| Attribute | Value |
|---|---|
| Bolt Hole Pattern | 2 |
| Bolt Hole PCD Clutch Pres.plte | 254 |
| Bolt Hole PCD Crankshaft | 2.5984, 66 |
| Centering Diameter / Dowel Hole | 254 |
| Crank Hole Dia. | 0.4094, 10.4 |
| Crank To Friction Surface | 0.9961, 25.3 |
| Dowel Hole Pattern | 5 |
| Dowel Hole Diameter | 0.2362, 6 |
| Flange Thickness | 0.4055, 10.3 |
| Flywheel Cup Depth Or Step Height | -0.0787, -2 |
| Flywheel Friction Surface Inner Diameter | 145, 5.7087 |
| Flywheel Thickness [mm] | 1.0236, 26 |
| Flywheel Friction Surface Outer Diameter | 234, 9.2126 |
| Flywheel Matches Clutch | Flywheel Matches Clutch |
| Has Dowel Pins | With Dowel Pins |
| I.D. For Pilot | 1.2461, 31.65 |
| Number Of Teeth, Starter Ring Gear | 124 |
| Overall Casting O.D. | 11.8799, 301.75 |
| Ring Gear Chamfer Position @ 6:00 O´clock | Not Available |
| Ring Gear Chamfer Side | Not Available |
| Ring Gear Chamfer Matches OE | Ring Gear Chamfer Matches Oe |
| Ring Gear Major Dia. | 12.4016, 315 |
| Ring Gear Mounting O.D. | 11.378, 289 |
| Ring Gear Thickness | 0.437, 11.1 |
This part fits the following vehicles:
| SubmodelSUB- MODEL |
Body Style | Years | Engine | Attributes |
|---|---|---|---|---|
| 2.5i | Wagon | 2014 | H4 2.5L | AWD Automatic |
| 2.5i | Wagon | 2013 - 2017 | H4 2.5L | AWD Automatic CVT |
| 2.5i | Wagon | 2013 - 2014 | H4 2.5L | AWD Manual |
| 2.5i Convenience | Wagon | 2014 | H4 2.5L | AWD Manual |
| 2.5i Convenience | Wagon | 2013 - 2014 | H4 2.5L | AWD Automatic CVT |
| 2.5i Limited | Wagon | 2013 - 2017 | H4 2.5L | AWD Automatic CVT |
| 2.5i Premium | Wagon | 2013 - 2017 | H4 2.5L | AWD Automatic CVT |
| 2.5i Premium | Wagon | 2013 - 2014 | H4 2.5L | AWD Manual |
| 2.5i Touring | Wagon | 2013 - 2017 | H4 2.5L | AWD Automatic CVT |
| 2.5i Touring | Wagon | 2013 - 2014 | H4 2.5L | AWD Manual |
| 3.6R | Wagon | 2013 - 2014 | H6 3.6L | AWD Automatic |
| 3.6R Limited | Wagon | 2015 - 2017 | H6 3.6L | AWD Automatic CVT |
| 3.6R Limited | Wagon | 2013 - 2014 | H6 3.6L | AWD Automatic |
| 3.6R Premium | Wagon | 2017 | H6 3.6L | AWD Automatic CVT |
| 3.6R Touring | Wagon | 2015 - 2017 | H6 3.6L | AWD Automatic CVT |
| Base | Wagon | 2015 | H4 2.5L | AWD Automatic CVT |
| Base | Wagon | 2013 | H4 2.5L | AWD Automatic |
| Base | Wagon | 2013 | H6 3.6L | AWD Automatic |
| Limited | Wagon | 2015 | H4 2.5L | AWD Automatic CVT |
| Limited | Wagon | 2015 | H6 3.6L | AWD Automatic CVT |
| Limited | Wagon | 2013 - 2014 | H4 2.5L | AWD Automatic |
| Premium | Wagon | 2015 | H4 2.5L | AWD Automatic CVT |
| Premium | Wagon | 2015 | H6 3.6L | AWD Automatic CVT |
We offer fast, reliable shipping on all orders:
We want you to be 100% satisfied with your purchase. That's why we offer:
This part comes with a limited lifetime warranty. Warranty begins on the original purchase date.
Warranty does NOT cover:
| Brand | Part Number |
|---|---|
| NAPA Clutch and Flywheel | 88476 |
| Subaru | 12342-AA110 |
Fits Years: 2013 2014 2015 2016 2017
Fits Models: Outback
