Voice or type your vehicle details and Wrenchy will confirm fitment in seconds.
| Attribute | Value |
|---|---|
| Anti Lock Brake Sensor Included | No |
| Bolt Circle Diameter | 115.000, 4.527 |
| Brake Pilot Diameter | 70.600 |
| Flange Bolt Hole Quantity | 3 |
| Flange Diameter | 145.500 |
| Flange Offset | 42.100 |
| Flange Shape | Modified |
| Hub Pilot Diameter | 91.400 |
| Spline Quantity | 33 |
| Wheel Pilot Diameter | 70.100 |
| Wheel Stud Quantity | 5 |
This part fits the following vehicles:
| SubmodelSUB- MODEL |
Body Style | Years | Engine | Attributes |
|---|---|---|---|---|
| Base | SUV | 2003 - 2005 | V6 3.4L | AWD/FWD Automatic |
| Rally | SUV | 2004 - 2005 | V6 3.4L | AWD/FWD Automatic |
| V | SUV | 2003 | V6 3.4L | AWD/FWD Automatic |
We offer fast, reliable shipping on all orders:
We want you to be 100% satisfied with your purchase. That's why we offer:
This part comes with a limited lifetime warranty. Warranty begins on the original purchase date.
Warranty does NOT cover:
| Brand | Part Number |
|---|---|
| ACDelco | 513203 |
| ACDelco | FW110 |
| ACDelco | FW144 |
| ACDelco | FW274 |
| ACDelco | FW304 |
| BCA | WE60880 |
| Centric Parts | 400.62 |
| Centric Parts | 400.62000E |
| Delphi | BK10036-40L1 |
| Dorman | 951069 |
| Drive Tech America | NT513203 |
| Duralast | DL513203HD |
| Fenco | WH513160 |
| Fenco | WH513203 |
| General Motors | 10334134 |
| General Motors | 12413005 |
| General Motors | 12413006 |
| General Motors | 12413097 |
| General Motors | 12413098 |
| General Motors | 12413139 |
| General Motors | 12413195 |
| General Motors | 12413196 |
| General Motors | 12413215 |
| General Motors | 12413216 |
| General Motors | 7467505 |
| General Motors | 7467558 |
| General Motors | 7467617 |
| General Motors | 88964096 |
| General Motors | 89047803 |
| GMB | 730-0179 |
| Mevotech | H513203 |
| Mevotech Original Grade | G513203 |
| Mevotech TTX | TXF513203 |
| NAPA Bearings | BR930184 |
| NAPA Bearings | BR930472 |
| Raybestos Brakes | 713203 |
| SKF | BAR-5135 |
| SKF | BR930184 |
| SKF | BR930472 |
| Timken | 513160 |
| Timken | HA590048 |
| Timken | HA590076 |
| Timken | HA590085 |
Fits Years: 2003 2004 2005
Fits Models: Aztek
