| Attribute | Value |
|---|---|
| 130.00 | |
| ABS Tone Ring Included | No |
| Assy/Disassy By Qualified Personnel Required! | . |
| Balancing Type | Mill Balancing |
| Bearings Included | No |
| Bolt Hole Circle Ø [in] | 5.12 |
| Bolt Hole Circle Ø [mm] | 130 |
| Bolt Hole Quantity | 7 |
| Brake Disc Thickness [in] | 1.10 |
| Brake Disc Thickness [mm] | 28 |
| Brake Disc Type | Internally Vented |
| California Proposition 65 Required | No |
| Center Hole Diameter | 130.0 |
| Centering Diameter [in] | 3.35 |
| Color | Silver |
| Colour | Silver |
| Construction | Full Cast |
| Directional Or Non Directional Brake Surface | Non-directional |
| Disc Finish | Coated |
| Discard Thickness | 26.00 |
| Grade Type | Standard Replacement |
| Hat Finish | Coated |
| Hole Arrangement / Number | 05/07 |
| Hole Arrangement/Number | 05/07 |
| Inside Diameter | 85.0 |
| Machining | High-carbon |
| Material | Gray Cast Iron |
| Minimum Thickness [in] | 1.02 |
| Minimum Thickness [mm] | 26 |
| Mounting Bolt Hole Circle Diameter | 130.00 |
| Mounting Bolt Hole Quantity | 7 |
| Nominal Thickness | 28.00 |
| Number Of Bolts/screws | 1 |
| Outer Diameter [in] | 12.99 |
| Overall Height | 73.70 |
| Rust Resistant Coating | Yes |
| Solid Or Vented Type Rotor | Vented |
| Surface | Coated |
| Surface Type | Smooth |
| Technical Information Number | 54220pro_hc_na |
| Weight [kg] | 8,8, 8.8 |
| Wheel Bolt Bore Diameter [mm] | 15.4 |
| Wheel Bolt Bore Ø [mm] | 15.4 |
This part fits the following vehicles:
| SubmodelSUB- MODEL |
Body Style | Years | Engine | Attributes |
|---|---|---|---|---|
| Base | SUV | 2011 - 2016 | V6 3.0L DIESEL Turbo | AWD Automatic |
| Base | SUV | 2011 - 2014 | V6 3.0L DIESEL Turbo | AWD Manual |
| Base | SUV | 2008 - 2014, 2016 - 2018 | V6 3.6L | AWD Automatic |
| Base | SUV | 2008 - 2014 | V6 3.6L | AWD Manual |
| Base | SUV | 2004 - 2006 | V6 3.2L | AWD Automatic & Manual |
| Diesel | SUV | 2013 - 2018 | V6 3.0L DIESEL Turbo | AWD Automatic |
| Diesel Platinum Edition | SUV | 2014 | V6 3.0L DIESEL Turbo | AWD Automatic |
| GTS | SUV | 2015 - 2018 | V6 3.6L Turbo | AWD Automatic |
| GTS | SUV | 2008 - 2010, 2013 - 2014 | V8 4.8L | AWD Automatic |
| GTS | SUV | 2008 - 2010 | V8 4.8L | AWD Manual |
| Platinum Edition | SUV | 2014, 2017 - 2018 | V6 3.6L | AWD Automatic |
| Platinum Edition | SUV | 2014 | V6 3.6L | AWD Manual |
| S | SUV | 2016 | V8 4.2L DIESEL Turbo | AWD Automatic |
| S | SUV | 2015 - 2016 | V6 3.0L PLUG-IN HYBRID EV-GAS (PHEV) Supercharged | AWD Automatic |
| S | SUV | 2015 - 2018 | V6 3.6L Turbo | AWD Automatic |
| S | SUV | 2011 - 2014 | V6 3.0L FULL HYBRID EV-GAS (FHEV) Supercharged | AWD Automatic |
| S | SUV | 2008 - 2016 | V8 4.8L | AWD Automatic |
| S | SUV | 2004 - 2006 | V8 4.5L | AWD Manual |
| S | SUV | 2003 - 2006 | V8 4.5L | AWD Automatic |
| S E-Hybrid | SUV | 2015 - 2018 | V6 3.0L PLUG-IN HYBRID EV-GAS (PHEV) Supercharged | AWD Automatic |
| S E-Hybrid Platinum Edition | SUV | 2017 - 2018 | V6 3.0L PLUG-IN HYBRID EV-GAS (PHEV) Supercharged | AWD Automatic |
| S Hybrid | SUV | 2011 - 2014 | V6 3.0L FULL HYBRID EV-GAS (FHEV) Supercharged | AWD Automatic |
| S Platinum Edition | SUV | 2017 - 2018 | V6 3.6L Turbo | AWD Automatic |
| S Transsyberia | SUV | 2010 | V8 4.8L | AWD Automatic |
| Turbo | SUV | 2008 - 2018 | V8 4.8L Turbo | AWD Automatic |
| Turbo | SUV | 2003 - 2006 | V8 4.5L Turbo | AWD Automatic |
| Turbo S | SUV | 2009 - 2010, 2013 - 2014, 2016 - 2018 | V8 4.8L Turbo | AWD Automatic |
| Turbo S | SUV | 2006 | V8 4.5L Turbo | AWD Automatic |
We offer fast, reliable shipping on all orders:
This part comes with a limited lifetime warranty. Warranty begins on the original purchase date.
