| Attribute | Value |
|---|---|
| 120.00 | |
| ABS Tone Ring Included | No |
| Assy/Disassy By Qualified Personnel Required! | . |
| Balancing Type | Mill Balancing |
| Bearings Included | No |
| Bolt Hole Circle Ø [in] | 4.72 |
| Bolt Hole Circle Ø [mm] | 120 |
| Bolt Hole Quantity | 6 |
| Brake Disc Thickness [in] | 0.94 |
| Brake Disc Thickness [mm] | 24 |
| Brake Disc Type | Internally Vented |
| California Proposition 65 Required | No |
| Center Hole Diameter | 112.0 |
| Centering Diameter [in] | 3.11 |
| Construction | Full Cast |
| Directional Or Non Directional Brake Surface | Non-directional |
| Disc Finish | Coated |
| Discard Thickness | 22.40 |
| Grade Type | Standard Replacement |
| Hat Finish | Coated |
| Hole Arrangement / Number | 05/06 |
| Hole Arrangement/Number | 05/06 |
| Inside Diameter | 79.0 |
| Machining | High-carbon |
| Material | Gray Cast Iron |
| Minimum Thickness [mm] | 22,4, 22.4 |
| Mounting Bolt Hole Circle Diameter | 120.00 |
| Mounting Bolt Hole Quantity | 6 |
| Nominal Thickness | 24.00 |
| Outer Diameter [in] | 12.09 |
| Overall Height | 45.30 |
| Rust Resistant Coating | Yes |
| Solid Or Vented Type Rotor | Vented |
| Surface | Coated |
| Surface Type | Smooth |
| Technical Information Number | 55756pro_hc |
| Weight [kg] | 7,8, 7.8 |
| Wheel Bolt Bore Diameter [mm] | 16.7 |
| Wheel Bolt Bore Ø [mm] | 16.7 |
This part fits the following vehicles:
| SubmodelSUB- MODEL |
Body Style | Years | Engine | Attributes |
|---|---|---|---|---|
| Base | Hatchback | 2013 - 2016 | L4 1.6L | FWD Automatic & Manual |
| John Cooper Works | Hatchback | 2014 - 2016 | L4 1.6L Turbo | AWD Automatic & Manual |
| John Cooper Works ALL4 | Hatchback | 2013 - 2016 | L4 1.6L Turbo | AWD Automatic & Manual |
| S | Hatchback | 2013 - 2016 | L4 1.6L Turbo | FWD Automatic & Manual |
| S ALL4 | Hatchback | 2013 - 2016 | L4 1.6L Turbo | AWD Automatic & Manual |
| S Chili | Hatchback | 2013 - 2016 | L4 1.6L Turbo | FWD Automatic & Manual |
| S Hot Chili | Hatchback | 2013 - 2016 | L4 1.6L Turbo | AWD/FWD Automatic & Manual |
We offer fast, reliable shipping on all orders:
We want you to be 100% satisfied with your purchase. That's why we offer:
This part comes with a limited lifetime warranty. Warranty begins on the original purchase date.
Warranty does NOT cover:
| Brand | Part Number |
|---|---|
| ATE | 24012402401 |
| Blue Print | ADB114312 |
| Borg & Beck | BBD5336 |
| Bosch | 0986479726 |
| Brake Engineering | DI956983 |
| Brembo | 09B63810 |
| Brembo | 09B63811 |
| Cifam | 8001380C |
| Delphi | BG4771C |
| DON | PCD20752 |
| Dynamic Friction Company | 600-32011 |
| Dynamic Friction Company | 604-32011 |
| Dynamic Friction Company | 900-32011 |
| Febi-Bilstein | 43925 |
| Ferodo | DDF2125C |
| Ferodo | DDF2125C1 |
| Ferodo | DDF2125C1D |
| FREMAX BRAKE ROTORS AND DRUMS | BD9062 |
| Girling | 6061195 |
| Hella Pagid | 55756PROHC |
| Hella Pagid | 8DD355126291 |
| Japan Parts | DI0154 |
| Japan Parts | DI0154C |
| Jurid | 562717JC |
| Jurid | 562717JC1 |
| LPR | B2066V |
| Magneti Marelli | 3.60406E+11 |
| Magneti Marelli | 360406188101 |
| METELLI | 231380C |
| MEYLE | 3155210021PD |
| Mintex | MDC2779C |
| Motaquip | LVBD1747 |
| NK Autoparts | 3115123 |
| Optimal | BS9100 |
| Optimal | BS9100HC |
| PAGID Racing | 55756HC |
| Remsa | 6144010 |
| SBS | 18153115123 |
| Textar | 92275600 |
| Textar | 92275605 |
| Textar | 98200275601 |
| TRW | DF6119S |
| VAICO | V2080097 |
| Valeo | 197755 |
| Zimmermann | 150348620 |
| Zimmermann | 150348652 |
Fits Years: 2013 2014 2015 2016
Fits Models: Cooper Paceman
