Voice or type your vehicle details and Wrenchy will confirm fitment in seconds.
| Attribute | Value |
|---|---|
| Active Or Passive Suspension | Passive |
| Adjustable Compression | No |
| Adjustable Damping | No |
| Adjustable Rebound | No |
| Adjustable Ride Height | No |
| Air Adjustable | No |
| Air Ride Suspension | No |
| Bearing Plate Included | No |
| Bladder Heavy Duty Crimping Rings Included | No |
| Bladder Sleeve(s) Included | No |
| Bladder(s) Included | No |
| Body Color | White |
| Body Diameter | 2.25, 57.2 |
| Body Material | Steel |
| Boot Included | Yes |
| Coil Over Springs Included | No |
| Coil Spring Insulator(s) Included | No |
| Compressed Length | 16.81, 427 |
| Cylinder Color | White |
| Cylinder Finish | Painted |
| Cylinder Material | Steel |
| Cylinder Outside Diameter | 2.25, 57.2 |
| Dust Shield Color | Red |
| Dust Shield Diameter | 2.99, 75.9 |
| Dust Shield Included | Yes |
| Dust Shield Material | Rubber |
| Extended Length | 27.59, 700.8 |
| Gas Charged | Yes |
| Grade Type | Performance |
| Hydraulic Lockout | No |
| Includes Bump Stop | No |
| Internal Construction Type | Twin Tube |
| Internal Rebound Bumper | No |
| Internal Rebound Spring | No |
| Lower Mount Code | Ls47 |
| Lower Mount Type | Loop Bushing And Sleeve Mount - 9/16" Sleeve Id X 1.5/8" Sleeve Oal |
| Maximum Ride Height Lowering Distance | 0 |
| Maximum Ride Height Raising Distance | 0 |
| Mounting Hardware Included | No |
| Parts Pack(s) | None |
| Remote Reservoir | No |
| Rod Diameter | 0.622, 15.8 |
| Self Leveling | No |
| Shaft Material | Nitrocarburized |
| Shock Absorber Body End Measuring Point | Center Of Loop |
| Shock Absorber Bore Size | 1.3779527559055118, 35 |
| Shock Absorber Rod End Measuring Point | Center Of Loop |
| Shock Stroke | 10.78, 273.8 |
| Spring Included | No |
| Spring Isolators Included | No |
| Spring Seat Included | No |
| Strut Mount Insulator(s) Included | No |
| Travel Length | 10.78, 273.8 |
| Upper Mount Code | Ls47 |
| Upper Mount Type | Loop Bushing And Sleeve Mount - 9/16" Sleeve Id X 1.5/8" Sleeve Oal |
| Valving Type | Progressive |
This part fits the following vehicles:
| SubmodelSUB- MODEL |
Body Style | Years | Engine | Attributes |
|---|---|---|---|---|
| Big Horn | Crew Cab Pickup | 2012 | V8 5.7L | RWD/4WD Automatic |
| Big Horn | Extended Cab Pickup | 2012 | V8 5.7L | RWD/4WD Automatic |
| Express | Crew Cab Pickup | 2012 | V8 5.7L | RWD/4WD Automatic |
| Express | Extended Cab Pickup | 2012 | V8 5.7L | RWD/4WD Automatic |
| Express | Standard Cab Pickup | 2012 | V8 5.7L | RWD/4WD Automatic |
| Laramie | Crew Cab Pickup | 2012 | V8 5.7L | RWD/4WD Automatic |
| Laramie | Extended Cab Pickup | 2012 | V8 5.7L | RWD/4WD Automatic |
| Laramie Longhorn | Crew Cab Pickup | 2012 | V8 5.7L | RWD/4WD Automatic |
