | D1792 |
| EBC Brakes | GD1792 |
| EBC Brakes | USR1792 |
| Febi-Bilstein | 43860 |
| Ferodo | DDF2122C |
| Ferodo | DDF2122C1 |
| Ferodo | DDF2122C1D |
| FREMAX BRAKE ROTORS AND DRUMS | BD2898 |
| FTE | 9072187 |
| FTE | BS7348 |
| Girling | 6061361 |
| Girling | 6061365 |
| Hella Pagid | 55778PROHC |
| Hella Pagid | 8DD355122931 |
| Japan Parts | DI0153 |
| Japan Parts | DI0153C |
| JP Group A/S | 6063100700 |
| Jurid | 562708JC |
| Jurid | 562708JC1 |
| LPR | B2065V |
| LPR | B2065VR |
| Magneti Marelli | 360406181801 |
| Magneti Marelli | 361302040845 |
| METELLI | 231408C |
| MEYLE | 3155210020PD |
| Mintex | MDC2706 |
| NK Autoparts | 2015113 |
| NK Autoparts | 3115113 |
| Optimal | BS9282 |
| Optimal | BS9282C |
| PAGID Racing | 55778 |
| Pilenga | V478 |
| Remsa | 6143910 |
| SBS | 18152015113 |
| SBS | 18153115113 |
| Textar | 92277805 |
| Textar | 98200277801 |
| Textar | MDC82706C |
| TRW | DF6136 |
| TRW | DF8001 |
| TRW Steering and Suspension Parts | DF6136S |
| VAICO | V2080096 |
| Valeo | 197766 |
| Zimmermann | 150348520 |
| Zimmermann | 150348552 |
Fits Years: 2013 2014 2015 2016
Fits Models: Cooper Paceman
