| Attribute | Value |
|---|---|
| 98.3 | |
| Attribute ID (Type) | California Proposition 65 |
| Bolt Circle Diameter [cntrc] In | 3.858 |
| Bolt Circle Diameter [cntrc] Mm | 98.000 |
| Bolt Hole Quantity | 5 |
| Friction Surface Width [cntrc] In | 2.504 |
| Friction Surface Width [cntrc] Mm | 63.600 |
| Friction Surface Inches | 2.50 |
| Friction Surface Mm | 63.6 |
| Height [cntrc] In | 3.090 |
| Height [cntrc] Mm | 78.486 |
| Hub Hole / Register [cntrc] In | 2.327 |
| Hub Hole / Register [cntrc] Mm | 59.100 |
| Maximum Brake Diameter (Discard) | 10.070, 255.80, 255.800 |
| Misc Holes [cntrc] | 3 |
| Mounting Hole Diameter | 0.52, 0.520, 13.210 |
| Mounting Type [cntrc] | Floating |
| Nominal Drum Diameter | 10.000, 253.8, 254.000 |
| Outer Cooling Fins | No |
| Product Grade [cntrc] | Standard |
| Weight [cntrc] Kgs | 10.795 |
| Weight [cntrc] Lbs | 23.750 |
This part fits the following vehicles:
| SubmodelSUB- MODEL |
Body Style | Years | Engine | Attributes |
|---|---|---|---|---|
| Base | Mini Passenger Van | 2015 - 2022 | L4 2.4L | FWD Automatic |
| SLT | Mini Cargo Van | 2015 - 2016 | L4 2.4L | FWD Automatic |
| SLT | Mini Passenger Van | 2015 - 2022 | L4 2.4L | FWD Automatic |
| ST | Mini Cargo Van | 2015 - 2019 | L4 2.4L | FWD Automatic |
| ST | Mini Passenger Van | 2015 - 2016, 2020 - 2022 | L4 2.4L | FWD Automatic |
| Tradesman | Mini Cargo Van | 2015 - 2022 | L4 2.4L | FWD Automatic |
| Tradesman SLT | Mini Cargo Van | 2015 - 2021 | L4 2.4L | FWD Automatic |
We offer fast, reliable shipping on all orders:
We want you to be 100% satisfied with your purchase. That's why we offer:
This part comes with a limited lifetime warranty. Warranty begins on the original purchase date.
Warranty does NOT cover:
| Brand | Part Number |
|---|---|
| Canadian Tire | 123.63049 |
| Mighty Distributing System | 860045 |
| Qualis | 23099 |
| Raybestos Brakes | 97869R |
Fits Years: 2015 2016 2017 2018 2019 2020 2021 2022
Fits Models: ProMaster City
