| Attribute | Value |
|---|---|
| 130.00 | |
| ABS Tone Ring Included | No |
| Assy/Disassy By Qualified Personnel Required! | . |
| Balancing Type | Mill Balancing |
| Bearings Included | No |
| Bolt Hole Circle Ø [in] | 5.12 |
| Bolt Hole Circle Ø [mm] | 130 |
| Brake Disc Thickness [in] | 0.79 |
| Brake Disc Thickness [mm] | 20 |
| Brake Disc Type | Internally Vented |
| California Proposition 65 Required | No |
| Center Hole Diameter | 130.0 |
| Centering Diameter [in] | 3.86 |
| Color | Silver |
| Colour | Silver |
| Construction | Full Cast |
| Directional Or Non Directional Brake Surface | Non-directional |
| Disc Finish | Coated |
| Discard Thickness | 18.00 |
| Grade Type | Standard Replacement |
| Hat Finish | Coated |
| Height [in] | 2.64 |
| Hole Arrangement / Number | 05/09 |
| Hole Arrangement/Number | 05/09 |
| Inside Diameter | 98.0 |
| Machining | High-carbon |
| Material | Gray Cast Iron |
| Minimum Thickness [in] | 0.71 |
| Minimum Thickness [mm] | 18 |
| Mounting Bolt Hole Circle Diameter | 130.00 |
| Nominal Thickness | 20.00 |
| Outer Diameter [in] | 11.50 |
| Overall Height | 67.00 |
| Rust Resistant Coating | Yes |
| Solid Or Vented Type Rotor | Vented |
| Surface | Coated |
| Surface Type | Smooth |
| Technical Information Number | 50226pro_hc_na |
| Weight [kg] | 5,9, 5.9 |
This part fits the following vehicles:
| SubmodelSUB- MODEL |
Body Style | Years | Engine | Attributes |
|---|---|---|---|---|
| Base | Convertible | 2004 | H6 2.7L | RWD Manual |
| Base | Convertible | 2001 - 2004 | H6 2.7L | RWD Automatic |
| Base | Convertible | 1997 - 2000 | H6 2.5L | RWD Manual |
| Base | Convertible | 1997 - 1999 | H6 2.5L | RWD Automatic |
| Roadster | Convertible | 2000 - 2003 | H6 2.7L | RWD Automatic & Manual |
| Roadster S | Convertible | 2000 - 2003 | H6 3.2L | RWD Automatic & Manual |
| S | Convertible | 2001 - 2004 | H6 3.2L | RWD Automatic & Manual |
| S Special Edition | Convertible | 2004 | H6 3.2L | RWD Automatic & Manual |
We offer fast, reliable shipping on all orders:
We want you to be 100% satisfied with your purchase. That's why we offer:
This part comes with a limited lifetime warranty. Warranty begins on the original purchase date.
Warranty does NOT cover:
| Brand | Part Number |
|---|---|
| ATE | 24012001761 |
| ATE | 420176 |
| Bendix | 520722 |
| Bendix | 562584BC |
| Borg & Beck | BBD4205 |
| Bosch | 0986479079 |
| Brake Engineering | DI955751 |
| Brembo | 09D58011 |
| Delphi | BG3410 |
| Dynamic Friction Company | 600-02029 |
| Dynamic Friction Company | 604-02029 |
| Dynamic Friction Company | 900-02029 |
| EBC Brakes | D1063 |
| Ferodo | DDF2023C |
| Ferodo | DDF2023C1 |
| FTE | 9082612 |
| FTE | BS4791HB |
| Girling | 6063382 |
| Hella Pagid | 50226PROHCNA |
| Hella Pagid | 8DD355121852 |
| Jurid | 562584J1 |
| Jurid | 562584JC |
| MEYLE | 4835230001PD |
| Mintex | MDC1363 |
| Optimal | BS9026 |
| Optimal | BS9026C |
| PAGID Racing | 50226 |
| PAGID Racing | 50226PRO |
| Pilenga | V989 |
| Porsche | 98635240103 |
| Remsa | 6112610 |
| Textar | 92088900 |
| Textar | 92088903 |
| Textar | 92088905 |
| Textar | 92088907 |
| Textar | 92088910 |
| Textar | 98200088901 |
| TRW | DF6338 |
| VAICO | V4580005 |
| Zimmermann | 460152400 |
| Zimmermann | 460152420 |
| Zimmermann | 460152452 |
| Zimmermann | 460152470 |
| Zimmermann | 460152472 |
| Zimmermann | 460152475 |
Fits Years: 1997 1998 1999 2000 2001 2002 2003 2004
Fits Models: Boxster
