| Attribute | Value |
|---|---|
| 130.00 | |
| ABS Tone Ring Included | No |
| Assy/Disassy By Qualified Personnel Required! | . |
| Balancing Type | Mill Balancing |
| Bearings Included | No |
| Bolt Hole Circle Ø [in] | 5.12 |
| Bolt Hole Circle Ø [mm] | 130 |
| Brake Disc Thickness [in] | 0.94 |
| Brake Disc Thickness [mm] | 24 |
| Brake Disc Type | Perforated / Vented, Perforated/vented |
| Brake Surface Finish | Drilled |
| California Proposition 65 Required | No |
| Center Hole Diameter | 130.0 |
| Centering Diameter [in] | 3.86 |
| Color | Silver |
| Colour | Silver |
| Construction | Full Cast |
| Directional Or Non Directional Brake Surface | Non-directional |
| Disc Finish | Coated |
| Discard Thickness | 22.00 |
| Grade Type | Standard Replacement |
| Hat Finish | Coated |
| Height [in] | 2.95 |
| Hole Arrangement / Number | 05/09 |
| Hole Arrangement/Number | 05/09 |
| Inner Diameter [in] | 7.09 |
| Inside Diameter | 98.0 |
| Machining | High-carbon |
| Material | Gray Cast Iron |
| Minimum Thickness [in] | 0.87 |
| Mounting Bolt Hole Circle Diameter | 130.00 |
| Nominal Thickness | 24.00 |
| Outer Diameter [in] | 11.77 |
| Overall Height | 75.00 |
| Rust Resistant Coating | Yes |
| Solid Or Vented Type Rotor | Vented |
| Surface | Coated |
| Surface Type | X Drilled |
| Technical Information Number | 50278pro_hc_na |
| Weight [kg] | 6,6, 6.6 |
| Wheel Bolt Bore Diameter [mm] | 15.4 |
| Wheel Bolt Bore Ø [mm] | 15.4 |
This part fits the following vehicles:
| SubmodelSUB- MODEL |
Body Style | Years | Engine | Attributes |
|---|---|---|---|---|
| Base | Convertible | 2013 - 2015 | H6 2.7L | RWD Automatic Dual Clutch |
| Base | Convertible | 2009 - 2012 | H6 2.9L | RWD Manual & Automatic Dual Clutch |
| Base | Convertible | 2005 - 2008 | H6 2.7L | RWD Automatic |
| Base | Convertible | 2005 - 2008, 2013 - 2015 | H6 2.7L | RWD Manual |
| GTS | Convertible | 2015 | H6 3.4L | RWD Manual & Automatic Dual Clutch |
| Limited Edition | Convertible | 2008 | H6 2.7L | RWD Automatic & Manual |
| RS 60 Spyder | Convertible | 2008 | H6 3.4L | RWD Automatic & Manual |
| S | Convertible | 2009 - 2015 | H6 3.4L | RWD Automatic Dual Clutch |
| S | Convertible | 2007 - 2015 | H6 3.4L | RWD Manual |
| S | Convertible | 2007 - 2008 | H6 3.4L | RWD Automatic |
| S | Convertible | 2005 - 2006 | H6 3.2L | RWD Automatic & Manual |
| S Black Edition | Convertible | 2012 | H6 3.4L | RWD Manual & Automatic Dual Clutch |
| S Limited Edition | Convertible | 2008 | H6 3.4L | RWD Automatic & Manual |
| S Porsche Design 2 | Convertible | 2009 | H6 3.4L | RWD Manual & Automatic Dual Clutch |
| S Porsche Design 2 | Convertible | 2008 | H6 3.4L | RWD Automatic |
| Spyder | Convertible | 2011 - 2012 | H6 3.4L | RWD Manual & Automatic Dual Clutch |
We offer fast, reliable shipping on all orders:
We want you to be 100% satisfied with your purchase. That's why we offer:
This part comes with a limited lifetime warranty. Warranty begins on the original purchase date.
Warranty does NOT cover:
| Brand | Part Number |
|---|---|
| ATE | 24012401761 |
| ATE | 24012401941 |
| ATE | 424176 |
| Bendix | 521602 |
| Bendix | 562585BC |
| Borg & Beck | BBD5191 |
| Bosch | 0986478592 |
| Brake Engineering | DI956031 |
| Brembo | 09666511 |
| Brembo | 9889021 |
| Delphi | BG4163 |
| Delphi | BG4163C |
| Dynamic Friction Company | 620-02034 |
| Dynamic Friction Company | 624-02034 |
| Dynamic Friction Company | 920-02034 |
| EBC Brakes | D1065D |
| FTE | 9082609 |
| FTE | BS7310HB |
| Hella Pagid | 50278PROHCNA |
| Hella Pagid | 8DD355121942 |
| JP Group A/S | 1663201107 |
| Jurid | 562585JC |
| MEYLE | 4835230002PD |
| MEYLE | 4835230005PD |
| Mintex | MDC1431 |
| Optimal | BS8932 |
| Optimal | BS8932C |
| Optimal | BS8938 |
| PAGID Racing | 50278 |
| Pilenga | V988 |
| Porsche | 987.352.031.03 |
| Porsche | 987.352.403.00 |
| Porsche | 996.352.401.03 |
| Porsche | 99635240103 |
| Remsa | 694110 |
| Textar | 92100100 |
| Textar | 92100103 |
| Textar | 92100105 |
| Textar | 92100107 |
| Textar | 92100110 |
| Textar | 98200100101 |
| VAICO | V4580002 |
| Werner Metzger GmbH | 6110924 |
| Zimmermann | 460152700 |
| Zimmermann | 460152720 |
| Zimmermann | 460152770 |
| Zimmermann | 460152772 |
| Zimmermann | 460152775 |
Fits Years: 2005 2006 2007 2008 2009 2010 2011 2012 2013 2014 2015
Fits Models: Boxster
