| Attribute | Value |
|---|---|
| Anti Lock Braking System | Yes |
| Anti Lock Braking System Type | Tone Ring With Sensor |
| Bearing Generation | Gen 3 |
| Bearing Type | Ball |
| Bolt Circle Diameter | 115, 4.528 |
| Brake Pilot Diameter | 2.78, 70.6 |
| Drive Type | Driven |
| Flange Bolt Hole Quantity | 3 |
| Flange Diameter | 145, 5.71 |
| Flange Included | Yes |
| Flange Offset | 1.656, 42.1 |
| Flange Quantity | 2 |
| Flange Shape | Modified Triangle |
| Knuckle Bolt Circle Diameter | 116, 4.57 |
| Knuckle Bolt Hole Size | 0.47 |
| Knuckle Bolt Thread Pitch | 1.75 |
| Knuckle Pilot Hole Diameter | 3.59, 91.2 |
| Spline Quantity | 33 |
| Wheel Pilot Diameter | 2.76, 70.1 |
| Wheel Stud Quantity | 5 |
| Wheel Stud Size | 0.47 |
| Wheel Stud Thread Pitch | 1.5 |
This part fits the following vehicles:
| SubmodelSUB- MODEL |
Body Style | Years | Engine | Attributes |
|---|---|---|---|---|
| Base | SUV | 2001 - 2005 | V6 3.4L | AWD/FWD Automatic |
| GT | SUV | 2001 | V6 3.4L | AWD/FWD Automatic |
| Rally | SUV | 2004 - 2005 | V6 3.4L | AWD/FWD Automatic |
| V | SUV | 2002 - 2003 | V6 3.4L | AWD/FWD Automatic |
We offer fast, reliable shipping on all orders:
We want you to be 100% satisfied with your purchase. That's why we offer:
This part comes with a limited lifetime warranty. Warranty begins on the original purchase date.
Warranty does NOT cover:
| Brand | Part Number |
|---|---|
| ACDelco | 2017 |
| ACDelco | FW128 |
| ACDelco | FW293 |
| Alltech Automotive | 513121 |
| Autopart International | 1411259919 |
| Autopart International | 1411326724 |
| Carquest | 91-259919 |
| Carquest | 91-326724 |
| Centric Parts | 402.62002 |
| Centric Parts | 402.62002E |
| Centric Parts | 402.62005E |
| Centric Parts | 402.62016E |
| Dorman | 4110309 |
| Drive Tech America | NT513121 |
| Drive Tech America | NT513179 |
| Drive Tech America | NT513187 |
| DuraGo | 29513121 |
| DuraGo | 29513179 |
| DuraGo | 29513187 |
| DuraGo | 29513199 |
| FAG CA - Archived | 102026 |
| Fenco | WH513121 |
| Fenco | WH513179 |
| Fenco | WH513187 |
| General Motors | 10305030 |
| General Motors | 10434253 |
| General Motors | 12413035 |
| General Motors | 12413093 |
| General Motors | 12429203 |
| General Motors | 12429204 |
| General Motors | 12429205 |
| General Motors | 13582664 |
| General Motors | 19259596 |
| General Motors | 25673714 |
| General Motors | 25696347 |
| General Motors | 7470017 |
| General Motors | 7470105 |
| General Motors | 7470143 |
| General Motors | 7470567 |
| General Motors | 7470568 |
| General Motors | 88955477 |
| General Motors | 88964168 |
| General Motors | 88964968 |
| General Motors | 89047684 |
| General Motors | 89047802 |
| GMB | 7300003 |
| GMB | 7300055 |
| GSP | 104121 |
| Magneti Marelli | 1AMH513121 |
| Magneti Marelli | 1AMH513179 |
| Mevotech | H513121 |
| Mevotech | H513179 |
| Mevotech | H513187 |
| Mevotech | TXF513121 |
| Mevotech | TXF513179 |
| MOOG Chassis Products | 513199 |
| Parts Master | PM513121 |
| Parts Master | PM513179 |
| Parts Master | PM513187 |
| Parts Plus | P513121 |
| Parts Plus | P513179 |
| Parts Plus | P513187 |
| Power Train | PT513121 |
| Power Train | PT513179 |
| Power Train | PT513187 |
| Precision Bearing | 513187 |
| Raybestos Brakes | 713121 |
| Raybestos Brakes | 713179 |
| Raybestos Brakes | 713187 |
| Raybestos Brakes | 713199 |
| Schaeffler | FW9121 |
| SKF | BR930148 |
| SKF | BR930149 |
| SKF | BR930548K |
| Timken | 513179 |
| Timken | HA590075 |
| Timken | HA590093 |
| WJB | WA513121 |
| WJB | WA513179 |
| WJB | WA513187 |
Fits Years: 2001 2002 2003 2004 2005
Fits Models: Aztek