Warranty does NOT cover:
We want you to be 100% satisfied with your purchase. That's why we offer:
| Brand | Part Number |
|---|---|
| Akebono | BN0227 |
| Akebono | BN0227E |
| AMC | FO4021 |
| ATE | 24012801491 |
| ATE | 428149 |
| Bendix | 521227 |
| Bendix | 562325B |
| Bendix | 562393B |
| Bendix | 562393BC |
| Bendix | BR2245ULT |
| Blue Print | ADV184332 |
| Borg & Beck | BBD5131 |
| Bosch | 0986479095 |
| Bosch | 0986479S20 |
| Bosch | 0986AB5955 |
| Bosch | 0986AB6135 |
| Brake Engineering | DI956231 |
| Brembo | 09A05610 |
| Brembo | 09A05611 |
| Brembo | 09A05614 |
| Brembo | 09C88411 |
| Brembo | 59E11461 |
| Cifam | 800883C |
| Delphi | BG3775 |
| Delphi | BG3775C |
| Delphi | BG3775C18B1 |
| Delphi | BG3775C19B1 |
| Dynamic Friction Company | 600-74048 |
| Dynamic Friction Company | 604-74048 |
| Dynamic Friction Company | 900-74048 |
| EBC Brakes | D1327 |
| EBC Brakes | GD1327 |
| EBC Brakes | USR1327 |
| Febi-Bilstein | 28157 |
| Ferodo | DDF1580 |
| Ferodo | DDF15801 |
| Ferodo | DDF1580C |
| Ferodo | DDF1580C1 |
| Ferodo | DDF1580C1D |
| Ferodo | DDF1580DSL1D |
| Ferodo | DDF1580DSR1D |
| FREMAX BRAKE ROTORS AND DRUMS | BD3328 |
| FTE | 9071211 |
| FTE | 9081057 |
| FTE | 9082565 |
| FTE | BS5372 |
| FTE | BS5372B |
| FTE | BS5372HB |
| Girling | 6044875 |
| Hella Pagid | 54220PROHCNA |
| Hella Pagid | 8DD355109822 |
| Japan Parts | DP0918 |
| Japan Parts | DP0918C |
| JP Group A/S | 1163202600 |
| Jurid | 562325J |
| Jurid | 562393J |
| Jurid | 562393JC |
| Jurid | 562393JC1 |
| Key Parts | KBD5131 |
| LPR | P2000V |
| LPR | P2000VR |
| Magneti Marelli | 360406069400 |
| Magneti Marelli | 360704028200 |
| METELLI | 230883C |
| MEYLE | 1155230041 |
| MEYLE | 1155230041PD |
| MEYLE | 1155231105PD |
| Mintex | MDC1612 |
| Mintex | MDC1612C |
| Mintex | MDC81612C |
| Motaquip | LVBD1365Z |
| National | NBD1235 |
| NK Autoparts | 2047106 |
| NK Autoparts | 3147106 |
| NK Autoparts | 344710 |
| NK Autoparts | 3447106 |
| Optimal | BS8096 |
| Optimal | BS8096C |
| PAGID Racing | 54220 |
| PAGID Racing | 54220PRO |
| PAGID Racing | 65119 |
| Porsche | 95535240100 |
| Remsa | 697110 |
| SBS | 18152047106 |
| SBS | 18153147106 |
| SBS | 1815344710 |
| SBS | 18153447106 |
| Skoda | 7L8 615 601 G |
| Skoda | 7L8 615 601 N |
| Textar | 92122000 |
| Textar | 92122003 |
| Textar | 92122005 |
| Textar | 92122010 |
| Textar | 98200122001 |
| Topran | 111290 |
| TRW | DF4487S |
| TRW Steering and Suspension Parts | DF4487 |
| TRW Steering and Suspension Parts | DF4487SL |
| TRW Steering and Suspension Parts | DF4487SR |
| TRW Steering and Suspension Parts | DF4487XSS |
| VAICO | V1080006 |
| Valeo | 196077 |
| Valeo | 197090 |
| Valeo | 297090 |
| Valeo | 672615 |
| Volkswagen | 7L6 661 560 D |
| Volkswagen | 7L6 661 560 J |
| Wagner | WGR15801 |
| Zimmermann | 600322900 |
| Zimmermann | 600322920 |
| Zimmermann | 600322954 |
| Zimmermann | 600322955 |
| Zimmermann | 600322970 |
| Zimmermann | 600322972 |
| Zimmermann | 600322975 |
Fits Years: 2003 2004 2005 2006 2008 2009 2010 2011 2012 2013 2014 2015 2016 2017 2018
Fits Models: Cayenne