| Outdoorsman | Crew Cab Pickup | 2012 | V8 4.7L FLEX | RWD/4WD Automatic |
| Outdoorsman | Crew Cab Pickup | 2012 | V8 5.7L | RWD/4WD Automatic |
| Outdoorsman | Extended Cab Pickup | 2012 | V8 4.7L FLEX | RWD/4WD Automatic |
| Outdoorsman | Extended Cab Pickup | 2012 | V8 5.7L | RWD/4WD Automatic |
| Outdoorsman | Standard Cab Pickup | 2012 | V8 4.7L FLEX | RWD/4WD Automatic |
| Outdoorsman | Standard Cab Pickup | 2012 | V8 5.7L | RWD/4WD Automatic |
| SLT | Crew Cab Pickup | 2012 | V8 4.7L FLEX | RWD/4WD Automatic |
| SLT | Crew Cab Pickup | 2012 | V8 5.7L | RWD/4WD Automatic |
| SLT | Extended Cab Pickup | 2012 | V8 4.7L FLEX | RWD/4WD Automatic |
| SLT | Extended Cab Pickup | 2012 | V8 5.7L | RWD/4WD Automatic |
| SLT | Standard Cab Pickup | 2012 | V8 4.7L FLEX | RWD/4WD Automatic |
| SLT | Standard Cab Pickup | 2012 | V8 5.7L | RWD/4WD Automatic |
| ST | Crew Cab Pickup | 2012 | V6 3.7L | RWD/4WD Automatic |
| ST | Crew Cab Pickup | 2012 | V8 4.7L FLEX | RWD/4WD Automatic |
| ST | Crew Cab Pickup | 2012 | V8 5.7L | RWD/4WD Automatic |
| ST | Extended Cab Pickup | 2012 | V6 3.7L | RWD/4WD Automatic |
| ST | Extended Cab Pickup | 2012 | V8 4.7L FLEX | RWD/4WD Automatic |
| ST | Extended Cab Pickup | 2012 | V8 5.7L | RWD/4WD Automatic |
| ST | Standard Cab Pickup | 2012 | V6 3.7L | RWD/4WD Automatic & Manual |
| ST | Standard Cab Pickup | 2012 | V8 4.7L FLEX | RWD/4WD Automatic |
| ST | Standard Cab Pickup | 2012 | V8 5.7L | RWD/4WD Automatic |
| Sport | Crew Cab Pickup | 2012 | V8 5.7L | RWD/4WD Automatic |
| Sport | Extended Cab Pickup | 2012 | V8 5.7L | RWD/4WD Automatic |
| Sport | Standard Cab Pickup | 2012 | V8 5.7L | RWD/4WD Automatic |
| Tradesman | Crew Cab Pickup | 2012 | V8 4.7L FLEX | RWD/4WD Automatic |
| Tradesman | Crew Cab Pickup | 2012 | V8 5.7L | RWD/4WD Automatic |
| Tradesman | Extended Cab Pickup | 2012 | V8 4.7L FLEX | RWD/4WD Automatic |
| Tradesman | Extended Cab Pickup | 2012 | V8 5.7L | RWD/4WD Automatic |
| Tradesman | Standard Cab Pickup | 2012 | V8 4.7L FLEX | RWD/4WD Automatic |
| Tradesman | Standard Cab Pickup | 2012 | V8 5.7L | RWD/4WD Automatic |
| Tradesman HD | Standard Cab Pickup | 2012 | V8 5.7L | RWD Automatic |
We offer fast, reliable shipping on all orders:
We want you to be 100% satisfied with your purchase. That's why we offer:
This part comes with a limited lifetime warranty. Warranty begins on the original purchase date.
Warranty does NOT cover:
| Brand | Part Number |
|---|---|
| AL-KO Xtreme | 813003 |
| Bulldog HD | HD12140851 |
| Gold Shock Absorber | 7186006 |
| Monroe Shocks & Struts | 34521 |
| Monroe Shocks & Struts | 34535 |
| Monroe Shocks & Struts | 911199 |
| Monroe Shocks & Struts | 911222 |
| Pro Comp Suspension | 927543B |
| Rancho | RS5269 |
| Skyjacker | N8017 |
Fits Years: 2012
Fits Models: 1500
