2004 - 2009 Subaru Outback Spark Plug (NGK) NEW

$ 13 .48

Product Notes

⚠️ Most jobs typically require 4 of this item.
Gap 0.044" Actual OE Manufacturer 30,000 mi OE Mfr Recommended Service Interval
Laser Platinum Spark Plug
NGK Laser Platinum spark plugs provide high ignitability and longer service life compared to conventional nickel spark plugs. Laser Platinum plugs are tested to the highest standards to ensure quality and durability. Engineered specifically for OE applications. Laser platinum plugs provide stable idling, superior anti-fouling, improved fuel efficiency and lower emissions. High-grade pure alumina ceramic and 98% pure copper core prevents spark plug from overheating and provides reliable starts. Most Laser Platinum spark plugs feature a platinum pad on the ground electrode for even wear in distributorless ignition systems.
Brand: NGK
Condition: New
See Other Subaru Outback Spark Plugs
LIFE
TIME
Lifetime Warranty Included
This part is backed by our industry-leading lifetime warranty. Shop with total confidence.
100%money-back 120-dayreturns OE-gradequality
Wrenchy the Robot

Meet Wrenchy - The Amazing Parts Assistant!

Voice or type your vehicle details and Wrenchy will confirm fitment in seconds.

Specifications & Info


Attribute Value
Center Electrode Core Material Copper
Center Electrode Design Fine Wire
Center Electrode Insulator Tip Projection 0.14, 3.5
Center Electrode Projection Mid Projection
Center Electrode Tip Material Platinum
Electrical Terminal Type Non-removable Nut
Grade Type Performance
Ground Configuration J-gap
Ground Electrode Core Material Nickel
Ground Electrode Quantity 1
Ground Electrode Tip Design Standard
Ground Electrode Tip Material Nickel
Hex Size 5/8" (16mm)
Insulator Height 1.99, 50.5
Insulator Material Ceramic
Manufacturer Heat Range 5
Material Grade Platinum
Part Number Fr5ap-11
Pre Gap Size .044, 1.1
Reach 0.750, 19.0
Resistance 5000.0
Resistor Type Yes
Seat Type Flat
Service Number Fr5ap-11
Short Style Spark Plug No
Skirt No
Skirt Length 0.0
Stock Number 5463
Thread Diameter 0.551, 14.0
Washer Included Yes
Washer Type Crush

Vehicle Fitment Guide

This part fits the following vehicles:

Subaru 1 model (tapclick to expand)(tapclick to hide)
Outback 2004-2009 (tapclick to expand)(tapclick to hide)
Swipe left/right to see more info
SubmodelSUB-
MODEL		 Body Style Years Engine Attributes
2.5 XT Wagon 2008 H4 2.5L Turbo AWD Automatic & Manual
2.5i Wagon 2006 - 2009 H4 2.5L AWD Automatic & Manual
2.5i Basic Wagon 2007 H4 2.5L AWD Automatic & Manual
2.5i L.L. Bean Edition Wagon 2008 H4 2.5L AWD Automatic
2.5i Limited Sedan 2007 H4 2.5L AWD Automatic
2.5i Limited Wagon 2006, 2008 - 2009 H4 2.5L AWD Automatic
2.5i Limited Wagon 2006 H4 2.5L AWD Manual
2.5i Limited L.L. Bean Edition Wagon 2008 H4 2.5L AWD Automatic
2.5i Special Edition Wagon 2009 H4 2.5L AWD Automatic
3.0 R Wagon 2007 - 2008 H6 3.0L AWD Automatic
3.0 R Limited Wagon 2009 H6 3.0L AWD Automatic
3.0 R Premier Wagon 2009 H6 3.0L AWD Automatic
Base Wagon 2004, 2008 H4 2.5L AWD Automatic & Manual
H6 Sedan 2004 H6 3.0L AWD Automatic
H6 Wagon 2004 H6 3.0L AWD Automatic
H6 35th Anniversary Edition Wagon 2004 H6 3.0L AWD Automatic
H6 VDC Sedan 2004 H6 3.0L AWD Automatic
H6 VDC Wagon 2004 H6 3.0L AWD Automatic
L.L. Bean Wagon 2004 H6 3.0L AWD Automatic
Limited Sedan 2004 H4 2.5L AWD Automatic & Manual
Limited Wagon 2004 - 2005, 2008 H4 2.5L AWD Automatic
Limited Wagon 2004 - 2005 H4 2.5L AWD Manual
Premier Wagon 2008 H4 2.5L AWD Automatic
R Sedan 2005 H6 3.0L AWD Automatic
R Wagon 2006 H6 3.0L AWD Automatic
R L.L. Bean Edition Sedan 2006 - 2007 H6 3.0L AWD Automatic
R L.L. Bean Edition Wagon 2005 - 2008 H6 3.0L AWD Automatic
R VDC Limited Wagon 2006 H6 3.0L AWD Automatic
Touring Wagon 2008 H4 2.5L AWD Automatic
VDC Limited Wagon 2005 H6 3.0L AWD Automatic
XT Wagon 2005 - 2008 H4 2.5L Turbo AWD Automatic
XT Wagon 2005 - 2006 H4 2.5L Turbo AWD Manual
XT Limited Wagon 2005 - 2009 H4 2.5L Turbo AWD Automatic & Manual
i Wagon 2005 H4 2.5L AWD Automatic & Manual
Verify before ordering — please confirm your vehicle's year, make, model and sub-model specifications before placing your order. If anything is unclear, our customer service team is available to help.
