| Attribute | Value |
|---|---|
| Adjustable | No |
| Ball Joint Assembly | Yes |
| Bushings Included | No |
| Castle Nut Included | No |
| Color | Gray |
| Cotter Pin Hole | No |
| Cotter Pin Included | No |
| Distance Between Mounting Holes | 41.50 |
| Dust Boot Included | Yes |
| Dust Boot Material | Rubber |
| Grease Fitting Included | No |
| Greaseable | No |
| Material | Steel |
| Maximum Outside Diameter | 1.870, 47.50 |
| Mount Plate Included | No |
| Mounting Bolt Head Diameter | 0.709, 18.00 |
| Mounting Bolt Length | 3.248, 82.50 |
| Mounting Bolt Shank Diameter | 0.438, 11.00 |
| Mounting Bolt Thread Diameter | 0.438, 11.13 |
| Mounting Bolt Thread Length | 1.299, 33.00 |
| Mounting Bolt Threads Per Inch | 20 |
| Mounting Bolts Included | Yes |
| Mounting Hardware Included | Yes |
| Mounting Hole Quantity | 2 |
| Mounting Type | Bolt-in |
| Nuts Included | Yes |
| Position(s) | Front Lower, Front Upper. For The Position Specific To Your Vehicle, Refer To The Applications. |
| Stud Tapered End 1 Diameter | 0.675, 17.15 |
| Stud Tapered End 2 Diameter | 0.764, 19.4 |
| Stud Thread Diameter | 0.5, 12.7 |
| Stud Thread Length | 1.043, 26.5 |
| Stud Threads Per Inch | 20 |
| Stud Type | Threaded |
| Suspension Grade Type | Standard Replacement |
| Tapered Stud | No |
| Washers Included | Yes |
| Wrench Size | 16mm |
This part fits the following vehicles:
| SubmodelSUB- MODEL |
Body Style | Years | Engine | Attributes |
|---|---|---|---|---|
| Base | Hatchback | 1991 - 1992 | L4 2.1L | FWD Automatic & Manual |
| Base | Hatchback | 1981 - 1990 | L4 2.0L | FWD Automatic & Manual |
| Base | Sedan | 1991 - 1992 | L4 2.1L | FWD Automatic & Manual |
| Base | Sedan | 1981 - 1990 | L4 2.0L | FWD Automatic & Manual |
| EMS | Hatchback | 1979 - 1980 | L4 2.0L | FWD Automatic & Manual |
| GL | Hatchback | 1979 | L4 2.0L | FWD Automatic & Manual |
| GLE | Hatchback | 1979 - 1980 | L4 2.0L | FWD Automatic & Manual |
| GLI | Hatchback | 1980 | L4 2.0L | FWD Automatic & Manual |
| S | Convertible | 1991 - 1993 | L4 2.1L | FWD Automatic & Manual |
| S | Hatchback | 1991 - 1993 | L4 2.1L | FWD Automatic & Manual |
| S | Hatchback | 1981 - 1990 | L4 2.0L | FWD Automatic & Manual |
| S | Sedan | 1991 - 1993 | L4 2.1L | FWD Automatic & Manual |
| S | Sedan | 1986 | L4 2.0L | FWD Automatic & Manual |
| S | Sedan | 1981 - 1990 | L4 2.0L | FWD Automatic & Manual |
| S Turbo | Convertible | 1991 | L4 2.0L Turbo | FWD Automatic & Manual |
| S Turbo | Hatchback | 1991 | L4 2.0L Turbo | FWD Automatic & Manual |
| SE Turbo | Convertible | 1991 | L4 2.0L Turbo | FWD Automatic & Manual |
| SE Turbo | Hatchback | 1991 | L4 2.0L Turbo | FWD Automatic & Manual |
| SPG | Hatchback | 1986 - 1991 | L4 2.0L Turbo | FWD Automatic & Manual |
| Turbo | Convertible | 1986 - 1990, 1992 - 1993 | L4 2.0L Turbo | FWD Automatic & Manual |
| Turbo | Hatchback | 1979 - 1990, 1992 - 1993 | L4 2.0L Turbo | FWD Automatic & Manual |
| Turbo | Hatchback | 1979 - 1980 | L4 2.0L Turbo | FWD Automatic & Manual |
| Turbo | Sedan | 1981 - 1985, 1989 - 1990 | L4 2.0L Turbo | FWD Automatic & Manual |
| Turbo Commemorative Edition | Hatchback | 1993 | L4 2.0L Turbo | FWD Automatic & Manual |
We offer fast, reliable shipping on all orders:
We want you to be 100% satisfied with your purchase. That's why we offer:
This part comes with a limited lifetime warranty. Warranty begins on the original purchase date.
Warranty does NOT cover:
| Brand | Part Number |
|---|---|
| General Motors | 8933970 |
| General Motors | 8985348 |
| Mevotech | GK9578 |
Fits Years: 1979 1980 1981 1982 1983 1984 1985 1986 1987 1988 1989 1990 1991 1992 1993
