| Attribute | Value |
|---|---|
| Adjustable | No |
| Ball Joint Assembly | Yes |
| Bushings Included | No |
| Castle Nut Included | No |
| Color | Silver |
| Cotter Pin Hole | No |
| Cotter Pin Included | No |
| Distance Between Mounting Holes | 70.00 |
| Dust Boot Included | Yes |
| Dust Boot Material | Rubber |
| Grease Fitting Included | No |
| Greaseable | No |
| Material | Steel |
| Mount Plate Included | Yes |
| Mounting Bolt Head Diameter | 0.689, 17.50 |
| Mounting Bolt Length | 1.043, 26.50 |
| Mounting Bolt Thread Diameter | 0.394, 10.00 |
| Mounting Bolt Thread Length | 0.709, 18.00 |
| Mounting Bolt Thread Pitch | 1.5 |
| Mounting Bolts Included | Yes |
| Mounting Hardware Included | Yes |
| Mounting Hole Diameter | 10.7 |
| Mounting Hole Quantity | 2 |
| Mounting Type | Bolt-in |
| Nuts Included | No |
| Position(s) | Front Lower Outer |
| Stud Taper Per Foot | 2.1 |
| Stud Tapered End 1 Diameter | 0.65, 16.51 |
| Stud Tapered End 2 Diameter | 0.825, 20.95 |
| Stud Thread Diameter | 0.551, 14 |
| Stud Thread Length | 1.063, 27 |
| Stud Thread Pitch | 1.5 |
| Stud Threads Per Inch | 17 |
| Stud Type | Threaded |
| Suspension Grade Type | Standard Replacement |
| Tapered Stud | Yes |
| Type | Premium |
| Washers Included | No |
| Wrench Size | 6mm |
This part fits the following vehicles:
| SubmodelSUB- MODEL |
Body Style | Years | Engine | Attributes |
|---|---|---|---|---|
| Base | Hatchback | 2013 - 2016 | L4 1.6L | FWD Automatic & Manual |
| John Cooper Works | Hatchback | 2014 - 2016 | L4 1.6L Turbo | AWD Automatic & Manual |
| John Cooper Works ALL4 | Hatchback | 2013 - 2016 | L4 1.6L Turbo | AWD Automatic & Manual |
| S | Hatchback | 2013 - 2016 | L4 1.6L Turbo | FWD Automatic & Manual |
| S ALL4 | Hatchback | 2013 - 2016 | L4 1.6L Turbo | AWD Automatic & Manual |
| S Chili | Hatchback | 2013 - 2016 | L4 1.6L Turbo | FWD Automatic & Manual |
| S Hot Chili | Hatchback | 2013 - 2016 | L4 1.6L Turbo | AWD/FWD Automatic & Manual |
We offer fast, reliable shipping on all orders:
We want you to be 100% satisfied with your purchase. That's why we offer:
This part comes with a limited lifetime warranty. Warranty begins on the original purchase date.
Warranty does NOT cover:
| Brand | Part Number |
|---|---|
| Beck/Arnley | 101-8170 |
| BMW | 31 10 9 803 662 |
| MAS Industries | BJ29045PR |
| Mevotech | MS10563 |
| MOOG Chassis Products | K500229 |
Fits Years: 2013 2014 2015 2016
Fits Models: Cooper Paceman
