| Attribute | Value |
|---|---|
| ABS Tone Ring Included | No |
| Center Hole Diameter | 2.78, 70.6 |
| Conventional Or Drum In Hat Type Rotor | Conventional |
| Directional Or Non Directional Brake Surface | Non-directional |
| Discard Thickness | 0.413, 10.5 |
| Harmonize Code | 8708.30.5030 |
| Material | Cast Iron |
| Mounting Bolt Hole Circle Diameter | 115, 4.528 |
| Mounting Bolt Hole Diameter | 0.557, 14.15 |
| Mounting Bolt Hole Quantity | 6 |
| Nominal Thickness | 0.472 |
| Overall Height | 1.37, 34.8 |
| Salability Restrictions | No |
| Solid Or Vented Type Rotor | Solid |
| Stud/Lug Hole Quantity | 6 |
| UNSPSC Code | 25171715 |
This part fits the following vehicles:
| SubmodelSUB- MODEL |
Body Style | Years | Engine | Attributes |
|---|---|---|---|---|
| 1 | Mini Passenger Van | 2007 | V6 3.9L | FWD Automatic |
| 1 | Mini Passenger Van | 2007 | V6 3.9L FLEX | FWD Automatic |
| 2 | Mini Passenger Van | 2007 | V6 3.9L | FWD Automatic |
| 2 | Mini Passenger Van | 2007 | V6 3.9L FLEX | FWD Automatic |
| 2 | Mini Passenger Van | 2006 | V6 3.5L | FWD Automatic |
| 3 | Mini Passenger Van | 2007 | V6 3.9L FLEX | FWD Automatic |
| 3 | Mini Passenger Van | 2006 | V6 3.5L | AWD/FWD Automatic |
| 3 | Mini Passenger Van | 2006 - 2007 | V6 3.9L | FWD Automatic |
| 3 | Mini Passenger Van | 2006 | V6 3.9L | AWD Automatic |
We offer fast, reliable shipping on all orders:
We want you to be 100% satisfied with your purchase. That's why we offer:
This part comes with a limited lifetime warranty. Warranty begins on the original purchase date.
Warranty does NOT cover:
| Brand | Part Number |
|---|---|
| ACDelco | 177-0992 |
| Advance Auto Parts | YH145625 |
| Advance Auto Parts | YH145625C |
| Advance Auto Parts | YH145625P |
| Advance Auto Parts | YH145686 |
| Autoxtra | AX55119 |
| AutoZone | 55119DG |
| Bendix | 145625 |
| Bendix | PRT5625 |
| Bosch | 25010671 |
| BrakeBest | 580373 |
| BrakeBest | 580373FZN |
| BrakeBest | 580373R |
| BrakeBest | 580373RGS |
| Brembo | 08.B590.10 |
| Casting Numbers | 326264 |
| Centric Parts | 120.66062 |
| Centric Parts | 120.66062CRY |
| Centric Parts | 121.66062 |
| Centric Parts | 126.66062SL |
| Centric Parts | 126.66062SR |
| Centric Parts | 127.66062L |
| Centric Parts | 127.66062R |
| Centric Parts | 128.66062L |
| Centric Parts | 128.66062R |
| Centric Parts | 320.66062 |
| Dura Corp | BR55119 |
| Dura Corp | BR5511902 |
| General Motors | 19303821 |
| Mighty Distributing System | 55119 |
| Promax | 14-55119 |
| Promax | 20-55119 |
| Saturn | 10377634 |
| TruStar | 493865 |
| VIPAR - Vehicle Indusrty Parts & Manufacturing | X51728 |
| WABCO - Archived | PS126501 |
| Wagner Brake | BD126501 |
| Wagner Brake | BD126501E |
| Winhere | 661709 |
Fits Years: 2006 2007
Fits Models: Relay
